5150500328 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Passive components> The resistor> 5150500328

5150500328: DescriptionRESISTOR, POTENTIOMETER, CARBON FILM, 1 TURN(S), 0.1W, 22000ohm, ROHS COMPLIANT; CategoryPassive components The resistor; File Size100KB，1 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com; Environmental Compliance

Download Datasheet Parametric View All

5150500328 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	5150500328	-	-	View	Buy Now

5150500328 Overview

RESISTOR, POTENTIOMETER, CARBON FILM, 1 TURN(S), 0.1W, 22000ohm, ROHS COMPLIANT

5150500328 Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	TE Connectivity
package instruction	ROHS COMPLIANT
Reach Compliance Code	compliant
ECCN code	EAR99
Is Samacsys	N
Actuator direction	VERTICAL
Actuator type	THUMB WHEEL
gang number	1
Installation features	THROUGH HOLE MOUNT
Number of terminals	3
number of turns	1
Package shape	RECTANGULAR PACKAGE
Rated power dissipation(P)	0.1 W
resistance	22000 Ω
resistance law	LINEAR
Resistor type	POTENTIOMETER
surface mount	NO
technology	CARBON FILM
Terminal shape	FLAT
Tolerance	20%
Base Number Matches	1

Preview

Download Datasheet

View All

C orporate Hom e

Electronic Components

Se gm e nts

W ho W e Are

My Account

Searc h

Products

Documentation

Resources

My Account

Customer Support

Home

Products

By Type

Resistors

Product Feature Selector

> Product Details

5150500328 Product Details

Live Product Chat

Variable Resistors

Always EU R oHS/ELV C om plia nt

(

Sta te m e nt of C om plia nce

)

Quick Links

C heck Pricing & Availability

Search for Tooling

Product Feature Selector

C ontact Us About This Product

5150500328

(1-1624191-2)

T E I nternal N umber: 1 - 1 6 2 4 1 9 1 - 2

Product Highlights:

Variable Resistor

Resistor Type = Potentiometer

Resistance Selection = K ?

Resistance = 22K ?

Power Rating = .10 W

View all Features

A dd to M y P art L is t

Reques t Sample

Find Similar P roduc ts

Active

Buy P roduc t

Documentation & Additional Information

Product Drawings:

None Available

Catalog Pages/Data Sheets:

Spindle Operated Potentiometers - Type 51 Series - T...

(PDF, English)

Product Specifications:

None Available

Application Specifications:

None Available

Instruction Sheets:

None Available

CAD Files:

None Available

List all Documents

Product Features

(Please use the Product Drawing for all design activity)

Product Type Features:

Product Type = Variable Resistor

Resistor Type

= Potentiometer

Resistance (?)

= 22K

Element

= C arbon

Sealed

= No

Mount Angle

= Horizontal

Termination Type

= PC B Terminations

C omment = Suited for Plugin Accessory

Electrical Characteristics:

Resistance Selection (?) = K

Power Rating (W)

= 0.10

Tolerance (%)

= 20

Termination Related Features:

Termination Post Orientation

= In Line

Body Related Features:

Series

= 51

Package, C omponent Size

= 12.5 x 15.8

Configuration Related Features:

Sections

= Single

Adjustment Location

= Top

Adjustment Style

= Spindle (Sold Separately)

Operating Function

= Single Turn

Industry Standards:

RoHS/ELV C ompliance

= RoHS compliant, ELV compliant

Lead Free Solder Processes

= Wave solder capable to 240?C , Wave

solder capable to 260?C , Wave solder capable to 265?C

RoHS/ELV C ompliance History = Always was RoHS compliant

Conditions for Usage:

Temperature C oefficient (ppm/?C )

= 500

Other:

Brand = C itec

Additional Information:

Product Line Information
