3-1423393-2

Description
ON-DELAY RELAY, 4PDT, MOMENTARY, 10A (CONTACT), 4-120s, SOCKET MOUNT
CategoryMechanical and electronic products    relay
File Size99KB,1 Pages
ManufacturerTE Connectivity
Websitehttp://www.te.com
Download Datasheet Parametric View All

3-1423393-2 Overview

ON-DELAY RELAY, 4PDT, MOMENTARY, 10A (CONTACT), 4-120s, SOCKET MOUNT

3-1423393-2 Parametric

Parameter NameAttribute value
Is it Rohs certified?incompatible
Reach Compliance Codecompliant
ECCN codeEAR99
Is SamacsysN
Maximum adjustable time delay120 s
Minimum adjustable time delay4 s
body width45 mm
body height109 mm
Body length or diameter45 mm
Maximum coil voltage (AC)120 V
Maximum contact current (AC)10 A
Maximum contact current (DC)10 A
Contact/Output Power TypeAC/DC
Manufacturer's serial number1423393
Installation featuresSOCKET MOUNT
Maximum operating temperature50 °C
Minimum operating temperature
physical size45mm x 45mm x 109mm
GuidelineCSA; UL
Relay actionMOMENTARY
Relay function4PDT
Relay typeON-DELAY RELAY
surface mountNO
Termination typeSNAP-ON
Base Number Matches1
My Account
Tyco Electronics
(C hange)
Se a rch by Ke yword or Pa rt #
Products
Documentation
Resources
My Account
Customer Support
Home
>
Products
>
By Type
>
Relays
>
Product Feature Selector
> Product Details
TR14I3E Product Details
Time Delay Relays
Not re vie we d for R oHS C om plia nce
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
TR14I3E
(3-1423393-2)
T E I nternal N umber: 3 - 1 4 2 3 3 9 3 - 2
Product Highlights:
l
TR - C ontrol Relay - Timing Version Series
l
Input Voltage = 120 VAC
l
C ontact Arrangement = 4 Form C , 4PDT, 4 C /O
l
C ontact Rating = 10A
l
Mounting Options = Socket
View all Features
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Active
Buy P roduc t
Documentation & Additional Information
Product Drawings:
l
None Available
Catalog Pages/Data Sheets:
l
None Available
Product Specifications:
l
None Available
Application Specifications:
l
None Available
Instruction Sheets:
l
None Available
CAD Files:
l
None Available
Additional Information:
l
Product Line Information
Additional Product Images:
l
Wiring Diagram
Related Products:
l
Tooling
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Termination Type = 16 Flat Base Pins
l
Magnetic Blow-Out Device = Without
Electrical Characteristics:
l
Input Voltage (VAC ) = 120
l
C ontact Rating = 10A
Body Related Features:
l
Series = TR - C ontrol Relay - Timing Version
Contact Related Features:
l
Mounting Options = Socket
l
Mode of Operation = Delay on Energization
l
Delay Time = 4 seconds to 120 seconds
l
Type of C ontrol = Potentiometer Adjustable
l
Repeatability, Max. = ? 2%
l
Approved Standards = C SA C ertified, UL Listed
l
C ontact Base Material = Silver Plated
l
Approx. Dimensions (L x W x H) (mm [in]) = 45.00 x 45.00 x 109.00
[1.773 x 1.773 x 4.294]
Configuration Related Features:
l
C ontact Arrangement
= 4 Form C , 4PDT, 4 C /O
l
Multiple Timing Ranges = Without
Industry Standards:
l
RoHS/ELV C ompliance
= Not reviewed for ELV/RoHS compliance
l
Lead Free Solder Processes
= Not reviewed for lead free solder
process
Conditions for Usage:
l
Temperature Range (?C ) = 0 – 50
Other:
l
Brand = Agastat
