Example with connector 222C20M13
4
12
7
D
B
C
6.6
A
4
2.5
XX = distance between fixing axies B
2.5
6
1.8
1.8
3
5.6
3
2
1
Example with B=25mm (C13024-25)
B
2
Material : Copper alloy / Ni Sn plated
2 23/10/08
www.nicomatic.com
Mail : nicomatic@nicomatic.fr
Tel : +33 (0)4.50.36.13.85
This document and drawings, sketches, and schematic drawings are the property of
the NICOMATIC company. and no parts thereof may be reproduced and used without
the written consent of the owner. Law dated 11.03.1902
H.L.
Drawn
Iss
Date
E.M.
Checked
D.Z.
Approved
Item : Shielding for CMM220 female on cable,
distance between axis XXmm
General
tolerance
1
Page
1/1
Folder :
X:\Méthodes\Plans clients\Plans clients 2D\11 - CMM composants\05 - Blindage\C13024-xx_cl
Catalogue
Reference :
C13024-XX
±0.2
Scale
3:1
D
A4
