FPC Connector Family
Product Dimensions
(Continued)
0.5 mm, FPC Connector,
SMT, Top Contact
Part Number
Lead Free
1470359
1734839
C
0.70
Typ.
[.028]
0.50
Typ.
[.020]
0.20
Typ.
[.008]
2.31
2 Plcs.
[.091]
1.75
Typ.
[.069]
2.05
[.081]
PCB Board
Material and Finish
Housing
— High temperature thermo-
plastic, UL 94V-O, natural color
Actuator
— Thermoplastic, UL 94V-O,
ivory color
Hold Down
— Phosphor bronze
Contact
— Phosphor bronze
4.40
[.173]
2.80
Typ.
[.110]
B
A
20°
Ref.
0.23
[.009]
Technical Documents
Product Specification
— 108-57238
2.00
[.079]
3.50
[.138]
2.00
[.079]
0.50
Typ.
[.020]
0.50
✕
(Pos. + 1)
[.020]
0.30
[.012]
Stiffener
Board
3.50
Min.
[.138]
4.50
Min.
[.177]
0.50
[.020]
0.35
[.014]
Typ.
Recommended FPC Layout
2.82
Typ.
[.111]
C
0.50
Typ.
[.020]
0.70
Typ.
[.028]
1.10
Typ.
[.043]
3.10
[.122]
0.30
[.012]
2.30
2 Plcs.
[.091]
Recommended PCB Layout
4
Catalog 1-1773440-6
Revised 05-06
www.tycoelectronics.com
Dimensions are in millimeters
and inches unless otherwise
specified. Values in brackets
are standard equivalents.
Dimensions are shown for
reference purposes only.
Specifications subject
to change.
USA: 1-800-522-6752
Canada: 1-905-470-4425
Mexico: 01-800-733-8926
C. America: 52-55-5-729-0425
South America: 55-11-3611-1514
Hong Kong: 852-2735-1628
Japan: 81-44-844-8013
UK: 44-141-810-8967
FPC Connector Family
Product Dimensions
(Continued)
0.5 mm, FPC Connector,
SMT, Top Contact
Part Number
Lead Free
1470359
1734839
Dimension
B
3.10
.122
3.60
.141
4.10
.161
4.60
.181
5.10
.200
5.60
.220
6.10
.240
6.60
.259
7.10
.279
7.60
.299
8.10
.318
8.60
.338
9.10
.358
9.60
.377
10.10
.397
10.60
.417
11.10
.437
11.60
.456
12.10
.476
12.60
.496
13.10
.515
13.60
.535
14.10
.555
Dimension
B
14.60
.574
15.10
.594
15.60
.614
16.10
.633
16.60
.653
17.10
.673
17.60
.692
18.10
.712
18.60
.732
19.10
.751
19.60
.771
20.10
.791
20.60
.811
21.10
.830
21.60
.850
22.10
.870
22.60
.890
23.10
.909
23.60
.929
24.10
.949
24.60
.968
25.10
.988
25.60
1.008
Part Number
1470359-5
1470359-6
1470359-7
1470359-8
1470359-9
1-1470359-0
1-1470359-1
1-1470359-2
1-1470359-3
1-1470359-4
1-1470359-5
1-1470359-6
1-1470359-7
1-1470359-8
1-1470359-9
2-1470359-0
2-1470359-1
2-1470359-2
2-1470359-3
2-1470359-4
2-1470359-5
2-1470359-6
2-1470359-7
Position
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
A
7.93
.312
8.43
.331
8.93
.351
9.43
.371
9.93
.390
10.43
.410
10.93
.430
11.43
.450
11.93
.469
12.43
.489
12.93
.509
13.43
.528
13.93
.548
14.43
.568
14.93
.587
15.43
.607
15.93
.627
16.43
.646
16.93
.666
17.43
.686
17.93
.705
18.43
.725
18.93
.745
C
2.00
.078
2.50
.098
3.00
.118
3.50
.137
4.00
.157
4.50
.177
5.00
.196
5.50
.216
6.00
.236
6.50
.255
7.00
.275
7.50
.295
8.00
.314
8.50
.334
9.00
.354
9.50
.374
10.00
.393
10.50
.413
11.00
.433
11.50
.452
12.00
.472
12.50
.492
13.00
.511
Part Number
2-1470359-8
2-1470359-9
3-1470359-0
3-1470359-1
3-1470359-2
3-1470359-3
3-1470359-4
3-1470359-5
3-1470359-6
3-1470359-7
3-1470359-8
3-1470359-9
4-1470359-0
4-1470359-1
4-1470359-2
4-1470359-3
4-1470359-4
4-1470359-5
4-1470359-6
4-1470359-7
4-1470359-8
4-1470359-9
5-1470359-0
Position
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
A
19.43
.764
19.93
.784
20.43
.804
20.93
.824
21.43
.843
21.93
.863
22.43
.883
22.93
.902
23.43
.922
23.93
.942
24.43
.961
24.93
.981
25.43
1.001
25.93
1.020
26.43
1.040
26.93
1.060
27.43
1.079
27.93
1.099
28.43
1.119
28.93
1.138
29.43
1.158
29.93
1.178
30.43
1.198
C
13.50
.531
14.00
.551
14.50
.570
15.00
.590
15.50
.610
16.00
.629
16.50
.649
17.00
.669
17.50
.688
18.00
.708
18.50
.728
19.00
.748
19.50
.767
20.00
.787
20.50
.807
21.00
.826
21.50
.846
22.00
.866
22.50
.885
23.00
.905
23.50
.925
24.00
.944
24.50
.964
5
Catalog 1-1773440-6
Revised 05-06
www.tycoelectronics.com
Dimensions are in millimeters
and inches unless otherwise
specified. Values in brackets
are standard equivalents.
Dimensions are shown for
reference purposes only.
Specifications subject
to change.
USA: 1-800-522-6752
Canada: 1-905-470-4425
Mexico: 01-800-733-8926
C. America: 52-55-5-729-0425
South America: 55-11-3611-1514
Hong Kong: 852-2735-1628
Japan: 81-44-844-8013
UK: 44-141-810-8967
