General Purpose, Industrial, and Power Relays
4
R12 Series Ñ General Purpose Relays
Features
c
Slightly Larger Than 1 Cubic Inch
c
Clear Plastic Dust Cover
c
High Reliability, 50 Million Operations
c
Plug-In or Solder Terminals
AC Operated
Stock
No.
235-0019
235-0092
Mfr.Õs
Type
R12-17A3-24
R12-17A3-24P
Fig.
A
A
Nominal
Voltage
24 VAC
24 VAC
Contact
Arrangement
4PDT
4PDT
Nominal
Power
1.2 VA
1.2 VA
Max.
Contact
Current @
120 VAC
3A
5A
EACH
10.83
10.85
R14 Series Ñ General Purpose Relays
Features
c
Slightly Larger Than 1 Cubic Inch
c
Clear Plastic Dust Cover
c
High Reliability, 50 Million Operations
c
Plug-In or Solder Terminals
AC Operated
Stock
No.
235-0023
235-0024
235-1030
235-1032
235-1034
235-1036
Mfr.Õs
Type
R14-11A10-24
R14-11A10-120
R14-14A10-24
R14-14A10-120
R14-17A10-24
R14-17A10-120
Fig.
C
C
C
C
C
C
Nominal
Voltage
24 VAC
120 VAC
24 VAC
120 VAC
24 VAC
120 VAC
Contact
Arrangement
DPDT
DPDT
3PDT
3PDT
4PDT
4PDT
Max.
Nominal
Power
120 VAC
1.2 VA
1.2 VA
1.2 VA
1.2 VA
1.2 VA
1.2 VA
Contact
Current @
10 A
10 A
10 A
10 A
10 A
10 A
EACH
8.91
8.67
11.84
12.02
12.70
12.49
Electrical Specifications
c
Operating Time: 25 mS or Less
c
Release Time: 25 mS or Less
c
Duty Cycle: Continuous
c
Operating Temperature: Ð30¡ to +55¡C
Electrical Specifications
c
Operating Time: 25 mS or Less
c
Release Time: 25 mS or Less
c
Duty Cycle: Continuous
c
Operating Temperature: Ð30¡ to +55¡C
DC Operated
Stock
No.
Mfr.Õs
Type
R14-5D15-12
R14-11D10-12
R14-11D10-24
R14-14D10-12
R14-14D10-24
R14-17D10-12
R14-17D10-24
Fig.
C
C
C
C
C
C
C
Nominal
Voltage
12 VDC
12 VDC
24 VDC
12 VDC
24 VDC
12 VDC
24 VDC
Contact
Arrangement
SPDT
DPDT
DPDT
3PDT
3PDT
4PDT
4PDT
Coil
Res.
½ (Typ.)
160
160
650
107
410
100
350
Max.
Nominal
Power
28 VDC
0.9 W
0.9 W
0.9 W
0.9 W
0.9 W
0.9 W
0.9 W
Contact
Current @
15 A
10 A
10 A
10 A
10 A
10 A
10 A
EACH
7.55
7.97
8.05
11.84
11.84
13.34
13.34
DC Operated
Stock
No.
235-0021
235-0022
Mfr.Õs
Type
R12-17D3-12
R12-17D3-24
Fig.
B
B
Nominal
Voltage
12 VDC
24 VDC
Contact
Arrangement
4PDT
4PDT
Coil
Res.
½ (Typ.)
160
650
Nominal
Power
0.9 W
0.9 W
Max.
Contact
Current @
28 VDC
3A
3A
EACH
11.00
11.11
235-0025
235-0026
235-0027
235-1038
235-1040
235-1042
235-1044
R16 Series Ñ Miniature Industrial Relays
Features
c
Combination Plug-In/Solder Terminals
c
Clear Plastic Dust Cover
c
Gold Overlay Bar Type Long Life Contacts
DC Operated
Stock
No.
235-0028
235-0030
Mfr.Õs
Type
R16-11D3-12
R16-11D5-24
Fig.
D
D
Nominal
Voltage
12 VDC
24 VDC
Contact
Arrangement
DPDT
DPDT
Coil
Res.
½ (Typ.)
185
700
Max.
Nominal
Power
28 VDC
0.75 W
1.00 W
Contact
Current @
3A
5A
EACH
8.00
8.01
R22 Series Ñ Slim Line Relays
Features
c
Sealed Construction
c
Long Life
c
PC Board Mount
DC Operated
Stock
No.
235-0505
Mfr.Õs
Type
R22-5D16-24
Fig.
E
Nominal
Voltage
24 VDC
Contact
Arrangement
SPDT
Coil
Res.
½ (Typ.)
1100
Max.
Nominal
Power
30 VDC
540 mW
Contact
Current @
16 A
EACH
5.30
Electrical Specifications
c
Operating Time: 12 mS or Less
c
Release Time: 8 mS or Less
c
Operating Temperature: Ð55¡ to +70¡C,
10 Sec. Max.
Electrical Specifications
c
Operating Time: 30 mS or Less
c
Release Time: 8 mS or less
c
Operating Temperature: Ð30¡ to +70¡C
R24 Series Ñ Upright Epoxy Sealed Power Relays
Features
c
High Dielectric Ñ 400 VRMS Between
Control and Switching Circuits
c
Cut-Off Nib After PCB Washing
c
94 V-0 Enclosure
Electrical Specifications
c
Operating Time: 15 mS Approx.
c
Release Time: 10 mS Approx.
c
Switching Rate: 5 Operations Per
Second (Max.)
c
Operating Temperature: Ð40¡ to +70¡C
R25 Series Ñ Upright Epoxy Sealed Power Relays
Features
c
High Dielectric Ñ 400 V
RMS
Between
Control and Switching Circuits
c
Suitable for 5 mm Grid Pattern
c
Immersion Proof
DC Operated
Stock
No.
Mfr.Õs
Type
R25-1D16-12
R25-5D16-12
R25-5D16-48
R25-11D10-5/6
R25-11D10-12
R25-11D10-24
R25-11D10-48
Fig.
G
G
G
G
G
G
G
Nominal
Voltage
12 VDC
12 VDC
48 VDC
5/6 VDC
12 VDC
24 VDC
48 VDC
Contact
Arrangement
SPST-NO
SPDT
SPDT
DPDT
DPDT
DPDT
DPDT
Coil
Res.
½ (Typ.)
270
270
4200
68
270
1100
4200
Max.
Nominal
Power
28 VDC
500 mW
500 mW
500 mW
500 mW
500 mW
500 mW
500 mW
Contact
Current @
16 A
16 A
16 A
10 A
10 A
10 A
10 A
EACH
5.38
5.51
5.51
5.14
5.14
5.71
5.71
Electrical Specifications
c
Operating Time: 8 mS Approx.
c
Release Time: 5 mS Approx.
c
Switching Rate: 20 Operations Per
Second (Max.)
c
Operating Temperature: Ð40¡ to +70¡C
DC Operated
Stock
No.
235-0034
235-0035
235-1028
Mfr.Õs
Type
R24-5D10-12V
R24-5D10-24V
R24-5D10-24FP
Fig.
E
E
F
Nominal
Voltage
12 VDC
24 VDC
24 VDC
Contact
Arrangement
SPDT
SPDT
SPDT
Coil
Res.
½ (Typ.)
230
920
1200
Max.
Nominal
Power
28 VDC
0.6 W
0.6 W
600.0 mW
Contact
Current @
10 A
10 A
10 A
EACH
6.22
5.57
5.38
235-2006
235-2010
235-2012
235-2013
235-2014
235-2015
235-2016
136
b
ALLIED
Call Your Nearest Allied Location (1-800-433-5700) For Quick Service
