NUD3105D

Description
5 V Relay Driver Socket
File Size379KB,2 Pages
ManufacturerON Semiconductor
Websitehttp://www.onsemi.cn
Download Datasheet View All

NUD3105D Overview

5 V Relay Driver Socket

5 V Relay Driver Socket
Bipolar Relay Driver
Socket - NUD3105
Vibrator
Motor
12 V Relay Driver Socket
MOSFET Relay Driver
Socket - NUD3112
Water
Valve
Relay
Microprocessor
Microprocessor
24 V Relay Driver Socket
MOSFET Relay Driver
Socket - NUD3124
Window
Relay
Switch
Microprocessor
Most relays mounted to a PCB
require a relay driver circuit!
Available Relay Drive Circuits
Features
Integrates diodes, resistors and capacitors
into one circuit
Delivers additional current to the relay coil
and protects against ESD
Meets IEC61000-4-4 Electrical Fast Tran-
sient (EFT) test standards
Device
MDC3105
MDC3105D
NUD3105
NUD3105D
NUD3112
NUD3112D
NUD3124
NUD3124D
NUD3160
NUD3160D
NUD3048
Configuration
Single
Dual
Single
Dual
Single
Dual
Single
Dual
Single
Dual
Single
Circuit Type *
Bipolar-Clamp
Bipolar-Clamp
MOSFET
MOSFET
Bipolar-Freewheeling
Bipolar-Freewheeling
MOSFET
MOSFET
MOSFET
MOSFET
MOSFET
Voltage/Current
5 V / 500 mA
5 V / 500 mA
5 V / 500 mA
5 V / 500 mA
12 V / 500 mA
12 V / 500 mA
24 V / 150 mA
24 V / 150 mA
60 V / 150 mA
60 V / 150 mA
100 V / 900 mA
Package
SOT-23
SC-74
SOT-23
SC-74
SOT-23
SC-74
SOT-23
SC-74
SOT-23
SC-74
SC-74
Applications
Motors and electro-mechanical relays for:
utomotive windows and door locks
A
onsumer appliances, electronics, and toys
C
elecom modems
T
* Bipolar: the driver circuit consists of a transistor combined with resistors and diodes.
MOSFET: the driver circuit consists of a MOSFET combined with resistors and diodes.
