"PRELIMINARY"
2.45 GHz High Pass Filter
Detail Specification: 08/07/06
General Specifications
Part Number
Freq Range (MHz)
Insertion Loss
Return Loss
Attenuation (min.)
2450HP14A100
2400 - 2500
1.3 dB max.
14.0 dB min.
20 dB @ 1917 MHz
100% Tin
Tin / Lead
Suffix = "None"
Suffix = "/Pb"
eg. 2450HP14A100
eg. 2450HP14A100/Pb
Impedance
Operating Temperature
Reel Quantity
Input Power
50
Ω
-40 to +85°C
4,000
3 W max.
P/N 2450HP14A100
Page 1 of 2
Termination
Style
Terminal Configuration
No.
Function
IN
GND
OUT
NC
GND
NC
3
2
1
1
2
3
Mechanical Dimensions
In
L
W
T
a
b
c
g
p
0.063 ± 0.004
0.031 ± 0.004
0.022 ± 0.004
0.008 ± 0.004
0.008 +.004/-.008
0.006 ± 0.004
0.012 ± 0.004
0.020 ± 0.002
mm
1.60 ± 0.10
0.80 ± 0.10
0.55 ± 0.10
0.20 ± 0.10
0.20
+0.1/-0.2
T
g
b
4
0.15 ± 0.10
0.30 ± 0.10
0.50 ± 0.05
L
a
p
c
4
5
W
6
5
6
Mounting Considerations
Mount these devices with brown mark facing up.
Line width should be designed to provide 50
Ω
impedance matching characteristics.
Units: mm
Solder Resist
0.55
0.25
Land
Through-hole (
φ
0.35)
*
0.25
*
0.25
Johanson Technology, Inc. reserves the right to make design changes without notice.
All sales are subject to Johanson Technology, Inc. terms and conditions.
www.johansontechnology.com
931 Via Alondra • Camarillo, CA 93012 • TEL 805.389.1166 FAX 805.389.1821
2003 Johanson Technology, Inc. All Rights Reserved
"High Frequency Ceramic Solutions"
2.45 GHz High Pass Filter
Detail Specification: 08/07/06
P/N 2450HP14A100
Page 2 of 2
Typical Electrical Performance (T=25°C)
)
)
)
)
)
)
)
)
Insertion/Return Loss
)
)
)
)
)
)
)
)
)
0
)
)
)
)
)
)
-10
-20
-30
-40
-50
-60
0.5
1.0
1.5
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
dB(S(2,2))
dB(S(1,1))
dB(S(2,1))
)
)
)
2.0
)
)
2.5
3.0
freq, GHz
)
)
)
)
)
)
)
)
