3-1437397-1 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The connector> terminals> 3-1437397-1

3-1437397-1: Description25A, STRIP TERMINAL BLOCK, ROHS COMPLIANT; CategoryThe connector terminals; File Size104KB，1 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com; Environmental Compliance

Download Datasheet Parametric View All

3-1437397-1 Overview

25A, STRIP TERMINAL BLOCK, ROHS COMPLIANT

3-1437397-1 Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
package instruction	ROHS COMPLIANT
Reach Compliance Code	compliant
ECCN code	EAR99
Is Samacsys	N
Other features	STANDARD: UL 94V-1, PHENOLIC
Fastening method	SCREW
Manufacturer's serial number	1437397
Rated current	25 A
Rated voltage	600 V
safety certificate	UL
Terminal and terminal strip types	STRIP TERMINAL BLOCK
Wire gauge	8 AWG
Base Number Matches	1

Preview

Download Datasheet

View All

C orporate Hom e

Electronic Components

Se gm e nts

W ho W e Are

My Account

Searc h

Products

Documentation

Resources

My Account

Customer Support

Home

Products

By Type

Terminal Blocks & Strips

Product Feature Selector

> Product Details

358 Product Details

Live Product Chat

Product View

NEMA Terminal Blocks

Always EU R oHS/ELV C om plia nt

(

Sta te m e nt of C om plia nce

)

Quick Links

C heck Pricing & Availability

Search for Tooling

Product Feature Selector

C ontact Us About This Product

358

(3-1437397-1)

T E I nternal N umber: 3 - 1 4 3 7 3 9 7 - 1

Product Highlights:

300 Series Block Series

Terminal Block

Block Type = Fuse

In-Line C ircuit Protection Application

C ontact Type = Strap C lamp

View all Features

A dd to M y P art L is t

Reques t Sample

Find Similar P roduc ts

Active

Buy P roduc t

Documentation & Additional Information

Product Drawings:

None Available

Catalog Pages/Data Sheets:

BUC HANAN TERMINAL BLOC KS C ATALOG - NEMA TERMINAL BLOC KS

(PDF, English)

Product Specifications:

None Available

Application Specifications:

None Available

Instruction Sheets:

None Available

CAD Files:

None Available

List all Documents

Product Features

(Please use the Product Drawing for all design activity)

Product Type Features:

Product Type = Terminal Block

Screw Size = 8-32 Pan Head W/C lamp

Electrical Characteristics:

Voltage Rating (VAC ) = 600

Amperes (Amps.) = 25.0

Body Related Features:

Block Series

= 300 Series

Block Type

= Fuse

Mount Style = Direct Mount (Flat Base)

Wire Range (Solid and Stranded)[MC M] (AWG)

= 18-8

Blown Fuse Indicator

= Without

Blown Fuse Indicator Type

= None

Wire Strip Length (mm [in]) = 12.70 [0.500]

Flammability Rating = UL 94V-1

Contact Related Features:

C ontact Type = Strap C lamp

Pitch (mm [in]) = 19.05 [0.750]

Housing Related Features:

Housing Material

= Phenolic

Industry Standards:

RoHS/ELV C ompliance

= RoHS compliant, ELV compliant

Lead Free Solder Processes

= Not relevant for lead free process

RoHS/ELV C ompliance History = Always was RoHS compliant

Conditions for Usage:

Temperature, Max. (?C ) = 150

Operation/Application:

Application = In-Line C ircuit Protection

Packaging Related Features:

Terminals Per Foot = 16

Other:

Fuse Puller

= With

Brand = Buchanan

Additional Information:

Product Line Information

Additional Product Images:

Line Drawing

Typical Mounting C onfiguration
