3-1437565-1: DescriptionPUSHBUTTON SWITCH, SPST, MOMENTARY-TACTILE, 0.05A, THROUGH HOLE-STRAIGHT, ROHS COMPLIANT; CategoryMechanical and electronic products switch; File Size104KB，1 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com; Environmental Compliance

Download Datasheet Parametric View All

3-1437565-1 Overview

PUSHBUTTON SWITCH, SPST, MOMENTARY-TACTILE, 0.05A, THROUGH HOLE-STRAIGHT, ROHS COMPLIANT

3-1437565-1 Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
package instruction	ROHS COMPLIANT
Reach Compliance Code	compliant
ECCN code	EAR99
Factory Lead Time	9 weeks
Actuator color	BLACK
Actuator length	0.152 inch
Actuator material	POLYBUTYLENE TEREPHTHALATE
Actuator stroke	0.254 mm
Actuator type	ROUND/EXTENDED TYPE
body width	22.606 mm
Body color	BLACK
body height	10.541 mm
Body length or diameter	8.4074 mm
center contact material	COPPER ALLOY
Center contact plating	SILVER
Maximum contact current (AC)	0.05 A
Maximum contact current (DC)	0.05 A
Contact (DC) maximum rated R load	0.05A@24VDC
Contact function	OFF-(ON)
Contact resistance	0.1 mΩ
Maximum contact voltage (DC)	24 V
Dielectric withstand voltage	250VAC V
Electrical life	100000 Cycle(s)
Shell material	STEEL
Insulation resistance	100000000 Ω
insulator material	POLYBUTYLENE TEREPHTHALATE
Installation features	THROUGH HOLE-STRAIGHT
Maximum operating force	1.57 N
Maximum operating temperature	85 °C
Minimum operating temperature	-35 °C
PCB hole count	8
method of packing	BULK
Solderability	WAVE
surface mount	NO
Switch action	MOMENTARY-TACTILE
switch function	SPST
Switch type	PUSHBUTTON SWITCH
Terminal length	0.138 inch
Terminal material	COPPER ALLOY
Termination type	SOLDER
Base Number Matches	1

Preview

Download Datasheet

View All

My Account

Tyco Electronics

(C hange)

Se a rch by Ke yword or Pa rt #

Products

Documentation

Resources

My Account

Customer Support

Home

Products

By Type

Switches

Product Feature Selector

> Product Details

FSM2RA2J Product Details

Live Product Chat

Pushbutton Switches

Always EU R oHS/ELV C om plia nt

(

Sta te m e nt of C om plia nce

)

Quick Links

C heck Pricing & Availability

Search for Tooling

Product Feature Selector

C ontact Us About This Product

FSM2RA2J

(3-1437565-1)

T E I nternal N umber: 3 - 1 4 3 7 5 6 5 - 1

Product Highlights:

Switch - Mechanical

Tactile

Single Pole - Single Throw C onfiguration (Pole-Throw)

C ontact Rating = 50mA

Operating Function = Off [On]

View all Features

A dd to M y P art L is t

Reques t Sample

Find Similar P roduc ts

Active

Buy P roduc t

Documentation & Additional Information

Product Drawings:

None Available

Catalog Pages/Data Sheets:

None Available

Product Specifications:

None Available

Application Specifications:

None Available

Instruction Sheets:

None Available

CAD Files:

None Available

Additional Information:

Product Line Information
