General Purpose
Low Power PCB Relays
Miniature PCB Relay PE bistable
n
n
n
n
n
n
SCHRACK
Polarized bistable version
1 pole 5 A, 1 form C (CO) or 6A, 1 form A (NO) contact
Sensitive version with 200mW coil
Ambient temperature 70°C
Low height 10.0mm
Plastic materials according to IEC 60335-1 (domestic appliances)
Typical applications
Room thermostats, electricity meters, home automation, white goods,
battery powered controls.
Approvals
VDE Cert. No. 40011901 (for AgNi90/10 contacts only), UL E214025
Technical data of approved types on request.
Z
Coil Data
Magnetic system
Coil voltage range
Operative range, IEC 61810
Reset voltage max., % of rated coil voltage
Min./Max. energization duration
Coil versions, bistable 1 coil
Coil
code
F02
F03
F05
2)
1)
Contact Data
Contact arrangement
Rated voltage
Max. switching voltage
Rated current
Breaking capacity max.
Contact material
Frequency of operation, with/without load
Set/reset time
Bounce time, form A/form B
Contact ratings
Type
IEC 61810
PE014
PE014
PE034
UL 508
PE013
PE014
PE514
PE514
PE033
PE014
PE034
C (CO)
5A, 240VAC, resistive, 85°C
30x10
3
1 form C (CO) or 1 form A (NO)
250VAC
400VAC
5A (CO - types)
6A (NO - AgNi - types)
1250VA (CO - types)
1500VA (NO AgNi - types)
AgNi 90/10, AgSnO
2
AgNi 90/10 HTV (gold plated)
360/72000 ops/h
typ. 8/8ms
4/7ms
Cycles
100x10
3
100x10
3
bistable, polarized
2.2 to 48VDC
2
120% at -40°C
20ms /1min at <10% duty factor
1) Information on reduced pulse duration with higher energization voltages on demand.
Rated
voltage
VDC
H02
H03
H05
H06
H12
H24
2.2
3
5
6
12
24
Set
voltage
VDC
1.65
2.25
3.75
4.5
9.0
18.0
Reset
voltage
VDC
1.65
2.25
3.75
4.5
9.0
18.0
Coil
resistance
Ω±10%
22
41
125
180
650
2750
Rated coil
power
mW
220
220
200
200
222
209
Contact Load
C (CO)
A (NO)
NO
5A, 250VAC, cosφ=1, 85°C
5A, 30VDC, 0 ms, 85°C
6A, 250VAC cosφ=1, 70°C
F06
F12
F24
2)
20x10
3
Coil codes F.. and H..have opposite polarity; refer to coil operation table.
All figures are given for coil without pre-energization, at ambient temperature +23°C.
Other coil voltages on request.
Coils - operation
Version
Coil terminals
Operate
Reset
Contact position not defined at delivery
A1
+
-
F..
A2
-
+
A1
-
+
H..
A2
+
-
NO (of CO) B300
NO (of CO) R300
C (CO)
N (NO)
C/A/B
A (NO)
5A, 250VAC, general purpose, 85°C
5A, 240VAC, resistive, 85°C
5A, 250VAC, resistive, 85°C
6A, 250VAC, resistive, 70°C
>5x10
6
operations.
6.000
6.000
6.000
50x10
100x10
3
3
100x10
3
Mechanical endurance
07-2017, Rev. 0717
www.te.com
© 2014 Tyco Electronics Corporation,
a TE Connectivity Ltd. company.
Catalog and product specification according
to IEC 61810-1 and to be used only together
with the ‘Definitions’ section.
Catalog and product data is subject to the
terms of the disclaimer and all chapters of
the ‘Definitions’ section, available at
http://relays.te.com/definitions
Catalog product data, ‘Definitions’ section,
application notes and all specifications are
subject to change.
1
General Purpose
Low Power PCB Relays
Miniature PCB Relay PE bistable
(Continued)
Insulation Data
Initial dielectric strength
between open contacts
between contact and coil
Initial insulation resistance
open contact circuit
coil-contact circuit
Clearance/creepage
between contact and coil
Material group of insulation parts
Tracking index of relay base
≥3.2/4mm
IIIa
PTI250V
Shock resistance (destructive)
Terminal type
Resistance to soldering heat THT
IEC 60068-2-20
PCB Layout / terminal assignment
Bottom view on solder pins
SCHRACK
Other Data
Material compliance: EU RoHS/ELV, China RoHS, REACH, Halogen content
1000V
rms
4000V
rms
Ambient temperature
>10x10 Ω
9
refer to the Product Compliance Support Center at
www.te.com/customersupport/rohssupportcenter
Resistance to heat and fire
according EN60335, par.30
-40 to 85°C
70°C at 100% duty factor
Category of environmental protection
IEC 61810
RTII - flux proof
RTIII - wash tight on request
>100g
PCB-THT
260°C/10s (flux proof version)
260°C/5s (wash tight version)
Packaging/unit
tube/25 pcs., box/500 pcs.
Dimensions
Shock resistance (functional/ 11ms), form A/form B >15/5g
>10x10
9
Ω
1 form C (CO) version
1 form A (NO) version
Product code structure
Type
PE
Miniature PCB Relay PE bistable
Version
0
Flux proof
Contact configuration
1
1 form C (CO) contact
Contact material
4
AgNi 90/10
Coil
Coil code: please refer to coil versions table
Typical product code
PE
0
1
4
F12
5
3
3
Wash tight (on request)
1 form A (NO) contact
AgSnO
2
5
AgNi 90/10 HTV (gold plated)
Product code
PE514F03
PE014F02
PE014F03
PE014F05
PE014F06
PE014F12
PE014F24
PE014H02
PE014H03
PE014H05
PE014H06
PE014H12
PE014H24
PE015F05
PE034F09
PE034F12
Version
wash tight
flux proof
Contacts
1 form C
1 CO contact
Contact material
AgNi 90/10
Coil
bistable
polarity F
Part number
bistable
polarity H
2
1 form C
1formA
1 NO contact
Catalog and product specification according
to IEC 61810-1 and to be used only together
with the ‘Definitions’ section.
AgNi 90/10 HTV
AgNi 90/10
bistable
polarity F
2-1415539-0
9-1415389-1
1415390-1
1-1415390-1
2-1415390-1
3-1415390-1
5-1415390-1
7-1415390-1
8-1415390-1
9-1415390-1
1415391-1
1-1415391-1
2-1415391-1
3-1415542-4
1415543-7
1415544-4
07-2017, Rev. 0717
www.te.com
© 2014 Tyco Electronics Corporation,
a TE Connectivity Ltd. company.
Catalog and product data is subject to the
terms of the disclaimer and all chapters of
the ‘Definitions’ section, available at
http://relays.te.com/definitions
Catalog product data, ‘Definitions’ section,
application notes and all specifications are
subject to change.
