NTE30065 thru NTE30071

Super Bright LED Indicators, 10mm

Features:

RoHS Compliant

All Plastic Mold Type

/Water Clear Lens:

NTE30065 (Yellow Green, AIInGaP/GaAs)

NTE30066 (Light Green, InGaN/GaN)

NTE30067 (Orange, AllnGaP/GaAs)

NTE30068 (Light Red, AllnGaP/GaAs)

NTE30069 (Deep Red, GaAlAs/GaAlAs)

NTE30070 (Blue, INGaN/GaN)

NTE30071 (White)

Absolute Maximum Ratings:

= +25°C unless otherwise specified)

Reverse Voltage, V

NTE30066, NTE30070, NTE30071 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4V

NTE30065, NTE30067, NTE30068, NTE30069 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5V

Continuous Forward Current, I

All Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25mA

NTE30066

Only

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30mA

Peak Forward Current (1.10 Duty Cycle, 0.1ms Pulse Width), I

NTE30065, NTE30067, NTE30068, NTE30069 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50mA

NTE30066, NTE30070, NTE30071 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100mA

Power Dissipation, P

NTE30065, NTE30067, NTE30068 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100mW

NTE30069 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110mW

NTE30066, NTE30070, NTE30071 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120mW

LED Junction Temperature, T

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . +100°C

Operating Temperature Range, T

opr

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

−25°C

to +85°C

Storage Temperature Range, T

stg

All Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

−40°C

to +100°C

NTE30067

Only

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

−25°C

to +100°C

Lead Temperature (During Soldering, .063 (1.6mm) from body, 5sec max), T

. . . . . . . . . . . +260°C

Electro−Optical Characteristics:

= +25°C unless otherwise specified)

Parameter

Forward Voltage

NTE30065

NTE30066, NTE30070

NTE30067, NTE30068

NTE30069

NTE30071

Symbol

Test Conditions

= 20mA

Min

−

Typ

2.2

3.5

2.0

1.86

3.5

Max

2.5

4.0

2.5

4.2

Unit

NTE30071 Related Products

	NTE30071	NTE30065	NTE30066	NTE30067	NTE30070	NTE30069
Description	Super Bright LED Indicators, 10mm	Super Bright LED Indicators, 10mm	Super Bright LED Indicators, 10mm	Super Bright LED Indicators, 10mm	Super Bright LED Indicators, 10mm	Super Bright LED Indicators, 10mm
Reach Compliance Code	unknow	unknow	unknow	unknow	unknow	unknow
Base Number Matches	1	1	1	1	1	1
