1437590-2 Overview

DIP Switch, SLIDE DIP SWITCH-4SWITCHES, SPST, LATCHED,0.02A, 20VDC, THROUGH HOLE-STRAIGHT

1437590-2 Parametric

Parameter Name	Attribute value
Brand Name	Alcoswitch
Reach Compliance Code	unknown
ECCN code	EAR99
Other features	LOW PROFILE
body width	5.16 mm
body height	4.3 mm
Body length or diameter	11.12 mm
Maximum contact current (DC)	0.02 A
Contact (DC) maximum rated R load	.02A@20VDC
Maximum contact voltage (DC)	20 V
Electrical life	1000 Cycle(s)
JESD-609 code	e0
Manufacturer's serial number	1437590
Installation features	THROUGH HOLE-STRAIGHT
Number of switching segments	4
Maximum operating temperature	85 °C
Minimum operating temperature	-30 °C
seal	TAPE SEALED
surface mount	NO
Switch action	LATCHED
switch function	SPST
Switch type	SLIDE DIP SWITCH
Terminal surface	TIN LEAD
Termination type	SOLDER
Base Number Matches	1

Preview

Download Datasheet

View All

C orporate Hom e

|

Electronic Components

|

Se gm e nts

|

W ho W e Are

My Account

Searc h

Products

Documentation

Resources

My Account

Customer Support

Home

>

Products

>

By Type

>

Switches

>

Product Feature Selector

> Product Details

GDB04 Product Details

Live Product Chat

Product Photo

DIP, Rotary DIP, SIP Switches and DIP Shunts - Standard

Not EU R oHS or ELV C om plia nt

Quick Links

C heck Pricing & Availability

Search for Tooling

Product Feature Selector

C ontact Us About This Product

GDB04

(1437590-2)

T E I nternal N umber: 1 4 3 7 5 9 0 - 2

Product Highlights:

l

DIP Switch

l

PC B Mount Style = Through Hole

l

Single Pole - Single Throw C onfiguration (Pole-Throw)

l

Actuator Style = Flush, Rocker (Top Actuated)

l

Sealed

View all Features

Obsolete

C ontact Product Information C enter

A dd to M y P art L is t

Reques t Sample

Find Similar P roduc ts

Buy P roduc t

Documentation & Additional Information

Product Drawings:

l

None Available

Catalog Pages/Data Sheets:

l

ALC OSWITC H PRODUC TS

(PDF, English)

Product Specifications:

l

None Available

Application Specifications:

l

None Available

Instruction Sheets:

l

None Available

CAD Files:

l

None Available

List all Documents

Product Features

(Please use the Product Drawing for all design activity)

Product Type Features:

l

Product Type = DIP Switch

l

PC B Mount Style = Through Hole

l

C onfiguration (Pole-Throw)

= Single Pole - Single Throw

l

Actuator Style

= Flush, Rocker (Top Actuated)

l

Sealed = Yes

l

Number of Switches

= 4

Termination Related Features:

l

Seal Type = Tape

Body Related Features:

l

Series = GD

l

C enterline (mm [in]) = 2.54 [0.100]

l

Length (mm [in]) = 11.12 [0.438]

Contact Related Features:

l

Auto-Insertable = Yes

l

C ontact Base Material = C opper Alloy

l

C ontact Mating Area Plating Material = Gold

Housing Related Features:

l

Housing C olor = Black

l

Housing Material = PPS

l

Housing Flammability Rating = UL 94V-0

Industry Standards:

l

RoHS/ELV C ompliance

= Not ELV/RoHS compliant

l

Lead Free Solder Processes

= Wave solder capable to 240?C

Other:

l

Brand = Alcoswitch

Additional Information:

l

Product Line Information

1437590-2 Related Products

	1437590-2	GDB04
Description	DIP Switch, SLIDE DIP SWITCH-4SWITCHES, SPST, LATCHED,0.02A, 20VDC, THROUGH HOLE-STRAIGHT	ROCKER SWITCH,STRAIGHT,SP4T,PC TAIL TERMINAL,ROCKER
Brand Name	Alcoswitch	Alcoswitch
Reach Compliance Code	unknown	unknown
body width	5.16 mm	9.6012 mm
body height	4.3 mm	8.1534 mm
Body length or diameter	11.12 mm	11.1252 mm
Manufacturer's serial number	1437590	GD
Installation features	THROUGH HOLE-STRAIGHT	THROUGH HOLE-STRAIGHT
surface mount	NO	NO
Switch action	LATCHED	MAINTAINED
switch function	SPST	SP4T
Switch type	SLIDE DIP SWITCH	ROCKER SWITCH
Termination type	SOLDER	SOLDER
