NOTE: All specifications in this datasheet are measured at an ambient temperature of 25°C, humidity<75%, nominal input voltage and at
rated output load unless otherwise specified
Safety Specifications
Parameters
Approvals
Standards
UL60601-1 (except AM1DM-0305SH60-NZ)
EN55022 Class B (see recommended circuit)
IEC61000-4-2, Perf. Criteria B (ESD Contact +/- 8KV)
Pin Out Specifications
Pin
1
2
5
6
7
Single
+ V Input
- V Input
- V Output
No pin
+ V Output
Dual
+ V Input
- V Input
- V Output
Common
+ V Output
www.aimtec.com
F 051e R7 Rev # 1.91A10
Tel: +1 514 620 2722
2 of 4
Toll free: + 1 888 9 AIMTEC (926 6832)
North America only
Series AM1DM-NZ
1 Watt | DC-DC Converter
Dimensions
6000 DVC
19.50
(0.77)
9.8
(0.39)
PRINTED
FACE
12.50
(0.49)
12.5
(0.49)
0.50
(0.02)
2.54
(0.10)
15.24
(0.60)
4.10
(0.16)
0.50
(0.02)
9.8
(0.39)
Dimensions are in mm (inch)
Pin Pitch Tolerance: ±0.10 mm (±0.004 inch)
Case Tolerance: ±0.25 mm (±0.01 inch)
0.3(0.01)
3.20
(0.05)
0.50
(0.02)
Typical Characteristics
Derating Graph
3.3V output models
Temperature
5V output models
Graph
+15 %
Output Power (%)
Tolerance Envelope
Free Air Convection
+ 15%
+ 5%
+2.5%
-5 %
Tolerance Envelope Graph
Typical Load Line
+2.5%
+10 %
100
+ 5%
80
60
Typical Load
85ºC
Line
Safe Operating Area
Output Voltage
20
Output Voltage
Nominal
40
Voltage
Nominal
Voltage
-2.5%
-7.5%
0
-40 -20
0
20
40
60
80
100
Ambient
Temperature º C
-12.5%
10%
50%
Output Current (%)
100%
10%
50%
Output Current (%)
100%
Others
Tolerance Envelope Graph
+10%
+5%
+2.5%
-2.5%
-7.5%
Typical Load Line
Output Voltage
10%
50%
Output Current(%)
100%
www.aimtec.com
F 051e R7 Rev # 1.91A10
Tel: +1 514 620 2722
3 of 4
Toll free: + 1 888 9 AIMTEC (926 6832)
North America only
Series AM1DM-NZ
1 Watt | DC-DC Converter
Typical application circuit
Single
Vin+
Vo+
External capacitor – Single output
Cout
Cin
Vin-
Vo-
Vin
(VDC)
5
12
24
Cin
(μF)
10
4.7
2.2
Vout
(VDC)
3.3/5
12
15
Cout
(μF)
10
2.2
1
Dual
Vin+
Cout
Com
Cin
Cout
Vin-
Vo-
Vo+
External capacitor – Dual output
Vin
(VDC)
5
12
24
Cin
(μF)
10
4.7
2.2
Vout
(VDC)
±5
±9
±12/±15
Cout
(μF)
4.7
2.2
1
EMI
Recommended Circuit (Class B)
LDM
6.8µH
+V output
DC/DC
Converter
C1
4.7µF/
50V
C2
4.7µF/
50V
+V input
Cout
Load
-V input
-V output
NOTE: Cout value is the same as referenced in the Application Circuit.
NOTE: 1.
Datasheets are updated as needed and as such, specifications are subject to change without notice. Once printed or downloaded, datasheets are no longer controlled
by Aimtec; refer to www.aimtec.com for the most current product specifications.
2.
Product labels shown, including safety agency certifications on labels, may vary based on the
date manufactured.
3.
Mechanical drawings and specifications are for reference only.
4.
All specifications are measured at an ambient temperature of 25°C, humidity<75%,
nominal input voltage and at rated output load unless otherwise specified.
5.
Aimtec may not have conducted destructive testing or chemical analysis on all internal components
and chemicals at the time of publishing this document. CAS numbers and other limited information are considered proprietary and may not be available for release.
6.
This
product is not designed for use in critical life support systems, equipment used in hazardous environments, nuclear control systems or other such applications which necessitate
specific safety and regulatory standards other the ones listed in this datasheet.
7.
Warranty is in accordance with Aimtec’s standard Terms of Sale available at www.aimtec.com.
