1-213806-4 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The connector> The connector> 1-213806-4

1-213806-4: Description20 CONTACT(S), FEMALE, RIGHT ANGLE TELECOM AND DATACOM CONNECTOR, SOLDER, SOCKET; CategoryThe connector The connector; File Size140KB，2 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com; Environmental Compliance

Download Datasheet Parametric Compare View All

1-213806-4 Overview

20 CONTACT(S), FEMALE, RIGHT ANGLE TELECOM AND DATACOM CONNECTOR, SOLDER, SOCKET

1-213806-4 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Objectid	2131577437
Reach Compliance Code	unknown
YTEOL	0
Body/casing type	SOCKET
Connector type	TELECOM AND DATACOM CONNECTOR
Contact to complete cooperation	NOT SPECIFIED
Contact point gender	FEMALE
Contact material	NOT SPECIFIED
DIN compliance	NO
empty shell	NO
Filter function	NO
IEC compliance	NO
MIL compliance	NO
Mixed contacts	NO
Installation method	RIGHT ANGLE
Installation type	BOARD
Options	GENERAL PURPOSE
Shell surface	TIN
Shell material	BRASS
Termination type	SOLDER
Total number of contacts	20

Preview

Download Datasheet

View All

1-213806-4 Related Products

	1-213806-4	183-2-080-1-T-BS0-1940	185-1-027-0-NTX-BR1	185-2-014-0-NTX-BT0	1-213806-5	185-2-039-0-NTX-BT0	1-213806-7
Description	20 CONTACT(S), FEMALE, RIGHT ANGLE TELECOM AND DATACOM CONNECTOR, SOLDER, SOCKET	Board Connector, 80 Contact(s), 2 Row(s), Male, Straight, 0.05 inch Pitch, Surface Mount Terminal, Locking	Board Connector, 27 Contact(s), 1 Row(s), Female, Straight, 0.05 inch Pitch, Surface Mount Terminal, Locking	Board Connector, 14 Contact(s), 1 Row(s), Female, Straight, 0.05 inch Pitch, Surface Mount Terminal, Locking	22 CONTACT(S), FEMALE, RIGHT ANGLE TELECOM AND DATACOM CONNECTOR, SOLDER, SOCKET	Board Connector, 39 Contact(s), 1 Row(s), Female, Straight, 0.05 inch Pitch, Surface Mount Terminal, Locking	22 CONTACT(S), FEMALE, RIGHT ANGLE TELECOM AND DATACOM CONNECTOR, SOLDER, SOCKET
Reach Compliance Code	unknown	compliant	compliant	compliant	unknown	compliant	unknown
Connector type	TELECOM AND DATACOM CONNECTOR	BOARD CONNECTOR	BOARD CONNECTOR	BOARD CONNECTOR	TELECOM AND DATACOM CONNECTOR	BOARD CONNECTOR	TELECOM AND DATACOM CONNECTOR
Contact to complete cooperation	NOT SPECIFIED	SN	SN	SN	NOT SPECIFIED	SN	NOT SPECIFIED
Contact point gender	FEMALE	MALE	FEMALE	FEMALE	FEMALE	FEMALE	FEMALE
Contact material	NOT SPECIFIED	COPPER ALLOY	PHOSPHOR BRONZE	PHOSPHOR BRONZE	NOT SPECIFIED	PHOSPHOR BRONZE	NOT SPECIFIED
Installation method	RIGHT ANGLE	STRAIGHT	STRAIGHT	STRAIGHT	RIGHT ANGLE	STRAIGHT	RIGHT ANGLE
Installation type	BOARD	BOARD	BOARD	BOARD	BOARD	BOARD	BOARD
Termination type	SOLDER	SURFACE MOUNT	SURFACE MOUNT	SURFACE MOUNT	SOLDER	SURFACE MOUNT	SOLDER
Total number of contacts	20	80	27	14	22	39	22
Objectid	2131577437	309001718	309002935	309003496	-	309003896	2131577440
ECCN code	-	EAR99	EAR99	EAR99	-	EAR99	-
body width	-	0.222 inch	0.098 inch	0.098 inch	-	0.098 inch	-
subject depth	-	0.764 inch	0.236 inch	0.236 inch	-	0.236 inch	-
body length	-	2.126 inch	1.366 inch	0.716 inch	-	1.966 inch	-
contact mode	-	RECTANGULAR	RECTANGULAR	RECTANGULAR	-	RECTANGULAR	-
Contact style	-	SQ PIN-SKT	SQ PIN-SKT	SQ PIN-SKT	-	SQ PIN-SKT	-
Dielectric withstand voltage	-	424VAC V	424VAC V	424VAC V	-	424VAC V	-
insulator material	-	THERMOPLASTIC	THERMOPLASTIC	THERMOPLASTIC	-	THERMOPLASTIC	-
Manufacturer's serial number	-	183	185	185	213806	185	-
Plug contact pitch	-	0.05 inch	0.05 inch	0.05 inch	-	0.05 inch	-
Installation option 1	-	LOCKING	LOCKING	LOCKING	-	LOCKING	-
Number of connectors	-	ONE	ONE	ONE	-	ONE	-
PCB row number	-	2	2	2	-	2	-
Number of rows loaded	-	2	1	1	-	1	-
Maximum operating temperature	-	105 °C	105 °C	105 °C	-	105 °C	-
Minimum operating temperature	-	-40 °C	-40 °C	-40 °C	-	-40 °C	-
PCB contact pattern	-	RECTANGULAR	STAGGERED	STAGGERED	-	STAGGERED	-
PCB contact row spacing	-	4.3942 mm	3.2258 mm	3.2258 mm	-	3.2258 mm	-
polarization key	-	POLARIZED HOUSING	POLARIZED HOUSING	POLARIZED HOUSING	-	POLARIZED HOUSING	-
Rated current (signal)	-	1 A	1 A	1 A	-	1 A	-
Guideline	-	UL	UL	UL	-	UL	-
reliability	-	COMMERCIAL	COMMERCIAL	COMMERCIAL	-	COMMERCIAL	-
Terminal pitch	-	1.27 mm	2.54 mm	2.54 mm	-	2.54 mm	-
