1SV285
TOSHIBA Variable Capacitance Diode
Silicon Epitaxial Planar Type
1SV285
VCO for UHF Band Radio
•
•
•
High capacitance ratio: C
1 V
/C
4 V
= 2.3 (typ.)
Low series resistance: r
s
= 0.42
Ω
(typ.)
Useful for small size tuner.
Unit: mm
Absolute Maximum Ratings
(Ta
=
25°C)
Characteristics
Reverse voltage
Junction temperature
Storage temperature range
Symbol
V
R
T
j
T
stg
Rating
10
125
−55~125
Unit
V
°C
°C
Note: Using continuously under heavy loads (e.g. the application of high
temperature/current/voltage and the significant change in
temperature, etc.) may cause this product to decrease in the
reliability significantly even if the operating conditions (i.e.
operating temperature/current/voltage, etc.) are within the
absolute maximum ratings.
Please design the appropriate reliability upon reviewing the
Toshiba Semiconductor Reliability Handbook (“Handling
Precautions”/“Derating Concept and Methods”) and individual
reliability data (i.e. reliability test report and estimated failure rate,
etc).
JEDEC
JEITA
TOSHIBA
―
―
1-1G1A
Weight: 0.0014 g (typ.)
Electrical Characteristics
(Ta
=
25°C)
Characteristics
Reverse voltage
Reverse current
Capacitance
Capacitance
Capacitance ratio
Series resistance
Symbol
V
R
I
R
C
1 V
C
4 V
C
1 V
/C
4 V
r
s
I
R
=
1
μA
V
R
=
10 V
V
R
=
1 V, f
=
1 MHz
V
R
=
4 V, f
=
1 MHz
⎯
V
R
=
1 V, f
=
470 MHz
Test Condition
Min
10
⎯
4.0
1.85
2.0
⎯
Typ.
⎯
⎯
4.5
2.0
2.3
0.42
Max
⎯
3
4.9
2.35
⎯
0.55
Unit
V
nA
pF
pF
⎯
Ω
Marking
1
2007-11-01
1SV285
