3-1618058-1

Description
POWER/SIGNAL RELAY, DPDT, MOMENTARY, 200VDC (COIL), 5A (CONTACT), 30VDC (CONTACT)
CategoryMechanical and electronic products    relay
File Size103KB,1 Pages
ManufacturerTE Connectivity
Websitehttp://www.te.com
Download Datasheet Parametric View All

3-1618058-1 Overview

POWER/SIGNAL RELAY, DPDT, MOMENTARY, 200VDC (COIL), 5A (CONTACT), 30VDC (CONTACT)

3-1618058-1 Parametric

Parameter NameAttribute value
Is it lead-free?Contains lead
Is it Rohs certified?incompatible
Objectid1667238154
Reach Compliance Codeunknown
ECCN codeEAR99
Maximum coil voltage (AC)140 V
Maximum coil voltage (DC)200 V
Coil/Input Power TypeAC/DC
Contact (AC) maximum rated R load5A@240VAC
Maximum contact current (AC)5 A
Maximum contact current (DC)5 A
Contact (DC) maximum rated R load5A@30VDC
Maximum contact voltage (AC)240 V
Maximum contact voltage (DC)30 V
Contact/Output Power TypeAC/DC
Installation featuresDIN-RAIL MOUNT
Maximum operating temperature60 °C
Minimum operating temperature-40 °C
Relay actionMOMENTARY
Relay style1 FORM C
Relay functionSPDT
Relay typePOWER/SIGNAL RELAY
surface mountNO
Termination typeSOLDER/QUICK CONNECT
My Account
Tyco Electronics
(C hange)
Se a rch by Ke yword or Pa rt #
Products
Documentation
Resources
My Account
Customer Support
Home
>
Products
>
By Type
>
Relays
>
Product Feature Selector
> Product Details
WD5051-3-003 Product Details
Sensors & Protective Relays
Not EU R oHS or ELV C om plia nt
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
WD5051-3-003
(3-1618058-1)
T E I nternal N umber: 3 - 1 6 1 8 0 5 8 - 1
Product Highlights:
l
Relay Type = Protective Relay
l
WD5051 Series
l
AC /DC Actuating System
l
Input Voltage = 100 - 140 VAC
l
Input Voltage = 100 - 200 VDC
View all Features
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Active
Buy P roduc t
Documentation & Additional Information
Product Drawings:
l
None Available
Catalog Pages/Data Sheets:
l
None Available
Product Specifications:
l
None Available
Application Specifications:
l
None Available
Instruction Sheets:
l
None Available
CAD Files:
l
None Available
Additional Information:
l
Product Line Information
Additional Product Images:
l
Dimensional Drawing
l
Terminal Assignment
Related Products:
l
Tooling
Product Features
(Please use the Product Drawing for all design activity)
Electrical Characteristics:
l
Actuating System
= AC /DC
l
Input Voltage (VAC ) = 100 – 140
l
Input Voltage (VDC ) = 100 – 200
l
Phase
= Three
l
C ontact Rating = 5A Resistive @ 240 VAC or 30 VDC
Body Related Features:
l
Series
= WD5051
Contact Related Features:
l
Relay Type
= Protective Relay
Configuration Related Features:
l
C ontact Arrangement
= 2 Form C , DPDT, 2 C /O
l
C ontact Arrangement, Additional Output
= None
Industry Standards:
l
RoHS/ELV C ompliance
= Not ELV/RoHS compliant
l
Lead Free Solder Processes
= Not relevant for lead free process
Operation/Application:
l
Protection Function
= Overcurrent
l
Time Delay
= Without
Other:
l
Brand = C II
