Part Number

Search

3812753001

Description
WIRE AND CABLE
CategoryThe connector    Connector bracket
File Size123KB,2 Pages
ManufacturerTE Connectivity
Websitehttp://www.te.com
Download Datasheet Parametric View All

3812753001 Overview

WIRE AND CABLE

3812753001 Parametric

Parameter NameAttribute value
Is it Rohs certified?incompatible
Reach Compliance Codecompliant
Is SamacsysN
Connector bracket typeWIRE AND CABLE
Base Number Matches1
TE Connectivity
 My Cart |
 My Part Lists | Sign In/Register
English
(Change)
What can we help you find?
Products
Industries
Resources
About TE
My Account
Innovation
Support Center
Home > Products > Wire & Cable > Product Feature Selector > Product Details
55A1124­24­0/2­3 Product Details
Spec 44, Spec 55 and Spec RCW Wire and Cable
Not EU RoHS or ELV Compliant
 Share
 Print
 Email
Quick Links
Pricing & Availability
Search for Tooling
Product Feature Selector
Contact Us About This Product
Product Highlights:
Cable Type = Spec 55
Wire Source = United Kingdom
Cable Style = Jacketed, Round­Braid Shielded
Wire Size (AWG/CM) = 24 AWG
Voltage Rating = 600 VAC
55A1124­24­0/2­3

TE Internal Number: 3812753001
View all Features
 Active
Add to My Part List
Request Sample
Find Similar Products
Buy Product
Documentation & Additional Information
Product Drawings:
None Available
Catalog Pages/Data Sheets:
None Available
Product Specifications:
None Available
Application Specifications:
None Available
Instruction Sheets:
None Available
CAD Files:
None Available
Related Products:
Tooling
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
Cable Type = Spec 55
Cable Style = Jacketed, Round­Braid Shielded
Electrical Characteristics:
Voltage Rating (VAC) = 600
Dimensions:
Conductor Outer Diameter (mm [in]) = 0.64 [0.025]
Shield (Screen) Diameter (mm [in]) = 2.34 [0.092]
Body Features:
Wire Size (AWG/CM) = 24 AWG
Cable Jacket Color = Orange
Conductor Type = Silver­Coated High­Strength Copper Alloy
Wire Color = Black, Red
Nominal Outside Diameter (mm [in]) = 2.72 [0.107]
Wire Diameter (mm [in]) = 0.94 [0.037]
Configuration Features:
Number of Conductors = Twisted Pair
Industry Standards:
Government/Industry Qualification = No
RoHS/ELV Compliance = Not ELV/RoHS compliant
Lead Free Solder Processes = Not relevant for lead free process
Conditions for Usage:
Temperature Range (°C) = ­65 – +150
Wire Size ­ Details = 24 AWG 0.24 mm², 0.00037 in², 19 x 36 AWG
Operation/Application:
Application = General Purpose ­ Lightweight
Packaging Features:
Wire Source = United Kingdom
Other:
Brand = Raychem
Comment = 150°C Max Temp. Due To Tin Coated Copper Shield
