1-382804-8: DescriptionHEADER,JUMPER/SHUNT,36 CONTACTS,SKT,0.1 PITCH,BLACK; CategoryThe connector The connector; File Size103KB，1 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com

Download Datasheet Parametric View All

1-382804-8 Overview

HEADER,JUMPER/SHUNT,36 CONTACTS,SKT,0.1 PITCH,BLACK

1-382804-8 Parametric

Parameter Name	Attribute value
Objectid	301995861
Reach Compliance Code	unknown
ECCN code	EAR99
body width	0.2 inch
subject depth	0.25 inch
body length	1.796 inch
Body/casing type	PLUG
Connector type	SHUNTS / JUMPER CONNECTOR
Contact to complete cooperation	AU ON NI
Contact point gender	FEMALE
Contact material	PHOSPHOR BRONZE
contact mode	RECTANGULAR
Contact style	SQ PIN-SKT
Dielectric withstand voltage	1000VAC V
Insulator color	BLACK
insulator material	GLASS FILLED THERMOPLASTIC
Manufacturer's serial number	382804
Plug contact pitch	0.1 inch
Match contact row spacing	0.1 inch
Installation method	STRAIGHT
Number of connectors	ONE
Number of rows loaded	2
Maximum operating temperature	105 °C
Minimum operating temperature	-55 °C
Plating thickness	15u inch
Rated current (signal)	2.5 A
Guideline	UL, CSA
reliability	COMMERCIAL
Total number of contacts	36

Preview

Download Datasheet

View All

C orporate Hom e

Electronic Components

Se gm e nts

W ho W e Are

My Account

Searc h

Products

Documentation

Resources

My Account

Customer Support

Home

Products

By Type

PC B C onnectors

Product Feature Selector

> Product Details

1-382804-8 Product Details

Live Product Chat

Product Photo

Post Shunts

Not re vie we d for R oHS C om plia nce

Quick Links

C heck Pricing & Availability

Search for Tooling

Product Feature Selector

C ontact Us About This Product

1-382804-8

T E I nternal N umber: 1 - 3 8 2 8 0 4 - 8

Product Highlights:

Shunt Type = Multiposition

2.54 mm C enterline

Gold (15) C ontact Mating Area Plating Material

Grid Size = 2x18

Without Handle

View all Features

Obsolete

C ontact Product Information C enter

A dd to M y P art L is t

Reques t Sample

Find Similar P roduc ts

Buy P roduc t

Documentation & Additional Information

Product Drawings:

None Available

Catalog Pages/Data Sheets:

None Available

Product Specifications:

None Available

Application Specifications:

None Available

Instruction Sheets:

Multiposition Shunt C onnectors 390102 and 382909

(PDF, English)

CAD Files:

None Available

List all Documents

Product Features

(Please use the Product Drawing for all design activity)

Product Type Features:

Shunt Type

= Multiposition

Grid Size

= 2x18

Profile = Low

C SA C ertified = Yes

Termination Related Features:

Height (mm [in]) = 6.35 [0.250]

Body Related Features:

C enterline (mm [in])

= 2.54 [0.100]

Handle = Without

UL Rating = Recognized

Contact Related Features:

C ontact Mating Area Plating Material = Gold (15)

C ontact Base Material = Phosphor Bronze

Housing Related Features:

Housing C olor = Black

Housing Material = Thermoplastic Glass Reinforced

Housing Flammability Rating = UL 94V-0

Industry Standards:

RoHS/ELV C ompliance

= Not reviewed for ELV/RoHS compliance

Lead Free Solder Processes

= Not reviewed for lead free solder

process

Other:

Brand = AMP

Additional Information:
