Product catalogue | PCB connection systems | PCB terminals | TOP screw connection | LPA TOP | LPA TOP 1/90
General ordering data
Order No.
Part designation
Version
EAN
Qty.
System parameters
Conductor connection system
Fitted to PCB
Outgoing direction of conductor
Pitch
Pitch in inch
No. of poles
Fitted by customer
Solder pin length
Dia. of fitting hole
Fitting hole tolerance
Screwdriver blade
Screwdriver blade standard
Tightening torque, min.
Tightening torque, max.
Clamping screw
Stripping length
L1 in mm
L1 in inch
Material data
Insulating material
Colour
colour chart
Insulating material group
Flammability class UL 94
1535260000
LPATOP1/2/90 STI3.2 OR
PCB terminal, TOP connection, Soldered
connection, Clamping range, max.: 2.5 mm²,
Pitch: 5.08 mm, No. of poles: 2, 90°, Box
4008190067212
100 pc(s).
TOP connection
Soldered connection
90°
5.08 mm
0.2 inch
2
no
3.2 mm
1.3 mm
+ 0.1 mm
0.6 x 3.5
DIN 5264
0.4 Nm
0.5 Nm
M 2.5
13 mm
5.08 mm
0.2 inch
PA
orange
Similar to RAL 2000
I
V-2
-1-
Product catalogue | PCB connection systems | PCB terminals | TOP screw connection | LPA TOP | LPA TOP 1/90
Material data
CTI
Contact base material
Contact surface
Storage temperature, min.
Storage temperature, max.
Connectable conductors
Clamping range, min.
Clamping range, max.
AWG, min.
AWG, max.
Solid, min. H05(07) V-U
Solid, max. H05(07) V-U
Flexible, min. H05(07) V-K
Flexible, max. H05(07) V-K
With wire end ferrule, acc. to DIN 46 228/1, min.
With wire end ferrule, acc. to DIN 46 228/1, max.
w. plastic collar ferrule, DIN 46228 pt 4, min.
w. plastic collar ferrule, DIN 46228 pt 4, max.
DIN IEC rating data
Rated current, min. No. pins (Tu=20°C)
Rated current, max. No. pins (Tu=20°C)
Rated current, min. No. pins(Tu=40°C)
Rated current, max. No. pins (Tu=40°C)
Rated voltage for overvoltage class/pollution
severity II/2
Rated voltage for overvoltage class/pollution
severity III/2
Rated voltage for overvoltage class/pollution
severity III/3
Rated impulse withstand voltage for overvoltage
class/pollution severity II/2
Rated impulse withstand voltage for overvoltage
class/pollution severity III/2
Rated impulse withstand voltage for overvoltage
class/pollution severity III/3
CSA rating data
Rated voltage (Use group D)
Rated current (Use group D)
AWG conductor (field wiring), min.
AWG conductor (field wiring), max.
UL 1059 rating data
Rated voltage (Use group D)
Rated current (Use group D)
AWG conductor, min.
AWG conductor, max.
>= 600
Copper alloy
tinned
-20 °C
55 °C
0.13 mm²
2.5 mm²
26
14
0.5 mm²
2.5 mm²
0.5 mm²
2.5 mm²
0.5 mm²
1.5 mm²
0.5 mm²
1.5 mm²
24 A
18 A
23 A
15 A
500 V
320 V
250 V
4 kV
4 kV
4 kV
300 V
10 A
26
14
300 V
10 A
26
14
-2-
Product catalogue | PCB connection systems | PCB terminals | TOP screw connection | LPA TOP | LPA TOP 1/90
Approvals
Approvals institutes
Downloads
CAD Library (P-CAD Format - Standard)
Classifications
ETIM 2.0
ETIM 3.0
eClass 4.1
eClass 5.0
eClass 5.1
LPA TOP1.LIB
NK
EC001284
NK
NK
NK
Similar products
Order No.
1535360000
Part designation
LPATOP1/3/90 STI3.2 OR
Version
PCB terminal, TOP connection, Soldered connection, Clamping
range, max.: 2.5 mm², Pitch: 5.08 mm, No. of poles: 3, 90°, Box
-3-
