L50/L51 T1 3/4
—
RoHS Compliant
Front Mount LED Indicator
Special Features
• Front mounting, snap-in—no mounting hardware required
• Simplified one-piece construction
• Fits panel thickness from ,031˝ (.787) to .062˝ (1.574)
Specifications
• Mounting hole: .250˝ (6.35)
• Termination: 22 AWG 6˝ gray (anode) and black (cathode) leads
stripped to 1/4˝ standard; optional bi-pin available
• Custom lead lengths and colors available
• Body material: Black PP
5mm Panel Mount LED Assemblies
Electrical and Optical Characteristics (TA=25°C)
LED
Part#
Color
Luminous
Intensity (mcd)
Typ.@IF(mA)
VF Typ.@IF (mA)
Viewing
Angle
2Θ
2
Peak
More
Wavelength LED Data
(mm)
Page#
Package Dimensions
L50
.281 DIA.
(7.14)
.625 MAX.
(15.88)
.210 MAX.
(5.33)
.020 SQ.
(0.50)
.125
(3.18)
CATHODE LEAD
.050 REF.
(1.27)
.300 MIN.
(7.62)
HIGH EFFICIENCY
9102
9103
9104
9105
Red
Green
Yellow
Orange
5.6
5.6
5.6
5.6
10
10
10
10
2.0
2.2
2.1
2.0
20
20
20
20
60°
60°
60°
60°
635
565
585
630
24
24
24
24
LOW CURRENT
9121
9122
9123
Red
Yellow
Green
2.5
1.6
1.6
2
2
2
1.7
1.9
1.8
2
2
2
60°
60°
60°
625
590
565
25
25
25
L51
.281 DIA.
(7.14)
.625 MAX.
(15.88)
.210 MAX.
(5.33)
6.00 TYP
(152.40)
.250
(6.3)
5V INTERNAL RESISTOR
9124
9125
9126
Red
Yellow
Green
16.0
16.0
16.0
12
12
12
5.0
5.0
5.0
12
12
12
60°
60°
60°
625
565
590
26
26
26
BICOLOR
9109
9128
Red
Green
Yellow
Green
38.0
13.0
10.0
20.0
20
20
20
20
2.0
2.2
2.1
2.2
20
20
20
20
60°
60°
660
565
590
565
27
27
All Dimensions are in inches (mm)
.125
(3.18)
ULTRA BRIGHT
9129
9130
9131
Red
Green
Yellow
80.0
50.0
80.0
10
10
10
2.0
2.2
2.1
10
10
10
30°
30°
30°
625
565
590
24
24
24
How To Order
LED Series
SUPER ULTRA BRIGHT
9132
9133
Red
Green
1500.0
250.0
20
20
1.85
2.2
20
20
30°
30°
660
565
29
29
L 5 x — x x x x
Bipins = 0
Leads = 1
See LED Chart
®
WILBRECHT
ELECTRONICS, INC.
LEDCO
DIVISION
14
1400 Energy Park Drive, Suite 18 • St. Paul, MN 55108-5248 • (651) 659-0919 • Toll free (888) 323-8751 • FAX (651) 659-9204 • www.wilbrecht.com
