Tension spring |
Spacing 7.5 mm
AK3011/..KD-7.5-PEBBLE GREY
1- to n-poles
Technical Data
Wire Sizes
Solid min
solid max
Stranded (flexible)
min
Stranded (flexible)
max
0.08 mm²
2.5 mm²
0.14 mm²
2.5 mm²
Insulating Material
Material
Flammability Class
Temperatures
Operating Temperature
Wave Soldering Process
Soldering Temperature,
recommended
Peak Soldering Time,
recommended
Reflow Process
Soldering Temperature,
recommended
Peak Soldering Time,
recommended
Leere Zeile
-
-
265 °C
3-4 s
-30 °C - 105 °C
PA 6.6
UL 94 V-0
Order Data (Spacing 7.5 mm)
Poles
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
Width (mm)
17.90
25.40
32.90
40.40
47.90
55.40
62.90
70.40
77.90
85.40
92.90
100.40
107.90
115.40
122.90
130.40
137.90
145.40
152.90
160.40
167.90
175.40
182.90
Article Designation
AK3011/2KD-7.5-PEBBLE GREY
AK3011/3KD-7.5-PEBBLE GREY
AK3011/4KD-7.5-PEBBLE GREY
AK3011/5KD-7.5-PEBBLE GREY
AK3011/6KD-7.5-PEBBLE GREY
AK3011/7KD-7.5-PEBBLE GREY
AK3011/8KD-7.5-PEBBLE GREY
AK3011/9KD-7.5-PEBBLE GREY
AK3011/10KD-7.5-PEBBLE GREY
AK3011/11KD-7.5-PEBBLE GREY
AK3011/12KD-7.5-PEBBLE GREY
AK3011/13KD-7.5-PEBBLE GREY
AK3011/14KD-7.5-PEBBLE GREY
AK3011/15KD-7.5-PEBBLE GREY
AK3011/16KD-7.5-PEBBLE GREY
AK3011/17KD-7.5-PEBBLE GREY
AK3011/18KD-7.5-PEBBLE GREY
AK3011/19KD-7.5-PEBBLE GREY
AK3011/20KD-7.5-PEBBLE GREY
AK3011/21KD-7.5-PEBBLE GREY
AK3011/22KD-7.5-PEBBLE GREY
AK3011/23KD-7.5-PEBBLE GREY
AK3011/24KD-7.5-PEBBLE GREY
Article Number
53011020001E
53011030001E
53011040001E
53011050001E
53011060001D
53011070001D
53011080001D
53011090001D
53011100001D
53011110001D
53011120001D
53011130001D
53011140001D
53011150001D
53011160001D
53011170001D
53011180001D
53011190001D
53011200001D
53011210001D
53011220001D
53011230001D
53011240001D
PU
100
100
100
100
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
Stranded with Ferrule 0.14 mm²
min
Stranded with Ferrule 1.5 mm²
max
Dimensions
Stripped Length
PCB Hole Diameter
Materials
Solder Tag
Tension Spring
Copper Alloy
Stainless Steel
6.0 mm
1.0 mm
Colours
PEBBLE GREY
21
RAL7032
RAL7032
22
23
24
Colours according to RAL, there may be variations on colour due to production conditions.
Special colours on request.
Accessories
Figure
Designation
Brücke, 2-polig, isoliert, BRI/2-7.5-7.62-
L8.2-LICHTGRAU
Article Number
50000000017
Ratings
Usegroup
Rated Voltage
Rated Current
Rated Wire Size
solid
stranded
Test Voltage
B
300 V
16 A
AWG 28-14
AWG 28-14
1.6 kV
C
-
-
-
-
-
D
300 V
10 A
AWG 28-14
AWG 28-14
1.6 kV
min
0.5 mm²
0.5 mm²
750 V
24 A
max
2.5 mm²
2.5 mm²
3.0 kV
