318330017 Product Details
Industrial Relays (General Purpose)
Always EU RoHS/ELV Compliant
(
Statement of Compliance
)
Product Highlights:
RT1 Series
Contact Current Class = 10A to 20A Class, Less Than
16A
Contact Rated Current = 12 A
Terminal Type = PCBTHT, Plugin
Contact Arrangement = 1 Form C (CO)
View all Features
Share
Print
Email
Quick Links
Pricing & Availability
Search for Tooling
Product Feature Selector
Contact Us About This Product
318330017
TE Internal Number: 318330017
Superseded
Search for Replacement Parts
Add to My Part List
Request Sample
Find Similar Products
Buy Product
Documentation & Additional Information
Product Drawings:
None Available
Catalog Pages/Data Sheets:
Power PCB Relay RT1 (PDF, English)
Product Specifications:
None Available
Application Specifications:
None Available
Instruction Sheets:
None Available
CAD Files:
None Available
Additional Information:
Product Line Information
Related Products:
Tooling
List all Documents
Product Features
(Please use the Product Drawing for all design activity)
Electrical Characteristics:
Contact Current Class = 10A to 20A Class, Less Than 16A
Contact Rated Current (A) = 12
Contact Limiting Continuous Current (A) = 12
Contact Limiting Making Current (A) = 25
Contact Limiting Breaking Current (A) = 12
Insulation Initial Dielectric Between Coil/Contact Class = >4000V
Class
Insulation Initial Dielectric Between Open Contacts (V rms) = 1000
Insulation Initial Dielectric Between Contacts and Coil (V rms) =
5000
Contact Rated Voltage (VAC) = 250
Contact Switching Voltage Max. (VAC) = 400
Contact Limiting ShortTime Current (A) = 12
Coil Rated Voltage (VAC) = 24
Coil Resistance (Ω) = 350
Coil Rated Power, AC (VA) = 1.00
Coil Rated Power Class = 0.5VAW to 1.0VA Class
Insulation Creepage Class = >8mm Class
Insulation Clearance Class = >8mm Class
Insulation Special Features = Tracking Index of Relay Base PTI250
Dimensions:
Mechanical Length Class = 25mm to 30mm Class
Length (mm [in]) = 29.00 [1.142]
Mechanical Width Class = 12mm to 16mm Class
Width (mm [in]) = 12.70 [0.500]
Mechanical Height Class = 15mm to 16mm Class
Height (mm [in]) = 15.70 [0.618]
Insulation Clearance Between Contact and Coil (mm [in]) = 10
[0.394]
Body Features:
Mount Type = PCB, Socket
Weight (g [oz]) = 14.00 [0.494]
Contact Features:
Terminal Type = PCBTHT, Plugin
Contact Material = AgNi90/10
Contact Number of Poles = 1
Configuration Features:
Contact Arrangement = 1 Form C (CO)
Coil Magnetic System = Monostable, AC
Coil Special Features = UL Coil Insulation Class F
Industry Standards:
RoHS/ELV Compliance = RoHS compliant, ELV compliant
Lead Free Solder Processes = Wave solder capable to 260°C, Wave
solder capable to 240°C, Wave solder capable to 265°C
RoHS/ELV Compliance History = Always was RoHS compliant
Approved/Registered Standards = cULus, cCSAus, CQC, VDE
Environmental:
Environmental Category of Protection = RTII
Environmental Ambient Temperature, Max. (°C [°F]) = 70 [158]
Environmental Ambient Temperature Class = 50°C to 70°C Class
Packaging Features:
Packaging Method = Tube
Other:
Series = RT1
Brand = Schrack
