V23026A1007B201 Product Details
Communications/Signal PC Board Relays
C onve rte d to EU R oHS/ELV C om plia nt
(
Sta te m e nt of C om plia nce
)
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
V23026A1007B201
(1-1393774-8)
T E I nternal N umber: 1 - 1 3 9 3 7 7 4 - 8
Product Highlights:
l
V23026 / P1 Relay Series
l
DC Actuating System
l
Input Voltage = 1.5 VDC
l
C ontact Arrangement = 1 Form C , SPDT, 1 C /O
l
C ontact C urrent Rating = 1 Amps.
View all Features
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Active
Buy P roduc t
Documentation & Additional Information
Product Drawings:
l
None Available
Catalog Pages/Data Sheets:
l
None Available
Product Specifications:
l
None Available
Application Specifications:
l
None Available
Instruction Sheets:
l
None Available
CAD Files:
l
None Available
Additional Information:
l
Product Line Information
Additional Product Images:
l
Product Photo
l
Schematic
l
PC B Layout
l
Wiring Diagram
Related Products:
l
Tooling
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Termination Type = Through Hole
Electrical Characteristics:
l
Actuating System = DC
l
Input Voltage (VDC ) = 1.5
l
C ontact C urrent Rating (Amps.) = 1
l
C oil Resistance (?)
= 36
l
C oil Power, Nominal (mW) = 63
l
Dielectric Between C oil and C ontacts (V rms) = 1500
Body Related Features:
l
Series
= V23026 / P1 Relay
l
Polarized = Yes
Contact Related Features:
l
Mounting Options = PC Board
l
Enclosure = Immersion C leanable
l
FC C Part 68 Isolation
= Yes
l
Approved Standards = C SA C ertified, UL Recognized
l
C ontact Base Material = Palladium-Nickel, Gold Overlay, Rhodium
Flash
l
Approx. Dimensions (L x W x H) (mm [in]) = 13.00 x 7.60 x 6.90
[.512 x .299 x .271]
l
C ontact Type = Bifurcated
l
Pin C onfiguration = DIP
Configuration Related Features:
l
C ontact Arrangement
= 1 Form C , SPDT, 1 C /O
l
C oil Magnetic System
= Polarized, Monostable
l
C oil Suppression Diode = Without
Industry Standards:
l
RoHS/ELV C ompliance
= RoHS compliant, ELV compliant
l
Lead Free Solder Processes
= Wave solder capable to 240?C , Wave
solder capable to 260?C , Wave solder capable to 265?C
l
RoHS/ELV C ompliance History = C onverted to comply with RoHS
directive
Other:
l
Brand = Axicom
