1206L035/15YR

Description
PTC Resettable Fuse, Surface Mount, CHIP, 1206, ROHS COMPLIANT
CategoryPassive components    The resistor
File Size689KB,6 Pages
ManufacturerLittelfuse
Websitehttp://www.littelfuse.com
Environmental Compliance
Download Datasheet Parametric View All

1206L035/15YR Overview

PTC Resettable Fuse, Surface Mount, CHIP, 1206, ROHS COMPLIANT

1206L035/15YR Parametric

Parameter NameAttribute value
Is it lead-free?Lead free
Is it Rohs certified?conform to
MakerLittelfuse
package instructionCHIP, 1206, ROHS COMPLIANT
Reach Compliance Codecompliant
ECCN codeEAR99
Is SamacsysN
JESD-609 codee3
Installation featuresSURFACE MOUNT
Number of terminals2
Maximum operating temperature85 °C
Minimum operating temperature-40 °C
Package shapeRECTANGULAR PACKAGE
method of packingTR
Resistor typePTC RESETTABLE FUSE
surface mountYES
Terminal surfaceMatte Tin (Sn)
Terminal locationDUAL ENDED
Terminal shapeWRAPAROUND
Thermistor ApplicationsOVERLOAD PROTECTION
Base Number Matches1
POLY-FUSE
®
Resettable PTCs
Surface Mount > 1206L Series
1206L Series
Description
RoHS
The 1206L Series PTC provides surface mount overcurrent
protection for applications where space is at a premium
and resettable protection is desired.
Features
• RoHS compliant, lead-free
and halogen-free
• Fast response to fault
currents
• Compact design saves
board space
Agency Approvals
AGENCY
AGENCY FILE NUMBER
E183209
R50119118
• Low resistance
• Low-profile
• Compatible with high
temperature solders
Applications
• USB peripherals
• Disk drives
• CD-ROMs
• Plug and play protection
for motherboards and
peripherals
• Mobile phones - battery
and port protection
• Disk drives
• PDAs / digital cameras
• Game console port
protection
Electrical Characteristics
I
hold
(A)
0.125
0.16
0.20
0.25
0.35
0.35
0.50
0.50
0.75
0.75
0.75
1.10
1.50
1.75
2.00
Part Number
Marking
I
trip
(A)
0.29
0.37
0.42
0.50
0.75
0.75
1.00
1.00
1.50
1.50
1.50
2.20
3.00
3.50
3.50
V
max
(Vdc)
30
30
24
16
6
16
6
15
13.2
16
8
8
8
6
6
I
max
(A)
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
P
d
typ.
(W)
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.8
0.8
0.8
0.8
Maximum Time
To Trip
Current
(A)
1.00
1.00
8.00
8.00
8.00
8.00
8.00
8.00
8.00
8.00
8.00
8.00
8.00
8.00
8.00
Resistance
R
min
(Ω)
1.500
1.200
0.650
0.550
0.300
0.300
0.150
0.150
0.090
0.090
0.090
0.040
0.040
0.020
0.018
Agency
Approvals
Time
(Sec.)
0.20
0.30
0.10
0.08
0.10
0.10
0.10
0.10
0.20
0.20
0.20
0.10
0.30
0.50
1.50
R
1max
(Ω)
6.00
4.50
2.60
2.30
1.20
1.20
0.70
0.75
0.35
0.290
0.29
0.21
0.12
0.09
0.08
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
1206L012
1206L016
1206L020
1206L025
1206L035
1
1
1
A
B
C
D
E
J
F
M
G1
GF
G
H
K
V
L
1206L035/16
1206L050
1
1206L050/15
1206L075/13.2
1206L075/16
1206L075TH
1206L110TH
1206L150TH
1206L175
1206L200
1
1
1
I
hold
= Hold current: maximum current device will pass without tripping in 20°C still air.
I
trip
= Trip current: minimum current at which the device will trip in 20°C still air.
V
max
= Maximum voltage device can withstand without damage at rated current (I max)
I
max
= Maximum fault current device can withstand without damage at rated voltage (V
max
)
P
d
= Power dissipated from device when in the tripped state at 20°C still air.
R
min
= Minimum resistance of device in initial (un-soldered) state.
R
typ
= Typical resistance of device in initial (un-soldered) state.
R
1max
= Maximum resistance of device at 20°C measured one hour after tripping or reflow
soldering of 260°C for 20 sec.
Caution:
Operation beyond the specified rating may result in damage and possible arcing and flame.
1
Some older references to these devices may include “–C“ in the Part Number. The “–C“ should be omitted when placing new orders for the device.
© 2014 Littelfuse, Inc.
Specifications are subject to change without notice.
Revised: 04/01/14
