LT1223CN8#TR

Description

Basic information of LT1223CN8#TR amplifier:

LT1223CN8#TR is an OPERATIONAL AMPLIFIER. The commonly used packaging method is DIP,

LT1223CN8#TR amplifier core information:

The minimum operating temperature of LT1223CN8#TR is and the maximum operating temperature is 70 °C. Its peak reflow temperature is NOT SPECIFIED Its maximum average bias current is 3 µA

How to simply check the efficiency of an amplifier? Looking at its slew rate, the nominal slew rate of LT1223CN8#TR is 1300 V/us. When the op amp is used in closed loop, at a certain closed-loop gain (usually 1 or 2, 10, etc.), the frequency when the LT1223CN8#TR gain becomes 0.707 times the low-frequency gain is 100000 kHz.

The nominal supply voltage of LT1223CN8#TR is 15 V, and its corresponding nominal negative supply voltage is -15 V. The input offset voltage of LT1223CN8#TR is 3000 µV (input offset voltage: the compensation voltage added between the two input terminals to make the output terminal of the operational amplifier 0V (or close to 0V).)

Related dimensions of LT1223CN8#TR:

The width of LT1223CN8#TR is: 7.62 mm and the length is 10.16 mm. LT1223CN8#TR has 8 terminals. Its terminal position type is: DUAL. Terminal pitch is 2.54 mm. Total pins: 8

LT1223CN8#TR amplifier other information:

Its temperature grade is: COMMERCIAL. LT1223CN8#TR is not Rohs certified. It contains lead. The corresponding JESD-30 code is: R-PDIP-T8. The corresponding JESD-609 code is: e0.

The packaging code of LT1223CN8#TR is: DIP. The materials of LT1223CN8#TR package are mostly PLASTIC/EPOXY. The package shape is RECTANGULAR. The LT1223CN8#TR package pin format is: IN-LINE. Its terminal form is: THROUGH-HOLE.

The maximum seat height is 3.937 mm.

CategoryAnalog mixed-signal IC    Amplifier circuit
File Size252KB,16 Pages
ManufacturerLinear ( ADI )
Websitehttp://www.analog.com/cn/index.html
Alternative parts:LT1223CN8#TR
Download Datasheet Parametric View All

LT1223CN8#TR Overview

Basic information of LT1223CN8#TR amplifier:

LT1223CN8#TR is an OPERATIONAL AMPLIFIER. The commonly used packaging method is DIP,

LT1223CN8#TR amplifier core information:

The minimum operating temperature of LT1223CN8#TR is and the maximum operating temperature is 70 °C. Its peak reflow temperature is NOT SPECIFIED Its maximum average bias current is 3 µA

How to simply check the efficiency of an amplifier? Looking at its slew rate, the nominal slew rate of LT1223CN8#TR is 1300 V/us. When the op amp is used in closed loop, at a certain closed-loop gain (usually 1 or 2, 10, etc.), the frequency when the LT1223CN8#TR gain becomes 0.707 times the low-frequency gain is 100000 kHz.

The nominal supply voltage of LT1223CN8#TR is 15 V, and its corresponding nominal negative supply voltage is -15 V. The input offset voltage of LT1223CN8#TR is 3000 µV (input offset voltage: the compensation voltage added between the two input terminals to make the output terminal of the operational amplifier 0V (or close to 0V).)

Related dimensions of LT1223CN8#TR:

The width of LT1223CN8#TR is: 7.62 mm and the length is 10.16 mm. LT1223CN8#TR has 8 terminals. Its terminal position type is: DUAL. Terminal pitch is 2.54 mm. Total pins: 8

LT1223CN8#TR amplifier other information:

Its temperature grade is: COMMERCIAL. LT1223CN8#TR is not Rohs certified. It contains lead. The corresponding JESD-30 code is: R-PDIP-T8. The corresponding JESD-609 code is: e0.

The packaging code of LT1223CN8#TR is: DIP. The materials of LT1223CN8#TR package are mostly PLASTIC/EPOXY. The package shape is RECTANGULAR. The LT1223CN8#TR package pin format is: IN-LINE. Its terminal form is: THROUGH-HOLE.

The maximum seat height is 3.937 mm.

LT1223CN8#TR Parametric

Parameter NameAttribute value
Is it lead-free?Contains lead
Is it Rohs certified?incompatible
MakerLinear ( ADI )
Parts packaging codeDIP
package instructionDIP,
Contacts8
Reach Compliance Codecompliant
ECCN codeEAR99
Is SamacsysN
Amplifier typeOPERATIONAL AMPLIFIER
Maximum average bias current (IIB)3 µA
Nominal Common Mode Rejection Ratio63 dB
Maximum input offset voltage3000 µV
JESD-30 codeR-PDIP-T8
JESD-609 codee0
length10.16 mm
Negative supply voltage upper limit-18 V
Nominal Negative Supply Voltage (Vsup)-15 V
Number of functions1
Number of terminals8
Maximum operating temperature70 °C
Minimum operating temperature
Package body materialPLASTIC/EPOXY
encapsulated codeDIP
Package shapeRECTANGULAR
Package formIN-LINE
Peak Reflow Temperature (Celsius)NOT SPECIFIED
Certification statusNot Qualified
Maximum seat height3.937 mm
Nominal slew rate1300 V/us
Supply voltage upper limit18 V
Nominal supply voltage (Vsup)15 V
surface mountNO
technologyBIPOLAR
Temperature levelCOMMERCIAL
Terminal surfaceTin/Lead (Sn/Pb)
Terminal formTHROUGH-HOLE
Terminal pitch2.54 mm
Terminal locationDUAL
Maximum time at peak reflow temperatureNOT SPECIFIED
Nominal Uniform Gain Bandwidth100000 kHz
width7.62 mm
Base Number Matches1
LT1223
100MHz Current
Feedback Amplifier
FEATURES
DESCRIPTIO
100MHz Bandwidth at A
V
= 1
1000V/µs Slew Rate
Wide Supply Range:
±5V
to
±15V
1mV Input Offset Voltage
1µA Input Bias Current
5MΩ Input Resistance
75ns Settling Time to 0.1%
50mA Output Current
6mA Quiescent Current
Available in 8-Lead Plastic DIP and SO Packages
The LT
®
1223 is a 100MHz current feedback amplifier with
very good DC characteristics. The LT1223’s high slew
rate, 1000V/µs, wide supply range,
±15V,
and large output
drive,
±50mA,
make it ideal for driving analog signals over
double-terminated cables. The current feedback amplifier
has high gain bandwidth at high gains, unlike conventional
op amps.
The LT1223 comes in the industry standard pinout and
can upgrade the performance of many older products.
The LT1223 is manufactured on Linear Technology’s
proprietary complementary bipolar process.
, LTC and LT are registered trademarks of Linear Technology Corporation.
All other trademarks are the property of their respective owners.
APPLICATIO S
Video Amplifiers
Buffers
IF and RF Amplification
Cable Drivers
8-, 10-, 12-Bit Data Acquisition Systems
TYPICAL APPLICATIO
Video Cable Driver
60
Voltage Gain vs Frequency
50
40
VOLTAGE GAIN (dB)
V
IN
+
LT1223
75
R
G
= 10
R
G
= 33
R
G
= 110
R
G
= 470
R
G
=
R
F
1k
75
CABLE
30
20
10
0
V
OUT
R
G
1k
75Ω
–10
–20
100k
1M
10M
FREQUENCY (Hz)
LT1223 • TPC01
R
A
V
= 1 +
F
R
G
AT AMPLIFIER OUTPUT
6dB LESS AT V
OUT
LT1223 • TA02
U
100MHz GAIN
BANDWIDTH
+
1k
R
G
U
U
100M
1G
1223fb
1
