TECHNICAL DATA SHEET
6 Lake Street, Lawrence, MA 01841
1-800-446-1158 / (978) 620-2600 / Fax: (978) 689-0803
Website: http://www.microsemi.com
Gort Road Business Park, Ennis, Co. Clare, Ireland
Tel: +353 (0) 65 6840044 Fax: +353 (0) 65 6822298
DUAL SCHOTTKY POWER RECTIFIER
Qualified per MIL-PRF-19500/608
DEVICES
LEVELS
1N6660
1N6660CCT1
1N6660R
1N6660CAT1
1N6660DT1
JAN
JANTX
JANTXV
30 Amp / 45 Volts
COMMON CATHODE
OR
COMMON ANODE
SCHOTTKY RECTIFIER
ABSOLUTE MAXIMUM RATINGS
(T
C
= +25°C unless otherwise noted)(Per Diode)
Parameters / Test Conditions
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
Average Forward Current, 25°C
Peak Surge Forward Current @ t
p
= 8.3ms, half
sinewave, I
o
= 0; V
RM
= 0
Thermal Resistance, Junction to Case
Thermal Resistance, Junction to Ambient
Operating Junction Temperature
Storage Temperature
Symbol
V
RWM
V
RRM
V
R
I
o
I
FSM
R
θjc
R
θja
T
j
T
stg
Value
45
45
45
15
Note 1
300
1.65
40
-65°C to 150
-65°C to 150
Unit
V
V
V
Apk
Apk
°C/W
°C/W
°C
°C
TO-254
Note:
1. Derate linearly @ 300mA/°C from T
j
= T
c
= +100°C to 150°C
ELECTRICAL CHARACTERISTICS
(T
A
= +25°C, unless otherwise noted)
Parameters / Test Conditions
OFF CHARACTERTICS
Forward Voltage
I
F
= 5A, T
j
= 25°C*
I
F
= 15A, T
j
= 25°C*
I
F
= 30A, T
j
= 25°C*
I
F
= 15A, T
j
= -55°C*
Reverse Current
V
R
= 45V, T
j
= 25°C
V
R
= 45V, T
j
= 125°C
Junction Capacitance
V
R
= 5V
f = 1MHz
* Pulse test: Pulse width 300 µsec, Duty cycle 2%
0.55
0.75
1.0
0.80
1.0
40
2000
Symbol
Min.
Max.
Unit
•
1
•
2
•
3
1N6660 & 1N6660CCT1
•
1
V
F
V
•
2
•
3
1N6660R & 1N6660CAT1
I
R
mA
•
1
•
2
•
3
C
j
pF
1N6660DT1
T4-LDS-0015 Rev. 2 (101670)
Page 1 of 2
TECHNICAL DATA SHEET
6 Lake Street, Lawrence, MA 01841
1-800-446-1158 / (978) 620-2600 / Fax: (978) 689-0803
Website: http://www.microsemi.com
Gort Road Business Park, Ennis, Co. Clare, Ireland
Tel: +353 (0) 65 6840044 Fax: +353 (0) 65 6822298
PACKAGE DIMENSIONS
Ltr
BL
CH
LD
LL
LO
LS
MHD
MHO
TL
TT
TW
Dimensions
Inches
Millimeters
Min
Max
Min
Max
.535
.545
13.59 13.84
.249
.260
6.32
6.60
.035
.045
0.89
1.14
.510
.570
12.95 14.48
.150 BSC
3.81 BSC
.150 BSC
3.81 BSC
.139
.149
3.53
3.78
.665
.685
16.89 17.40
.790
.800
20.07 20.32
.040
.050
1.02
1.27
.535
.545
13.59 13.84
NOTES:
1. Dimensions are in inches
2. Millimeters are given for general information only.
3. All terminals are isolated from case.
4. In accordance with ASME Y14.5M, diameters are
equivalent to
Φx
symbology.
Types 1N6660, 1N6660CCT1, 1N6660R, 1N6660CAT1, and 1N6660DT1
FIGURE 1.
Physical dimensions and configuration (TO-254AA).
T4-LDS-0015 Rev. 2 (101670)
Page 2 of 2
