B8-4812T15M datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Analog mixed-signal IC> The signal circuit> B8-4812T15M

B8-4812T15M: DescriptionAnalog Circuit, MDIP20,; CategoryAnalog mixed-signal IC The signal circuit; File Size126KB，2 Pages; ManufacturerBOTHHAND; Websitehttp://www.bothhandusa.com/

Download Datasheet Parametric Compare View All

B8-4812T15M Overview

Analog Circuit, MDIP20,

B8-4812T15M Parametric

Parameter Name	Attribute value
Reach Compliance Code	compliant
Is Samacsys	N
Maximum input voltage	75 V
Minimum input voltage	36 V
JESD-30 code	R-MDIP-T20
Number of terminals	20
Maximum operating temperature	70 °C
Minimum operating temperature	-25 °C
Maximum output current	1.5 A
Nominal output voltage	12 V
Package body material	METAL
encapsulated code	DIP
Encapsulate equivalent code	DIP20,1.8
Package shape	RECTANGULAR
Package form	IN-LINE
Certification status	Not Qualified
surface mount	NO
Temperature level	OTHER
Terminal form	THROUGH-HOLE
Terminal pitch	2.54 mm
Terminal location	DUAL
Base Number Matches	1

Preview

Download Datasheet

View All

Series

1. Features :

Wide 2：1 Input Range

Low Ripple and Noise

Input / Output Isolation 1.5K Vdc or 3K Vdc

100 % Burn-In

Input

π-

Filter

Custom Design Available

10 to 15 Watt Isolated DC-DC Converter

Triple Output

2. Absolute maximum ratings：

( Exceeding these values may damage the module.

These are not continuous operating ratings

)

Parameter

Input

Absolute

Voltage Range

Condition

12V Input Model

24V Input Model

48V Input Model

Output Short circuit duration

Reverse Polarity Input current Limit

Operating temperature *

Storage temperature

Nominal Input Range

---

Output Full Load

Min.

-0.7

Typ.

Max.

22.5

Vdc

Unit

Indefinite & Auto-Restart

---

-25

-55

---

+71

+105

℃

To be measured at case plate temperature.

3. Nominal Input / Output Electrical Specifications :

( Specifications typical at Ta = +25℃, nominal input voltage, rated output current unless otherwise noted )

Parameter

Input Voltage Range

Condition

12V Input Model

24V Input Model

48V Input Model

Line Regulation

Load Regulation

Output Voltage Accuracy

Output Voltage Balance

Switching Frequency

Temperature Coefficient

Isolation Voltage

Isolation Resistance

Isolation Capacitance

Standard Series

High Isolation Series

500 Vdc

1 KHz / 250 mV rms

Output full Load

Single Output Model

Triple Output Model

Nominal Input

Dual Output at same Load

Nominal Input

---

1500

3000

1000

---

± 1.0

---

250

± 0.01

---

1000

Min.

---

Typ.

---

Max.

± 0.5

±2

± 2.0

± 1.0

---

± 0.02

---

MΩ

KHz

℃

Vdc

Unit

Tel：886-3-2122268

Fax：886-3-2122258

E-mail：sales@bothhand.com.tw

http://www.bothhand.com.tw

B8-4812T15M Related Products

	B8-4812T15M	B8-1212T15M	B8-2412T15M	B8-2412T10M	B8-4812T10M
Description	Analog Circuit, MDIP20,	Analog Circuit, MDIP20,	Analog Circuit, MDIP20,	Analog Circuit, MDIP20,	Analog Circuit, MDIP20,
Reach Compliance Code	compliant	compliant	compliant	compliant	compliant
Maximum input voltage	75 V	18 V	36 V	36 V	75 V
Minimum input voltage	36 V	9 V	18 V	18 V	36 V
JESD-30 code	R-MDIP-T20	R-MDIP-T20	R-MDIP-T20	R-MDIP-T20	R-MDIP-T20
Number of terminals	20	20	20	20	20
Maximum operating temperature	70 °C	70 °C	70 °C	70 °C	70 °C
Minimum operating temperature	-25 °C	-25 °C	-25 °C	-25 °C	-25 °C
Maximum output current	1.5 A	1.5 A	1.5 A	1 A	1 A
Nominal output voltage	12 V	12 V	12 V	12 V	12 V
Package body material	METAL	METAL	METAL	METAL	METAL
encapsulated code	DIP	DIP	DIP	DIP	DIP
Encapsulate equivalent code	DIP20,1.8	DIP20,1.8	DIP20,1.8	DIP20,1.8	DIP20,1.8
Package shape	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR
Package form	IN-LINE	IN-LINE	IN-LINE	IN-LINE	IN-LINE
Certification status	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified
surface mount	NO	NO	NO	NO	NO
Temperature level	OTHER	OTHER	OTHER	OTHER	OTHER
Terminal form	THROUGH-HOLE	THROUGH-HOLE	THROUGH-HOLE	THROUGH-HOLE	THROUGH-HOLE
Terminal pitch	2.54 mm	2.54 mm	2.54 mm	2.54 mm	2.54 mm
Terminal location	DUAL	DUAL	DUAL	DUAL	DUAL
Base Number Matches	1	1	1	1	1
Is Samacsys	N	N	N	-	-
