1N2980RB datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Discrete semiconductor> diode> 1N2980RB

1N2980RB: DescriptionZener Diode, 16V V(Z), 5%, 10W, Silicon, Unidirectional, DO-4, DO-4, 1 PIN; CategoryDiscrete semiconductor diode; File Size184KB，3 Pages; ManufacturerSemitronics Corp.

Download Datasheet Parametric Compare View All

1N2980RB Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	1N2980RB	-	-	View	Buy Now

1N2980RB Overview

Zener Diode, 16V V(Z), 5%, 10W, Silicon, Unidirectional, DO-4, DO-4, 1 PIN

1N2980RB Parametric

Parameter Name	Attribute value
Maker	Semitronics Corp.
Parts packaging code	DO-4
package instruction	DO-4, 1 PIN
Contacts	1
Reach Compliance Code	unknown
ECCN code	EAR99
Is Samacsys	N
Configuration	SINGLE
Diode component materials	SILICON
Diode type	ZENER DIODE
Maximum dynamic impedance	4 Ω
JEDEC-95 code	DO-4
JESD-30 code	O-MUPM-D1
Number of components	1
Number of terminals	1
Maximum operating temperature	175 °C
Package body material	METAL
Package shape	ROUND
Package form	POST/STUD MOUNT
polarity	UNIDIRECTIONAL
Maximum power dissipation	10 W
Certification status	Not Qualified
Nominal reference voltage	16 V
surface mount	NO
technology	ZENER
Terminal form	SOLDER LUG
Terminal location	UPPER
Maximum voltage tolerance	5%
Working test current	155 mA
Base Number Matches	1

Preview

Download Datasheet

View All

IPN= 4869246 0000316 682

1N2980RB Related Products

	1N2980RB	AA1-B0-12-640-5D2-C	1N3311RA	1N3317RA	1N3998RA	1N3996RA	1N3008RB	1N2973RB	1N3307RA
Description	Zener Diode, 16V V(Z), 5%, 10W, Silicon, Unidirectional, DO-4, DO-4, 1 PIN	Magnetic Circuit Breaker,	Zener Diode, 12V V(Z), 10%, 50W, Silicon, Unidirectional, DO-5, DO-5, 1 PIN	Zener Diode, 18V V(Z), 10%, 50W, Silicon, Unidirectional, DO-5, DO-5, 1 PIN	Zener Diode, 6.2V V(Z), 5%, 10W, Silicon, Unidirectional, DO-4, DO-4, 1 PIN	Zener Diode, 5.1V V(Z), 5%, 10W, Silicon, Unidirectional, DO-4, DO-4, 1 PIN	Zener Diode, 120V V(Z), 5%, 10W, Silicon, Unidirectional, DO-4, DO-4, 1 PIN	Zener Diode, 9.1V V(Z), 5%, 10W, Silicon, Unidirectional, DO-4, DO-4, 1 PIN	Zener Diode, 8.2V V(Z), 10%, 50W, Silicon, Unidirectional, DO-5, DO-5, 1 PIN
Reach Compliance Code	unknown	compliant	unknown	unknown	unknown	unknown	unknown	unknown	unknown
Maximum operating temperature	175 °C	85 °C	175 °C	175 °C	175 °C	175 °C	175 °C	175 °C	175 °C
surface mount	NO	NO	NO	NO	NO	NO	NO	NO	NO
Maker	Semitronics Corp.	-	Semitronics Corp.	Semitronics Corp.	-	Semitronics Corp.	Semitronics Corp.	Semitronics Corp.	Semitronics Corp.
Parts packaging code	DO-4	-	DO-5	DO-5	DO-4	DO-4	DO-4	DO-4	DO-5
package instruction	DO-4, 1 PIN	-	DO-5, 1 PIN	DO-5, 1 PIN	O-MUPM-D1	DO-4, 1 PIN	DO-4, 1 PIN	DO-4, 1 PIN	DO-5, 1 PIN
Contacts	1	-	1	1	1	1	1	1	1
ECCN code	EAR99	-	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99
Is Samacsys	N	-	N	N	N	N	N	N	N
Configuration	SINGLE	-	SINGLE	SINGLE	SINGLE	SINGLE	SINGLE	SINGLE	SINGLE
Diode component materials	SILICON	-	SILICON	SILICON	SILICON	SILICON	SILICON	SILICON	SILICON
Diode type	ZENER DIODE	-	ZENER DIODE	ZENER DIODE	ZENER DIODE	ZENER DIODE	ZENER DIODE	ZENER DIODE	ZENER DIODE
Maximum dynamic impedance	4 Ω	-	1 Ω	2 Ω	1.1 Ω	1.1 Ω	75 Ω	2 Ω	0.4 Ω
JEDEC-95 code	DO-4	-	DO-5	DO-5	DO-4	DO-4	DO-4	DO-4	DO-5
JESD-30 code	O-MUPM-D1	-	O-MUPM-D1	O-MUPM-D1	O-MUPM-D1	O-MUPM-D1	O-MUPM-D1	O-MUPM-D1	O-MUPM-D1
Number of components	1	-	1	1	1	1	1	1	1
Number of terminals	1	-	1	1	1	1	1	1	1
Package body material	METAL	-	METAL	METAL	METAL	METAL	METAL	METAL	METAL
Package shape	ROUND	-	ROUND	ROUND	ROUND	ROUND	ROUND	ROUND	ROUND
Package form	POST/STUD MOUNT	-	POST/STUD MOUNT	POST/STUD MOUNT	POST/STUD MOUNT	POST/STUD MOUNT	POST/STUD MOUNT	POST/STUD MOUNT	POST/STUD MOUNT
polarity	UNIDIRECTIONAL	-	UNIDIRECTIONAL	UNIDIRECTIONAL	UNIDIRECTIONAL	UNIDIRECTIONAL	UNIDIRECTIONAL	UNIDIRECTIONAL	UNIDIRECTIONAL
Maximum power dissipation	10 W	-	50 W	50 W	10 W	10 W	10 W	10 W	50 W
Certification status	Not Qualified	-	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified
Nominal reference voltage	16 V	-	12 V	18 V	6.2 V	5.1 V	120 V	9.1 V	8.2 V
technology	ZENER	-	ZENER	ZENER	ZENER	ZENER	ZENER	ZENER	ZENER
Terminal form	SOLDER LUG	-	SOLDER LUG	SOLDER LUG	SOLDER LUG	SOLDER LUG	SOLDER LUG	SOLDER LUG	SOLDER LUG
Terminal location	UPPER	-	UPPER	UPPER	UPPER	UPPER	UPPER	UPPER	UPPER
Maximum voltage tolerance	5%	-	10%	10%	5%	5%	5%	5%	10%
Working test current	155 mA	-	1000 mA	700 mA	405 mA	490 mA	20 mA	275 mA	1500 mA
Base Number Matches	1	-	1	1	1	1	1	1	1
