3-1734279-3: Description37 CONTACT(S), MALE-MALE, D SUBMINIATURE CONNECTOR, SOLDER, PLUG, ROHS COMPLIANT; CategoryThe connector The connector; File Size2MB，37 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com

Download Datasheet Parametric Compare View All

3-1734279-3 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	3-1734279-3	-	-	View	Buy Now

3-1734279-3 Overview

37 CONTACT(S), MALE-MALE, D SUBMINIATURE CONNECTOR, SOLDER, PLUG, ROHS COMPLIANT

3-1734279-3 Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	incompatible
Maker	TE Connectivity
package instruction	ROHS COMPLIANT
Reach Compliance Code	compliant
ECCN code	EAR99
Is Samacsys	N
Other features	AMPLIMITE, OTHER STACKING CONNECTOR: 37 CONTACTS; 4/C SHELL SIZE
body width	1.244 inch
subject depth	0.774 inch
body length	2.73 inch
Body/casing type	PLUG
Connector type	D SUBMINIATURE CONNECTOR
Contact to complete cooperation	NOT SPECIFIED
Contact point gender	MALE-MALE
Contact material	NOT SPECIFIED
contact mode	STAGGERED
Contact resistance	40 mΩ
Contact style	RND PIN-SKT
DIN compliance	NO
Dielectric withstand voltage	700VAC V
empty shell	NO
Filter function	NO
IEC compliance	NO
maximum insertion force	3.336 N
Insulation resistance	1000000000 Ω
Insulator color	BLACK
insulator material	POLYETHYLENE
MIL compliance	NO
Manufacturer's serial number	1734279
Plug contact pitch	0.109 inch
Plug information	MULTIPLE MATING PARTS AVAILABLE
Mixed contacts	NO
Installation option 1	#4-40
Installation option 2	THREADED INSERT
Installation method	RIGHT ANGLE
Installation type	BOARD AND PANEL
PCB row number	2+2
Number of rows loaded	2+2
Maximum operating temperature	105 °C
Minimum operating temperature	-55 °C
Options	GENERAL PURPOSE
PCB contact pattern	STAGGERED
PCB contact row spacing	4.064 mm
Plating thickness	30u inch
Rated current (signal)	3 A
Guideline	UL
reliability	COMMERCIAL
Shell surface	TIN
Shell material	STEEL
Housing size	4/C
Terminal length	0.125 inch
Terminal pitch	2.7686 mm
Termination type	SOLDER
Total number of contacts	37
UL Flammability Code	94V-0
Evacuation force-minimum value	.2085 N
Base Number Matches	1

Preview

Download Datasheet

View All

AMPLIMITE Subminiature D Connectors

Right-Angle Posted Connectors

Connector

Density

Type

Style and

Shell Finish

Front

Metal-Shell,

Tin Plated

(Pg. 52)

Full

Metal-Shell

With and Without

Grounding Indents,

Tin Plated

(Pgs. 71, 139, 155)

Front

Metal-Shell

With Grounding

Indents,

Tin Plated

(Pgs. 55-58,

60-63, 65-67, 131,

134, 138, 143, 150)

No. of

Contact

Positions

Footprint

Mating

Hardware

Threaded

Inserts

Board

Mounting

HD-22

Plug

and

Receptacle

.350

[8.89]

Boardlocks

Female

Screwlocks

Standard

Screws

Female

Screwlocks

.120

[3.05]

Dia. Holes

Threaded

Inserts

Female

Screwlocks

.125

[3.18]

Dia. Holes

.120

[3.05]

Dia. Holes

Threaded

Inserts

Female

Screwlocks

.125

[3.18]

Dia. Holes

.120

[3.05]

Dia. Elliptical

Holes

Boardlocks

.125

[3.18]

Dia. Holes

Boardlocks

.120

[3.05]

Dia. Holes

Contact Plating

(Mating Area/

Solder Tails)

Duplex

(0.000030 [0.00076]

Gold/Tin)

Duplex

(Gold Flash/Tin)

Duplex

(.000030 [0.00076]

Gold/Tin)

Duplex

(Gold Flash/Tin)

Duplex

(.000030 [0.00076]

Gold/Tin)

Duplex

(Gold Flash/Tin)

Post

Length

.125

[3.18]

.454

[11.53]

.545

[13.84]

.318

[8.08]

.478

[12.14]

.590

[14.99]

.125

[3.18]

.220

[5.59]

HD-20

Plugs

and

Receptacles

.125

[3.18]

All-Plastic

(Pgs. 68-70, 132,

133, 135, 136)

.318

[8.08]

.590

[14.99]

Duplex

(.000030 [0.00076]

Gold/Tin)

Duplex

(Gold Flash/Tin)

.125

[3.18]

Catalog 82068

Revised 1-08

www.tycoelectronics.com

Dimensions are in inches and

millimeters unless otherwise

specified. Values in brackets

are metric equivalents.

Dimensions are shown for

reference purposes only.

Specifications subject

to change.

USA: 1-800-522-6752

Canada: 1-905-470-4425

Mexico: 01-800-733-8926

C. America: 52-55-1106-0803

South America: 55-11-2103-6000

Hong Kong: 852-2735-1628

Japan: 81-44-844-8013

UK: 44-8706-080-208
