MAGNUM
®
Single & Double Row
Filtered Connectors
Series 1384X
Edge Connectors –
1 Sided Boards/Vertical Mount
13848-08G02B
Euro-MAG Series
PCB – Spring Clamp
SPECIFICATIONS
Rating:
10A, 250V
Center Spacing:
.375” or 3/8” (9.52 mm)
Wire Range:
#14-22 AWG CU; entry to PC board at 90° angle.
PC Board:
Edge contact accepts standard 1/16” (.0625) PCB.
Contacts:
Cantilever design .020” thick phosphorus bronze
with mating surface tin plated (.000200) over copper (.000050).
Terminals:
Pressure plate terminals.
Material:
Black, UL Rated 94V0 Thermoplastic (125°C)
Operating Temperature:
-55°C to 105°C (212°F)
Agency Information:
UL/CSA; CE Certified
13847-08TO2B
13847 Series
A
B
C
Inches (mm)
Poles
04
05
06
07
08
09
10
11
12
13
14
15
16
A
2.25
2.62
3.00
3.37
3.75
4.12
4.50
4.87
5.25
5.62
6.00
6.37
6.75
B
1.87
2.25
2.62
3.00
3.37
3.75
4.12
4.50
4.87
5.25
5.62
6.00
6.37
C
1.12
1.50
1.87
2.25
2.62
3.00
3.37
3.75
4.12
4.50
4.87
5.25
5.62
D
.89
(22.6)
Base & Rail Mount
Connectors
1.53
1.90
2.28
2.65
3.03
3.40
3.78
4.15
4.53
4.90
5.28
5.65
6.03
.15
(3.9)
D
1.03
(26.2)
13848 Series
A
B
C
.15
(3.9)
* Dimensions in inches. To convert to millimeters, multiply by 25.4.
Optional polarizing key (Part No. C5971) consult with factory.
1
2
3
4
5
6
11
12
13
14
15
1.03
(26.2)
D
fl.06
(fl1.5)
Power Distribution Blocks
fl.09
(fl 2.3)
Part Numbering System
Series
Block Style
Poles
Terminal Plating
Inches (Millimeters)
Screw Style
Block Color
Special Options
1 3 8 4
–
7
- Flat mtg. ears
04
to
16
w/ 2 slots
8
- Mtg. ears w/2 standoffs
with hole for mounting strip
T
- Tin over copper
G
- Gold*
0 2
02
- #6-32 pan head.
w/ SEMS wire
clamp
B
B
- Black
M
- Marking strip
WIRE MANAGEMENT PRODUCTS
* Consult Factory
144
