LASER DIODE
NX8563LF
1 550 nm InGaAsP MQW-DFB LASER DIODE MODULE
CW LIGHT SOURCE FOR DWDM APPLICATIONS
DESCRIPTION
The NX8563LF is a 1 550 nm Multiple Quantum Well (MQW) structured
Distributed Feed-Back (DFB) laser diode module with Polarization Maintain
Fiber (PMF).
It is designed as Continuous Wave (CW) light source and ideal for optical
transmission systems with external modulators. The device is available for
Dense Wavelength Division Multiplexing (DWDM) wavelengths based on ITU-
T recommendations, enabling a wide range of applications.
FEATURES
• Output power
P
f
= 10 mW MIN.
• Available for DWDM wavelengths based on ITU-T recommendations
(100 GHz grid, please refer to the
ORDERING INFORMATION)
• Internal thermo-electric cooler and isolator
• Hermetically sealed 14-pin butterfly package
• Polarization maintain fiber pigtail
Document No. PL10215EJ03V0DS (3rd edition)
Date Published September 2005 CP(K)
The mark
shows major revised points.
NX8563LF
OPTICAL FIBER DIMENSIONS (UNIT: mm)
Parameter
Outer Diameter
Minimum Fiber Bending Radius
Fiber Length
Specification
0.9±0.1
30
1 000 MIN.
Unit
mm
mm
mm
PMF
FC-PC Connector
Fiber Length: 1 000 mm MIN.
Data Sheet PL10215EJ03V0DS
3
NX8563LF
ORDERING INFORMATION
NX8563LF
-BA
With FC-PC Connector
Wavelength Code : Refer to
Table A
Table A: DWDM wavelength based on ITU-T recommendations (@T
LD
= T
set
) (1/2)
Wavelength Code
ITU-T Wavelength
(nm)
279
287
295
303
311
318
326
334
342
350
358
366
373
381
389
397
405
413
421
429
437
445
453
461
469
477
1 527.99
1 528.77
1 529.55
1 530.33
1 531.11
1 531.89
1 532.68
1 533.46
1 534.25
1 535.03
1 535.82
1 536.60
1 537.39
1 538.18
1 538.97
1 539.76
1 540.55
1 541.34
1 542.14
1 542.93
1 543.73
1 544.52
1 545.32
1 546.11
1 546.91
1 547.71
*1
Frequency
(THz)
196.20
196.10
196.00
195.90
195.80
195.70
195.60
195.50
195.40
195.30
195.20
195.10
195.00
194.90
194.80
194.70
194.60
194.50
194.40
194.30
194.20
194.10
194.00
193.90
193.80
193.70
Wavelength Code
ITU-T Wavelength
(nm)
*1
Frequency
(THz)
193.60
193.50
193.40
193.30
193.20
193.10
193.00
192.90
192.80
192.70
192.60
192.50
192.40
192.30
192.20
192.10
192.00
191.90
191.80
191.70
191.60
191.50
191.40
191.30
191.20
191.10
485
493
501
509
517
525
533
541
549
557
565
573
581
589
597
606
614
622
630
638
646
654
663
671
679
687
1 548.51
1 549.31
1 550.11
1 550.91
1 551.72
1 552.52
1 553.32
1 554.13
1 554.94
1 555.74
1 556.55
1 557.36
1 558.17
1 558.98
1 559.79
1 560.60
1 561.41
1 562.23
1 563.04
1 563.86
1 564.67
1 565.49
1 566.31
1 567.13
1 567.95
1 568.77
*1
The value which omitted and computed the 3rd place below the decimal point
4
Data Sheet PL10215EJ03V0DS
NX8563LF
Table A: DWDM wavelength based on ITU-T recommendations (@T
LD
= T
set
) (2/2)
Wavelength Code
ITU-T Wavelength
(nm)
695
704
712
720
728
737
745
753
761
770
778
786
795
803
811
820
828
836
845
853
862
870
878
887
895
904
1 569.59
1 570.41
1 571.23
1 572.06
1 572.88
1 573.71
1 574.54
1 575.36
1 576.19
1 577.02
1 577.85
1 578.68
1 579.51
1 580.35
1 581.18
1 582.01
1 582.85
1 583.69
1 584.52
1 585.36
1 586.20
1 587.04
1 587.88
1 588.72
1 589.56
1 590.41
*1
Frequency
(THz)
191.00
190.90
190.80
190.70
190.60
190.50
190.40
190.30
190.20
190.10
190.00
189.90
189.80
189.70
189.60
189.50
189.40
189.30
189.20
189.10
189.00
188.90
188.80
188.70
188.60
188.50
Wavelength Code
ITU-T Wavelength
(nm)
*1
Frequency
(THz)
188.40
188.30
188.20
188.10
188.00
187.90
187.80
187.70
187.60
187.50
187.40
187.30
187.20
187.10
187.00
186.90
186.80
186.70
186.60
186.50
186.40
186.30
186.20
186.10
186.00
912
921
929
937
946
954
963
971
980
988
997
6006
6014
6023
6031
6040
6048
6057
6066
6074
6083
6091
6100
6109
6117
1 591.25
1 592.10
1 592.94
1 593.79
1 594.64
1 595.48
1 596.33
1 597.18
1 598.04
1 598.89
1 599.74
1 600.60
1 601.45
1 602.31
1 603.16
1 604.02
1 604.88
1 605.74
1 606.60
1 607.46
1 608.32
1 609.19
1 610.05
1 610.92
1 611.78
*1
The value which omitted and computed the 3rd place below the decimal point
Data Sheet PL10215EJ03V0DS
5
