Screw Terminal Aluminum Electrolytic Capacitors
FEATURES
• LONG LIFE AT 85°C (5,000 HOURS)
• HIGH RIPPLE CURRENT
• HIGH VOLTAGE (UP TO 450VDC)
SPECIFICATIONS
Operating Temperature Range
Rated Voltage Range
Rated Capacitance Range
Capacitance Tolerance
Max. Leakage Current (µA)
After 5 minutes (20°C)
W.V. (Vdc)
Max. Tan
δ
0.20
at 120Hz/20°C
0.25
W.V. (Vdc)
Surge Voltage
S.V. (Vdc)
W.V. (Vdc)
Low Temperature
Impedance Ratio at 120Hz
Z-25°C/Z+25°C
Capacitance Change
Load Life Test
Tan
δ
5,000 hours at +85°C
Leakage Current
Capacitance Change
Shelf Life Test
96 hours at +85°C
Tan
δ
(no load)
Leakage Current
Capacitance Change
Surge Voltage Test
1000 Cycles of 30 seconds duration
Tan
δ
every 6 minutes at 15°~35°C
Leakage Current
-25 ~ +85°C
350 ~ 450Vdc
1,200 ~ 10,000µF
±20% (M)
3x
C(µF)V
NSTL Series
RoHS
Compliant
includes all homogeneous materials
*See Part Number System for Details
350
400
450
< 3,300µF
< 2700µF
< 1800µF
~ 10000µF
~ 8200µF
~ 6800µF
350
400
450
400
450
500
350
400
450
8
8
8
Within ±20% of initial measured value
Less than 200% of specified maximum value
Less than specified maximum value
Within ±10% of initial measured value
Less than 120% of specified maximum value
Less than specified maximum value
Within ±15% of initial measured value
Less than specified maximum value
Less than specified maximum value
CASE AND CLAMP DIMENSIONS (mm)
D
P
W1 W2 W3 W4 W5
51 21.8 34.0 40.0 3.5 6.0 12
2 Point 64 28.2 40.0 45.0 4.5 7.0 12
Clamp 77 31.4 47.0 53.0 4.5 6.0 12
90 31.4 54.0 60.0 4.5 6.0 14
51 21.8 32.5 37.5 4.5 6.0 12
3 Point 64 28.2 38.0 43.0 4.5 8.0 14
Clamp 77 31.4 43.5 49.0 4.5 7.0 14
90 31.4 50.8 56.0 4.5 8.0 16
See Standard Values Table for "L" dimensions
W6
6.0
6.5
5.5
5.5
6.0
6.5
5.5
5.5
PART NUMBER SYSTEM
NSTL 103 M 350V 90X141 P2 F
RoHS compliant
P2 or P3 (2 point or 3 point clamp)
or blank for no hardware
Case Size (mm)
Voltage Rating
Tolerance Code
Capacitance Code
Series
2 Point Clamp
PVC Plate
Mounting Clamp
(Zinc Plating)
Screw Terminal
Bolt
D ± 2mm
M5 P=0.8
W5
Vent
W1±1
Please review the notes on correct use, safety and precautions found on
pages T10
&
T11
of NIC’s
Electrolytic Capacitor catalog.
Also found at
www.niccomp.com/precautions
If in doubt or uncertainty, please review your specific application - process details with
NIC’s technical support personnel:
tpmg@niccomp.com
PRECAUTIONS
W6 ± 1
L ± 3.0mm
W3
3 Point Clamp
Mounting Clamp Screw Terminal
(Zinc Plating)
Bolt
M5 P=0.8
W1±1
W2±1
W3
W5
P±1mm
4
W
PVC Plate
W4
D ± 2mm
Vent
W6 ± 1
®
L ± 3.0mm
160
