NJG1108HA8

Description
Narrow Band Low Power Amplifier, 1570MHz Min, 1580MHz Max, 1.20 X 1 MM, 0.38 MM HEIGHT, ULTRA SMALL, PLASTIC PACKAGE-6
CategoryWireless rf/communication    Radio frequency and microwave
File Size280KB,10 Pages
ManufacturerNew Japan Radio Co., Ltd..
Environmental Compliance
Download Datasheet Parametric View All

NJG1108HA8 Overview

Narrow Band Low Power Amplifier, 1570MHz Min, 1580MHz Max, 1.20 X 1 MM, 0.38 MM HEIGHT, ULTRA SMALL, PLASTIC PACKAGE-6

NJG1108HA8 Parametric

Parameter NameAttribute value
Is it lead-free?Lead free
Is it Rohs certified?conform to
Reach Compliance Codecompliant
Is SamacsysN
Characteristic impedance50 Ω
structureCOMPONENT
Gain17 dB
Maximum input power (CW)15 dBm
JESD-609 codee4
Maximum operating frequency1580 MHz
Minimum operating frequency1570 MHz
Maximum operating temperature85 °C
Minimum operating temperature-40 °C
RF/Microwave Device TypesNARROW BAND LOW POWER
Terminal surfaceGold (Au) - with Nickel (Ni) barrier
Maximum voltage standing wave ratio2
Base Number Matches1
NJG1108HA8
GNSS LOW NOISE AMPLIFIER
I
GENERAL DESCRIPTION
The NJG1108HA8
is a low noise amplifier GaAs MMIC designed for
GNSS (Global Navigation Satellite Systems). This amplifier provides
low noise figure, high gain and high IP3 operated by single low positive
power supply. This IC has the function of Stand-by mode. The
NJG1108HA8 can be tuned to wide frequency from 1.5GHz to 2.7GHz
by changing the external matching components.
An ultra-small and ultra-thin package of
the USB6-A8 is adopted.
I
APPLICATIONS
GNSS application, like GPS,Galileo,GLONASS and COMPASS
W-LAN and WiMAX application
Note: Please check the Application Note for WLAN and WiMAX
.
I
PACKAGE OUTLINE
NJG1108HA8
I
FEATURES
G
Operating frequency range
G
Low voltage operation
G
Low current consumption
G
High gain
G
Low noise figure
G
Input power at 1dB gain compression point
G
High input IP3
G
Ultra-small and ultra-thin package
I
PIN CONFIGURATION
(Top View)
GN
D
RFI
N
1.5~2.7GHz
+2.7V typ.
2.0mA typ.
@V
CTL
=1.85V
1uA typ.
@V
CTL
=0V
19dB typ.
@V
CTL
=1.85V, f=1.575GHz
1.0dB typ.
@V
CTL
=1.85V, f=1.575GHz
-15.0dBm typ. @V
CTL
=1.85V, f=1.575GHz
0dBm typ.
@V
CTL
=1.85V, f=1.575+1.5751GHz
USB6-A8 (Package size: 1.0x1.2x0.38mm)
3
RFOU
T
4
2
Bia
Circui
GN
D
5
Logi
Circui
VCT
L
VIN
V
1
Pin Connection
1. VINV
2. RFOUT
3. GND
4. RFIN
5. GND
6. VCTL
6
I
TRUTH TABLE
V
CTL
H
L
“H”=V
CTL(H)
, “L”=V
CTL(L)
LNA Mode
Active Mode
Sleep Mode
Note: Specifications and description listed in this datasheet are subject to change without notice.
Ver.2013-04-02
-1-
