plerow
TM
APL0832
PLL Module
Features
·
4 dBm Output Level at 832 MHz
·
Channel Step Size : 200 kHz
·
2
nd
Description
The plerow
TM
PLL synthesizer module was
designed for use in wireless and wireline
systems in a wide range of frequency from
50 MHz to 6 GHz. ASB’s PLL provides ex-
ceptionally low spurious and phase noise
performance with fast locking time and low
current consumption. All products are avail-
able in a surface-mount type package.
Harmonic : < -25 dBc
·
Spurious Level : < -65 dBc
·
Lock Time : < 10 ms
·
Current Consumption : < 30 mA
Specifications
Parameter
Frequency Range
Output Power
Supply Voltage
Current Consumption
Channel Step Size
2 Harmonics
Spurious Level
Lock Time
Reference Frequency
Reference Input Level
Phase Noise (C / N)
@ 1 kHz
@ 10 kHz
@ 100 kHz
Output Impedance
Operating Temp. Range
Package Type & Size
Ω
°C
mm
-40
dBc/Hz
-80
-103
-122
50
25
SMT, 19.0W×19.0L×5.8H
80
-75
-98
-117
nd
Unit
MHz
dBm
V
mA
kHz
dBc
dBc
ms
MHz
dBm
Min.
818
2
4.75
Typical
Max.
848
4
5
25
200
-15
-70
6
5.25
30
More Information
Website: www.asb.co.kr
E-mail: sales@asb.co.kr
Tel: (82) 42-528-7223
Fax: (82) 42-528-7222
ASB Inc., 4th Fl. Venture Town
Bldg., 367-17 Goijeong-Dong,
Seo-Gu, Daejon 302-716, Korea
-25
-65
10
10
0
1) Measurement conditions are as follows: T = 25°C, V
CC
= 5 V, Freq. = 832 MHz, 50 ohm system.
Outline Drawing
1/1
www.asb.co.kr
December 2007
