3-1423393-8: DescriptionON-DELAY RELAY, 4PDT, MOMENTARY, 10A (CONTACT), 600-1800s, SOCKET MOUNT; CategoryMechanical and electronic products relay; File Size123KB，2 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com

Download Datasheet Parametric View All

3-1423393-8 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	3-1423393-8	-	-	View	Buy Now

3-1423393-8 Overview

ON-DELAY RELAY, 4PDT, MOMENTARY, 10A (CONTACT), 600-1800s, SOCKET MOUNT

3-1423393-8 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Reach Compliance Code	compliant
ECCN code	EAR99
Factory Lead Time	18 weeks 1 day
Is Samacsys	N
Maximum adjustable time delay	1800 s
Minimum adjustable time delay	600 s
body width	45 mm
body height	109 mm
Body length or diameter	45 mm
Maximum coil voltage (AC)	120 V
Maximum contact current (AC)	10 A
Maximum contact current (DC)	10 A
Contact/Output Power Type	AC/DC
Installation features	SOCKET MOUNT
Maximum operating temperature	50 °C
Minimum operating temperature
physical size	45mm x 45mm x 109mm
Guideline	CSA; UL
Relay action	MOMENTARY
Relay function	4PDT
Relay type	ON-DELAY RELAY
surface mount	NO
Termination type	SNAP-ON
Base Number Matches	1

Preview

Download Datasheet

View All

TE Connectivity

My Cart |

My Part Lists | Sign In/Register

English

(Change)

What can we help you find?

Products

Industries

Resources

About TE

My Account

Innovation

Support Center

Home > Products > Relays > Product Feature Selector > Product Details

TR14I3NN Product Details
