175487-6

Description
HEADER CONNECTOR,PCB MNT,RECEPT,6 CONTACTS,PIN,0.079 PITCH,PC TAIL W/RETNN TERMINAL,NATURAL
CategoryThe connector    The connector
File Size104KB，1 Pages
ManufacturerTE Connectivity
Websitehttp://www.te.com
Download Datasheet Parametric View All

175487-6 Online Shopping

Suppliers Part Number Price MOQ In stock
175487-6 - - View Buy Now

175487-6 Overview

HEADER CONNECTOR,PCB MNT,RECEPT,6 CONTACTS,PIN,0.079 PITCH,PC TAIL W/RETNN TERMINAL,NATURAL

175487-6 Parametric

Parameter NameAttribute value
Is it Rohs certified?incompatible
MakerTE Connectivity
Reach Compliance Codecompliant
ECCN codeEAR99
Is SamacsysN
Other featuresPACKAGING 500 PER BOX
body width0.228 inch
subject depth0.268 inch
body length0.543 inch
Body/casing typeRECEPTACLE
Connector typeBOARD CONNECTOR
Contact to complete cooperationSN-PB ON CU
Contact completed and terminatedTIN/LEAD OVER COPPER
Contact point genderMALE
Contact materialBRASS
contact modeRECTANGULAR
Contact resistance20 mΩ
Contact styleRND PIN-SKT
Dielectric withstand voltage1000VAC V
maximum insertion force48.928 N
Insulation resistance500000000 Ω
Insulator colorNATURAL
insulator materialNYLON
Manufacturer's serial number175487
Plug contact pitch0.079 inch
Installation methodSTRAIGHT
Installation typeBOARD
Number of connectorsONE
PCB row number1
Number of rows loaded1
Maximum operating temperature105 °C
Minimum operating temperature-30 °C
PCB contact patternRECTANGULAR
Plating thickness31u inch
polarization keyPOLARIZED HOUSING
Rated current (signal)2 A
GuidelineUL, CSA
reliabilityCOMMERCIAL
Terminal length0.126 inch
Terminal pitch2.0066 mm
Termination typeSOLDER KINKED LEADS
Total number of contacts6
Evacuation force-minimum value6.672 N
Base Number Matches1

Preview

Download Datasheet
C orporate Hom e
|
Electronic Components
|
Se gm e nts
|
W ho W e Are
My Account
Searc h
Products
Documentation
Resources
My Account
Customer Support
Home
>
Products
>
By Type
>
Discrete Wire C onnectors - IDC
>
Product Feature Selector
> Product Details
175487-6 Product Details
Live Product Chat
Product Photo
2mm AMP CT Connectors
Not EU R oHS or ELV C om plia nt
(
Find R oHS C om plia nt Alte rna te s
)
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
175487-6
T E I nternal N umber: 1 7 5 4 8 7 - 6
Product Highlights:
l
C onnector
l
C onnector Type = MT (Mass Termination)
l
Mating Type = Header
l
Number of Positions = 6
l
Number of Rows = 1
View all Features
Superseded
Search for Replacement Parts
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Buy P roduc t
Documentation & Additional Information
Product Drawings:
l
POST HEADER ASS'Y (BOX-V TYPE) (AMP C T C ONNEC TOR 2mm...
(PDF, English)
Catalog Pages/Data Sheets:
l
PERSONAL SYSTEMS PRODUC TS
(PDF, English)
Product Specifications:
l
AMP C ommon Termination (C T), C onn, 2mm Pitch, M/T Type
(PDF, English)
l
AMP C ommon Termination(C T), C onnector, 2mm Pitch, C r...
(PDF, English)
Application Specifications:
l
None Available
Instruction Sheets:
l
None Available
CAD Files:
l
None Available
List all Documents
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Product Type
= C onnector
l
C onnector Type
= MT (Mass Termination)
l
Mating Type
= Header
l
Number of Positions
= 6
l
PC B Mount Style
= Through Hole
l
PC B Mount Angle
= Vertical
l
PC B Mount Polarization
= No
l
PC B Retention Feature
= Yes
Mechanical Attachment:
l
Panel Attachment
= Without
Termination Related Features:
l
Solder Tail C ontact Plating = Pre-tinned
Body Related Features:
l
Number of Rows
= 1
l
Header Body Style
= Box
l
PC B Retention Method
= Retention Solder Tails
l
C enterline (mm [in]) = 2.00 [0.079]
Contact Related Features:
l
C ontact Base Material = Brass
l
C ontact Mating Area Plating Material = Pre-Tin
Housing Related Features:
l
Housing Material
= Nylon
l
Housing C olor
= Natural
l
Housing Flammability Rating = UL 94V-0
Industry Standards:
l
RoHS/ELV C ompliance
= Not ELV/RoHS compliant
l
Lead Free Solder Processes
= Not suitable for lead free processing
Conditions for Usage:
l
Terminate To
= Printed C ircuit Board
Other:
l
Brand = AMP
Additional Information:
l
Product Line Information
Related Products:
l
Tooling
