Restricted to: General Release
£ ¡ § ¥ £ ¡
¢¨¢¦¤¢
L
0.11-0.17
0.25m Max
B
C
2 Places
C
Label 1
Label 2
A
0.019m max
!
©
Connector(s): MT-RJ (No Pins)
Mode: MM
Housing Color: Black
Geom. Spec: 115-1215
A
Connector(s): ST
Fiber A
Fiber B
Notes:
1 IL tested at 1300nm.
2 Product and Processing must meet requirements of Tyco Electronics
Standard 230-702
3 Label 2 will not be present on any cable assembly less than 5 meters long.
4 Includes dust caps (not shown on print).
-
-
B
A
Mode: MM
Housing Color: N/A
Geom. Spec: N/A
B
VIEW C-C
NOT T O SCALE
Cable Assy Configurator
meters
!
# "
-
-
Tyco Electronics, Inc.
Harrisburg, PA 17105-3608
Michael Kepko
-
-
-
-
-
Michael Kepko
CE
B
Rev Per EC#
06-022379
9/27/2006
-
MK
FO C/A - 2 fiber, 62.5/125, OFNR (Riser) jacket, MT-RJ (No Pins)
to ST
16
CAC Customer Layout Rev: D
Customer Print
NTS
A2
C- 6278027
1 of 2
B
Restricted to: General Release
MT-RJ (No Pins), Black
Part #
0-6278027-1
0-6278027-2
0-6278027-3
0-6278027-4
0-6278027-5
0-6278027-6
0-6278027-7
0-6278027-8
0-6278027-9
1-6278027-0
1-6278027-1
1-6278027-2
1-6278027-3
1-6278027-4
1-6278027-5
1-6278027-6
2-6278027-0
2-6278027-5
3-6278027-0
5-6278027-0
9-6278027-7
9-6278027-8
9-6278027-9
L (meters)
0.950 - 1.050
1.950 - 2.050
2.950 - 3.050
3.920 - 4.080
4.920 - 5.080
5.920 - 6.080
6.920 - 7.080
7.920 - 8.080
0.427 - 0.487
9.850 - 10.150
0.274 - 0.334
0.579 - 0.639
0.864 - 0.964
13.850 - 14.150
14.850 - 15.150
1.474 - 1.574
19.800 - 20.200
24.750 - 25.250
29.700 - 30.300
49.500 - 50.500
2.450 - 2.550
1.450 - 1.550
0.470 - 0.530
L (feet)
3.11 - 3.44
6.39 - 6.72
9.67 - 10.00
12.86 - 13.38
16.14 - 16.66
19.42 - 19.94
22.70 - 23.22
25.98 - 26.50
1.40 - 1.59
32.31 - 33.30
0.89 - 1.09
1.89 - 2.09
2.83 - 3.16
45.43 - 46.42
48.72 - 49.70
4.83 - 5.16
64.96 - 66.27
81.20 - 82.84
97.44 - 99.40
162.40 - 165.68
8.03 - 8.36
4.75 - 5.08
1.54 - 1.73
IL
(dB)
0.5
0.5
0.5
0.51
0.51
0.51
0.51
0.51
0.5
0.52
0.5
0.5
0.5
0.52
0.52
0.5
0.53
0.54
0.55
0.58
0.5
0.5
0.5
RL
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
(dB)
IL
ST
Qty
(dB)
0.5
0.5
0.5
0.51
0.51
0.51
0.51
0.51
0.5
0.52
0.5
0.5
0.5
0.52
0.52
0.5
0.53
0.54
0.55
0.58
0.5
0.5
0.5
RL
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
(dB)
1
1
1
1
1
1
0.0139
0.0139
1
2
2
2
2
2
AR
1
2
piece
piece
piece
piece
piece
piece
sheet
sheet
piece
piece
piece
piece
piece
piece
meter
piece
piece
HOUSING, CONN, MT-RJ,BLACK
DUST COVER, MT-RJ
SPRING, MT-RJ, 3.8 DESIGN
PIN KEEPER, 3.8MM
MT-RJ, SPRING PUSH, UNIVERSAL
CRIMP EYELET, MT-RJ
Leg Label - "A"
Leg Label - "B"
MT-RJ FERRULE, THERMOPLAST,MM
Crimp Eyelet
ST Short Boot - 1.6 to 2.0mm, Beige
ST Connector, Ceramic, Metal Nut
2.5mm ferrule cover
PVC Build-up tubing
2 fiber, 62.5/125, 1.8 mm, Twinzip, Orange, OFNR (Riser)
MT-RJ TwinZip Bend Limiting Boot, Beige
Trace Label
U of M
Description
Item
No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
Label 1
Per specification 107-1645-1
Trace # - Bar Code
XXXXXXXXXXXXXXX
Tyco logo
Made in XXXX
X-XXXXXXX-X
Trace # - Human Readable
Part Number
Country of Origin
This label is used on all lengths on this drawing.
Label 2
Per specification 107-1645-1
Trace # - Bar Code
XXXXXXXXXXXXXXX
Tyco logo
Made in XXXX
X-XXXXXXX-X
Trace # - Human Readable
Part Number
Country of Origin
This label is used on all lengths on this drawing.
Cable Assy Configurator
meters
-
-
Tyco Electronics, Inc.
Harrisburg, PA 17105-3608
Michael Kepko
-
-
-
-
-
Michael Kepko
CE
B
Rev Per EC#
06-022379
9/27/2006
-
MK
FO C/A - 2 fiber, 62.5/125, OFNR (Riser) jacket, MT-RJ (No Pins)
to ST
16
CAC Customer Layout Rev: D
Customer Print
NTS
A2
C- 6278027
2 of 2
B
