MIC5219-2.8BM5 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Power/power management> The power supply circuit> MIC5219-2.8BM5

MIC5219-2.8BM5: DescriptionFixed Positive LDO Regulator 2.8V 0.6V Dropout BIPolar PDSO5; CategoryPower/power management The power supply circuit; File Size116KB，12 Pages; ManufacturerMicrel ( Microchip ); Websitehttps://www.microchip.com

Download Datasheet Parametric Compare View All

MIC5219-2.8BM5 Overview

Fixed Positive LDO Regulator 2.8V 0.6V Dropout BIPolar PDSO5

MIC5219-2.8BM5 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Maker	Micrel ( Microchip )
package instruction	SOT-23, 5 PIN
Reach Compliance Code	not_compliant
Is Samacsys	N
Adjustability	FIXED
Maximum drop-back voltage 1	0.6 V
Nominal dropback voltage 1	0.35 V
Maximum absolute input voltage	20 V
Maximum input voltage	12 V
Minimum input voltage	2.5 V
JESD-30 code	R-PDSO-G5
JESD-609 code	e0
length	2.9 mm
Maximum grid adjustment rate	0.023%
Maximum load regulation	0.0196%
Humidity sensitivity level	1
Number of functions	1
Output times	1
Number of terminals	5
Working temperatureTJ-Max	125 °C
Working temperature TJ-Min	-40 °C
Maximum output current 1	0.5 A
Maximum output voltage 1	2.856 V
Minimum output voltage 1	2.744 V
Nominal output voltage 1	2.8 V
Package body material	PLASTIC/EPOXY
encapsulated code	LSSOP
Encapsulate equivalent code	TSOP5/6,.11,37
Package shape	RECTANGULAR
Package form	SMALL OUTLINE, LOW PROFILE, SHRINK PITCH
Peak Reflow Temperature (Celsius)	240
Certification status	Not Qualified
Regulator type	FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR
Maximum seat height	1.45 mm
surface mount	YES
technology	BIPOLAR
Terminal surface	Tin/Lead (Sn85Pb15)
Terminal form	GULL WING
Terminal pitch	0.95 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	30
Maximum voltage tolerance	2%
width	1.6 mm
Base Number Matches	1

Preview

Download Datasheet

View All

MIC5219

Micrel

MIC5219

500mA-Peak Output LDO Regulator

General Description

The MIC5219 is an efficient linear voltage regulator with high

peak output current capability, very low dropout voltage, and

better than 1% output voltage accuracy. Dropout is typically

10mV at light loads and less than 500mV at full load.

The MIC5219 is designed to provide a peak output current for

startup conditions where higher inrush current is demanded.

It features a 500mA peak output rating. Continuous output

current is limited only by package and layout.

The MIC5219 can be enabled or shut down by a CMOS or

TTL compatible signal. When disabled, power consumption

drops nearly to zero. Dropout ground current is minimized to

help prolong battery life. Other key features include reversed-

battery protection, current limiting, overtemperature shut-

down, and low noise performance with an ultra-low-noise

option.

The MIC5219 is available in adjustable or fixed output volt-

ages in space-saving SOT-23-5 and MM8™ 8-lead power

MSOP packages. For higher power requirements see the

MIC5209 or MIC5237.

Features

• Guaranteed 500mA-peak output over the full operating

temperature range

• Low 500mV maximum dropout voltage at full load

• Extremely tight load and line regulation

• Tiny SOT-23-5 and MM8™ power MSOP-8 package

• Ultra-low-noise output

• Low temperature coefficient

• Current and thermal limiting

• Reversed-battery protection

• CMOS/TTL-compatible enable/shutdown control

• Near-zero shutdown current

Applications

•

Laptop, notebook, and palmtop computers

Cellular telephones and battery-powered equipment

Consumer and personal electronics

PC Card V

and V

regulation and switching

SMPS post-regulator/dc-to-dc modules

High-efficiency linear power supplies

Typical Applications

MIC5219-5.0BMM

ENABLE

SHUTDOWN

MIC5219-3.3BM5

ENABLE

SHUTDOWN

OUT

2.2µF

tantalum

OUT

3.3V

2.2µF

tantalum

470pF

5V Ultra-Low-Noise Regulator

3.3V Ultra-Low-Noise Regulator

Micrel, Inc. • 1849 Fortune Drive • San Jose, CA 95131 • USA • tel + 1 (408) 944-0800 • fax + 1 (408) 944-0970 • http://www.micrel.com

July 2000

MIC5219

MIC5219-2.8BM5 Related Products

	MIC5219-2.8BM5	MIC5219-3.6BM5	MIC5219-5.0BM5	1812CG681G500N	MIC5219-3.0BM5	MIC5219-3.0BMM	MIC5219BMM	MIC5219-2.6BM5
Description	Fixed Positive LDO Regulator 2.8V 0.6V Dropout BIPolar PDSO5	Fixed Positive LDO Regulator 3.6V 0.6V Dropout BIPolar PDSO5	Fixed Positive LDO Regulator, 5V, 0.6V Dropout, BIPolar, PDSO5, SOT-23, 5 PIN	Ceramic Capacitor, Multilayer, Ceramic, 50V, 2% +Tol, 2% -Tol, C0G, -/+30ppm/Cel TC, 0.00068uF, 1812,	Fixed Positive LDO Regulator, 3V, 0.6V Dropout, BIPolar, PDSO5, SOT-23, 5 PIN	Fixed Positive LDO Regulator 3V 0.6V Dropout BIPolar PDSO8	Adjustable Positive LDO Regulator 1.24V Min 11.5V Max 0.6V Dropout BIPolar PDSO8	Fixed Positive LDO Regulator, 2.6V, 0.6V Dropout, BIPolar, PDSO5, SOT-23, 5 PIN
package instruction	SOT-23, 5 PIN	LSSOP, TSOP5/6,.11,37	LSSOP, TSOP5/6,.11,37	, 1812	LSSOP, TSOP5/6,.11,37	TSSOP, TSSOP8,.19	TSSOP, TSSOP8,.19	LSSOP, TSOP5/6,.11,37
Reach Compliance Code	not_compliant	_compli	not_compliant	unknown	not_compliant	not_compliant	not_compliant	_compli
Is it Rohs certified?	incompatible	incompatible	incompatible	-	incompatible	incompatible	incompatible	incompatible
Maker	Micrel ( Microchip )	Micrel ( Microchip )	-	-	Micrel ( Microchip )	Micrel ( Microchip )	Micrel ( Microchip )	Micrel ( Microchip )
Adjustability	FIXED	FIXED	FIXED	-	-	FIXED	ADJUSTABLE	FIXED
Maximum drop-back voltage 1	0.6 V	0.6 V	0.6 V	-	-	0.6 V	0.6 V	0.6 V
Nominal dropback voltage 1	0.35 V	0.35 V	0.35 V	-	-	0.35 V	0.35 V	0.35 V
Maximum absolute input voltage	20 V	20 V	20 V	-	-	20 V	20 V	20 V
Maximum input voltage	12 V	12 V	12 V	-	-	12 V	-	12 V
Minimum input voltage	2.5 V	2.5 V	2.5 V	-	-	2.5 V	-	2.5 V
JESD-30 code	R-PDSO-G5	R-PDSO-G5	R-PDSO-G5	-	-	S-PDSO-G8	S-PDSO-G8	R-PDSO-G5
JESD-609 code	e0	e0	e0	-	-	e0	e0	e0
length	2.9 mm	2.9 mm	2.9 mm	4.5 mm	-	3 mm	3 mm	2.9 mm
Maximum grid adjustment rate	0.023%	0.02664%	0.03%	-	-	0.024%	-	0.02187%
Humidity sensitivity level	1	1	1	-	-	1	1	1
Number of functions	1	1	1	-	-	1	1	1
Output times	1	1	1	-	-	1	1	1
Number of terminals	5	5	5	2	-	8	8	5
Working temperatureTJ-Max	125 °C	125 °C	125 °C	-	-	125 °C	125 °C	125 °C
Maximum output current 1	0.5 A	0.5 A	0.5 A	-	-	0.5 A	0.5 A	0.5 A
Maximum output voltage 1	2.856 V	3.672 V	5.1 V	-	-	3.06 V	11.5 V	2.652 V
Minimum output voltage 1	2.744 V	3.528 V	4.9 V	-	-	2.94 V	1.24 V	2.548 V
Nominal output voltage 1	2.8 V	3.6 V	5 V	-	-	3 V	-	2.6 V
Package body material	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	-	-	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY
encapsulated code	LSSOP	LSSOP	LSSOP	-	-	TSSOP	TSSOP	LSSOP
Encapsulate equivalent code	TSOP5/6,.11,37	TSOP5/6,.11,37	TSOP5/6,.11,37	-	-	TSSOP8,.19	TSSOP8,.19	TSOP5/6,.11,37
Package shape	RECTANGULAR	RECTANGULAR	RECTANGULAR	-	-	SQUARE	SQUARE	RECTANGULAR
Package form	SMALL OUTLINE, LOW PROFILE, SHRINK PITCH	SMALL OUTLINE, LOW PROFILE, SHRINK PITCH	SMALL OUTLINE, LOW PROFILE, SHRINK PITCH	SMT	-	SMALL OUTLINE, THIN PROFILE, SHRINK PITCH	SMALL OUTLINE, THIN PROFILE, SHRINK PITCH	SMALL OUTLINE, LOW PROFILE, SHRINK PITCH
Peak Reflow Temperature (Celsius)	240	240	240	-	-	240	240	240
Certification status	Not Qualified	Not Qualified	Not Qualified	-	-	Not Qualified	Not Qualified	Not Qualified
Regulator type	FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR	FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR	FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR	-	-	FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR	ADJUSTABLE POSITIVE SINGLE OUTPUT LDO REGULATOR	FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR
Maximum seat height	1.45 mm	1.45 mm	1.45 mm	-	-	1.1 mm	1.1 mm	1.45 mm
surface mount	YES	YES	YES	-	-	YES	YES	YES
technology	BIPOLAR	BIPOLAR	BIPOLAR	-	-	BIPOLAR	BIPOLAR	BIPOLAR
Terminal surface	Tin/Lead (Sn85Pb15)	Tin/Lead (Sn85Pb15)	Tin/Lead (Sn85Pb15)	-	-	Tin/Lead (Sn85Pb15)	Tin/Lead (Sn85Pb15)	Tin/Lead (Sn85Pb15)
Terminal form	GULL WING	GULL WING	GULL WING	-	-	GULL WING	GULL WING	GULL WING
Terminal pitch	0.95 mm	0.95 mm	0.95 mm	-	-	0.65 mm	0.65 mm	0.95 mm
Terminal location	DUAL	DUAL	DUAL	-	-	DUAL	DUAL	DUAL
Maximum time at peak reflow temperature	30	30	30	-	-	30	30	30
Maximum voltage tolerance	2%	2%	2%	-	-	2%	-	2%
width	1.6 mm	1.6 mm	1.6 mm	3.2 mm	-	3 mm	3 mm	1.6 mm
