3-1470209-4

Description
50 CONTACT(S), FEMALE, STRAIGHT TWO PART BOARD CONNECTOR, SOLDER, RECEPTACLE
CategoryThe connector    The connector
File Size103KB,1 Pages
ManufacturerTE Connectivity
Websitehttp://www.te.com
Environmental Compliance
Download Datasheet Parametric View All

3-1470209-4 Online Shopping

Suppliers Part Number Price MOQ In stock
3-1470209-4 - - View Buy Now

3-1470209-4 Overview

50 CONTACT(S), FEMALE, STRAIGHT TWO PART BOARD CONNECTOR, SOLDER, RECEPTACLE

3-1470209-4 Parametric

Parameter NameAttribute value
Is it lead-free?Lead free
Is it Rohs certified?conform to
Objectid2072643454
Reach Compliance Codeunknown
Body/casing typeRECEPTACLE
Connector typeBOARD CONNECTOR
Contact to complete cooperationGOLD (30) OVER NICKEL (50)
Contact completed and terminatedTIN OVER NICKEL
Contact point genderFEMALE
Contact materialNOT SPECIFIED
DIN complianceNO
Filter functionNO
IEC complianceNO
JESD-609 codee3
MIL complianceNO
Manufacturer's serial number1470209
Mixed contactsNO
Installation methodSTRAIGHT
Installation typeBOARD
Number of rows loaded2
OptionsGENERAL PURPOSE
Terminal pitch2 mm
Termination typeSOLDER
Total number of contacts50
UL Flammability Code94V-0
C orporate Hom e
|
Electronic Components
|
Se gm e nts
|
W ho W e Are
My Account
Searc h
Products
Documentation
Resources
My Account
Customer Support
Home
>
Products
>
By Type
>
PC B C onnectors
>
Product Feature Selector
> Product Details
3-1470209-4 Product Details
Live Product Chat
Product Photo
2mm AMPMODU
Always EU R oHS/ELV C om pliant
(
Sta te m e nt of C om pliance
)
Quick Links
C heck Pricing & Availability
Search for Tooling
View Mating Products (12)
Product Feature Selector
C ontact Us About This Product
3-1470209-4
T E I nternal N umber: 3 - 1 4 7 0 2 0 9 - 4
Product Highlights:
l
Receptacle
l
PC B Mount Style = Through Hole
l
Not Shrouded
l
Number of Positions = 22
l
No PC B Retention Feature
View all Features
Pending Obsolescence
C ontact Product Information C enter
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Buy P roduc t
Documentation & Additional Information
Product Drawings:
l
AMPMODU 2.0MM PITC H REC C ONN, VERTIC AL MOUNT TYPE.
(PDF, English)
Catalog Pages/Data Sheets:
l
AMPMODU_INTERC ONNEC TION_SYSTEM_SEC TION3AND4
(PDF, English)
Product Specifications:
l
AMPMODU 2.0MM PITC H BOARD TO BOARD C ONNEC TOR.
(PDF, English)
Application Specifications:
l
None Available
Instruction Sheets:
l
None Available
CAD Files:
l
None Available
List all Documents
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Product Type
= Receptacle
l
PC B Mount Style
= Through Hole
l
Shrouded
= No
l
Number of Positions
= 22
l
PC B Retention Feature = No
l
PC B Mount Angle
= Vertical
l
Keyed
= No
l
Holddown Feature
= Without
l
PC B Thickness (mm [in]) = 1.57 [0.062]
l
Post Size (mm [in]) = 0.50 [.020]
Electrical Characteristics:
l
Voltage (VAC ) = 200
l
C ontact C urrent Rating (Amps.) = 1
l
Insulation Resistance (M?) = 1,000
Termination Related Features:
l
Termination Post Length (mm [in]) = 2.60 [0.102]
l
Solder Tail C ontact Plating = Tin (80) over Nickel (50)
Body Related Features:
l
Selectively Loaded
= No
l
Post Number(s) Omitted
= None
l
C enterline, Matrix (mm [in]) = 2.00 x 2.00 [.079 x .079]
l
Mount Type = Printed C ircuit Board
l
Number of Rows = Dual
l
C over = Without
l
UL Rating = UL 94V-0
Contact Related Features:
l
C ontact Mating Area Plating Material
= Gold (8)
l
C ontact Base Material = C opper Alloy
l
Approved Standards = UL E28476, C SA LR7189
Housing Related Features:
l
Housing Material = High Temperature Thermoplastic
l
Dielectric Strength (VAC ) = 650
l
Housing Flammability Rating = UL 94V-0
l
Housing C olor = Black
l
Housing Entry Style = C losed Top
Configuration Related Features:
l
Stack Height (mm [in]) = 4.50 [0.177]
Industry Standards:
l
RoHS/ELV C ompliance
= RoHS compliant, ELV compliant
l
Lead Free Solder Processes
= Wave solder capable to 240?C
l
RoHS/ELV C ompliance History = Always was RoHS compliant
Conditions for Usage:
l
Temperature Range (?C ) = -40 – +105
Packaging Related Features:
l
Packaging Method
= Tray
Other:
l
Brand = AMP
Additional Information:
l
Product Line Information
Related Products:
l
Tooling
l
Mating Products (12)
Provide Website Feedback
|
Need Help?
Home
|
C ustomer Support
|
Suppliers
|
Site Map
|
Privacy Policy
|
Browser Support
©
2009 Tyco Electronics C orporation All Rights Reserved
