Miniature Relays Series M
Type MZ 2 poles 10A
Monostable
•
•
•
•
•
•
•
•
•
Miniature size
PCB mounting
Reinforced insulation 4 kV / 8 mm
Switching capacity 10 A
DC coils 1.87 to 160 VDC
AC coils 4.8 to 264 VAC
General purpose, industrial electronics
Types: Standard, flux-free or sealed
Switching AC/DC load
MZP
Product Description
H:
Sealed with inert gas
Sealing
according to IP 67,suita-
P:
Standard,suitable for sol
ble for automatic solde
dering and manual washing.
ring and/or partial immer-
F:
Flux-free, suitable for auto-
sion or spray washing.
matic soldering and partial
immersion or spray
washing.
Ordering Key
Type
Sealing
Version (A = Standard)
Contact code
Coil reference number
Contact rating
MZ P A 200 47 10
For
General data,
notes and special versions see page
48
Version
A = 5.0 mm / Ag CdO (standard)
C = 5.0 mm / hard gold plated
D = 5.0 mm / flash gilded
S = 5.0 mm / Ag Sn 0
2
Available only on request Ag Ni
Type Selection
Contact configuration
2 normally open contact
2 normally closed contact
2 change over contact
(DPST -NO {2-form A})
(DPST -NC {2-form B})
DPDT {2-form C})
Contact rating
10 A
10 A
10 A
Contact code
200
020
002
Coil Characteristics DC
Coil
reference
number
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
(20°C)
Winding resistance
Ω
11
30
55
110
170
280
450
720
860
1150
1750
2700
4300
6450
9900
12550
16200
23500
Rated Voltage
200/002
020
VDC
VDC
2.6
4.3
5.9
8.5
10.5
13.0
17.0
21.5
23.5
27.0
34.5
42.5
54.5
68.0
87.5
101.0
115.0
132.0
2.5
4.1
5.6
8.0
10.0
12.5
16.0
20.5
22.5
26.0
32.5
40.5
51.5
64.5
83.0
95.0
109.0
125.0
±%
10
10
10
10
10
10
10
15
15
15
15
15
15
15
15
15
15
15
Operating range
Min. VDC
Max.VDC
200/002
020
1.98
3.30
4.52
6.49
7.99
9.98
13.0
16.3
18.0
20.7
26.2
32.6
41.8
52.0
67.2
77.0
87.9
101.0
1.87
3.13
4.28
6.14
7.56
9.49
12.30
15.50
17.10
19.70
24.90
30.90
39.60
49.20
63.60
73.00
83.30
96.00
3.50
5.75
7.80
11.00
13.70
17.60
22.50
28.60
30.80
35.70
44.00
55;00
69.30
84.70
104.00
117.00
136.00
160.00
Must release
VDC
≥
5% of
rated voltage
46
Specifications are subject to change without notice
046/47-MZ 2P 10A eng
2-03-2001
11:49
Pagina 47
Miniature Relays Series M
Type MZ 2poles 10A
Monostable
Coil Characteristics AC
Coil
ref. no.
90
91
92
93
94
95
96
97
(20°C)
Inductance
H
0.059
0.267
1.123
4.170
6.450
22.400
100.200
107.800
Must release Rated Current (mA)
Rated Voltage Winding resistance
Operating range
VAC
VAC
50Hz
60Hz
Ω
±%
min. VAC Max. VAC
6
12
24
48
60
110
220
240
12
56
230
870
1500
5300
20000
25000
10
10
10
15
15
15
15
15
4.8
9.6
19.2
38.4
48.0
88.0
176.0
192.0
6.6
13.2
26.4
52.8
66.0
129.0
242.0
264.0
270.0
119.0
57.0
30.5
23.8
12.3
5.9
5.7
237.0
104.0
50.0
26.7
21.0
10.8
5.2
5.0
≥
15% of
rated voltage
Contact Characteristics
Rating
Material
(standard version)
2)
Current
(at 250VAC)
Rated current
Max. switching current
Overload current
(4sec ON / 40sec OFF cycle)
Voltage
Rated voltage
Max.switching voltage
(VDE 0435)
2) 3)
10 A
AgCdO
10 A
12 A
14 A
Power
Max. switching power with
resistive load in AC
3)
Max. switching power in DC
Minimum switching current
2)
(typical value)
Life
(see diagram 1)
Typical electrical life at max.
resistive load
1000 cycles/h
500 cycles/h
Max.electrical repetition rate
Mech. life at 18000 cycles/h
2500 VA
see diagram 3
100mA at 24VDC
250 VAC
380 VAC
7.5 x 10 cycles
8 x 10 cycles
3600 cycles/h
50 x 10 cycles
4
6
4
See pag. 48
Dimensions
MZP...200/020/002 10A
h
Pin View
200
020
002
Wiring Diagrams
200
020
002
h’
MZP:
h = 25,2 mm
h’= 4,3 - 5,3 mm
MZF/MZH: h = 26.5 mm
h’= 2.8 - 3.8 mm
Diagrams
1 Expected life at 250 VAC
(Resistive loads and repetition
rate 1000 cycles/h)
2 Reduction of expected life
against load power factor cos
ϕ
3 Max. switching power DC
I
(Ampere) DC
Load power factor
V
(Volt) DC
47
Specifications are subject to change without notice
Specifications are subject to change without notice
47
