1N3899 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Discrete semiconductor> diode> 1N3899

1N3899: DescriptionRectifier Diode, 1 Phase, 1 Element, 20A, 50V V(RRM), Silicon, DO-5, DO-5, 2 PIN; CategoryDiscrete semiconductor diode; File Size63KB，1 Pages; ManufacturerSemitronics Corp.

Download Datasheet Parametric Compare View All

1N3899 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	1N3899	-	-	View	Buy Now

1N3899 Overview

Rectifier Diode, 1 Phase, 1 Element, 20A, 50V V(RRM), Silicon, DO-5, DO-5, 2 PIN

1N3899 Parametric

Parameter Name	Attribute value
Maker	Semitronics Corp.
Parts packaging code	DO-5
package instruction	DO-5, 2 PIN
Contacts	2
Reach Compliance Code	unknown
Is Samacsys	N
application	FAST RECOVERY
Shell connection	CATHODE
Configuration	SINGLE
Diode component materials	SILICON
Diode type	RECTIFIER DIODE
Maximum forward voltage (VF)	1.4 V
JEDEC-95 code	DO-5
JESD-30 code	O-MUPM-D1
Number of components	1
Phase	1
Number of terminals	1
Maximum operating temperature	150 °C
Maximum output current	20 A
Package body material	METAL
Package shape	ROUND
Package form	POST/STUD MOUNT
Certification status	Not Qualified
Maximum repetitive peak reverse voltage	50 V
Maximum reverse recovery time	0.2 µs
surface mount	NO
Terminal form	SOLDER LUG
Terminal location	UPPER
Base Number Matches	1

Preview

Download Datasheet

View All

1N3899 Related Products

	1N3899	1N3913	1N3900	1N3901	1812B824J250PX100HT-HB	1N3902
Description	Rectifier Diode, 1 Phase, 1 Element, 20A, 50V V(RRM), Silicon, DO-5, DO-5, 2 PIN	Rectifier Diode, 1 Phase, 1 Element, 30A, 400V V(RRM), Silicon, DO-5, DO-5, 2 PIN	Rectifier Diode, 1 Phase, 1 Element, 20A, 100V V(RRM), Silicon, DO-5, DO-5, 2 PIN	Rectifier Diode, 1 Phase, 1 Element, 20A, 200V V(RRM), Silicon, DO-5, DO-5, 2 PIN	Ceramic Capacitor, Ceramic, 25V, 5% +Tol, 5% -Tol, X7R, -/+15ppm/Cel TC, 0.82uF, 1812,	Rectifier Diode, 1 Phase, 1 Element, 20A, 300V V(RRM), Silicon, DO-5, DO-5, 2 PIN
package instruction	DO-5, 2 PIN	O-MUPM-D1	DO-5, 2 PIN	O-MUPM-D1	, 1812	DO-5, 2 PIN
Reach Compliance Code	unknown	unknown	unknown	unknown	compliant	unknown
Number of terminals	1	1	1	1	2	1
Maximum operating temperature	150 °C	150 °C	150 °C	150 °C	125 °C	150 °C
Package form	POST/STUD MOUNT	POST/STUD MOUNT	POST/STUD MOUNT	POST/STUD MOUNT	SMT	POST/STUD MOUNT
Maker	Semitronics Corp.	Semitronics Corp.	Semitronics Corp.	Semitronics Corp.	-	Semitronics Corp.
Parts packaging code	DO-5	DO-5	DO-5	DO-5	-	DO-5
Contacts	2	2	2	2	-	2
Is Samacsys	N	N	N	N	-	-
application	FAST RECOVERY	FAST RECOVERY	FAST RECOVERY	FAST RECOVERY	-	FAST RECOVERY
Shell connection	CATHODE	CATHODE	CATHODE	CATHODE	-	CATHODE
Configuration	SINGLE	SINGLE	SINGLE	SINGLE	-	SINGLE
Diode component materials	SILICON	SILICON	SILICON	SILICON	-	SILICON
Diode type	RECTIFIER DIODE	RECTIFIER DIODE	RECTIFIER DIODE	RECTIFIER DIODE	-	RECTIFIER DIODE
Maximum forward voltage (VF)	1.4 V	1.4 V	1.4 V	1.4 V	-	1.4 V
JEDEC-95 code	DO-5	DO-5	DO-5	DO-5	-	DO-5
JESD-30 code	O-MUPM-D1	O-MUPM-D1	O-MUPM-D1	O-MUPM-D1	-	O-MUPM-D1
Number of components	1	1	1	1	-	1
Phase	1	1	1	1	-	1
Maximum output current	20 A	30 A	20 A	20 A	-	20 A
Package body material	METAL	METAL	METAL	METAL	-	METAL
Package shape	ROUND	ROUND	ROUND	ROUND	-	ROUND
Certification status	Not Qualified	Not Qualified	Not Qualified	Not Qualified	-	Not Qualified
Maximum repetitive peak reverse voltage	50 V	400 V	100 V	200 V	-	300 V
Maximum reverse recovery time	0.2 µs	0.2 µs	0.2 µs	0.2 µs	-	0.2 µs
surface mount	NO	NO	NO	NO	-	NO
Terminal form	SOLDER LUG	SOLDER LUG	SOLDER LUG	SOLDER LUG	-	SOLDER LUG
Terminal location	UPPER	UPPER	UPPER	UPPER	-	UPPER
Base Number Matches	1	1	1	1	-	-
