NTE30053 thru NTE30059

Super Bright LED Indicators, 8mm

Features:

RoHS Compliant

All Plastic Mold Type

/Water Clear Lens:

NTE30053 (Yellow Green, AIInGaP/GaAs)

NTE30054 (Light Green, InGaN/GaN)

NTE30055 (Orange, AllnGaP/GaAs)

NTE30056 (Light Red, AllnGaP/GaAs)

NTE30057 (Deep Red, GaAlAs/GaAlAs)

NTE30058 (Blue, INGaN/GaN)

NTE30059 (White)

Absolute Maximum Ratings:

= +25°C unless otherwise specified)

Reverse Voltage, V

NTE30054, NTE30058, NTE30059 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4V

NTE30053, NTE30055, NTE30056, NTE30057 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5V

Continuous Forward Current, I

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25mA

Peak Forward Current (1.10 Duty Cycle, 0.1ms Pulse Width), I

NTE30053, NTE30055, NTE30056, NTE30057 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50mA

NTE30054, NTE30058, NTE30059 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100mA

Power Dissipation, P

NTE30053, NTE30055, NTE30056 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100mW

NTE30057 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110mW

NTE30054, NTE30058, NTE30059 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120mW

LED Junction Temperature, T

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . +100°C

Operating Temperature Range, T

opr

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

−25°C

to +85°C

Storage Temperature Range, T

stg

NTE30053, NTE30055, NTE30056 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

−25°C

to +100°C

NTE30054, NTE30057, NTE30058, NTE30059 . . . . . . . . . . . . . . . . . . . . . .

−40°C

to +100°C

Lead Temperature (During Soldering, .063 (1.6mm) from body, 5sec max), T

. . . . . . . . . . . +260°C

Electro−Optical Characteristics:

= +25°C unless otherwise specified)

Parameter

Forward Voltage

NTE30053

NTE30054

NTE30055

NTE30056

NTE30057

NTE30058

NTE30059

Symbol

Test Conditions

= 20mA

Min

−

Typ

2.2

3.5

2.0

1.86

3.5

Max

2.5

4.0

2.5

2.4

2.5

4.0

4.1

Unit
