126-165.000MHZ-DE0 datasheet, PDF

Datasheet> All Categories > Passive components> oscillator> 126-165.000MHZ-DE0

126-165.000MHZ-DE0: DescriptionHCMOS Output Clock Oscillator, 165MHz Nom, ROHS COMPLIANT, SMD, 4 PIN; CategoryPassive components oscillator; File Size178KB，2 Pages; ManufacturerFOX [Fox Electronics]; Environmental Compliance

Download Datasheet Parametric View All

126-165.000MHZ-DE0 Overview

HCMOS Output Clock Oscillator, 165MHz Nom, ROHS COMPLIANT, SMD, 4 PIN

126-165.000MHZ-DE0 Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
package instruction	ROHS COMPLIANT, SMD, 4 PIN
Reach Compliance Code	compliant
ECCN code	EAR99
Other features	ENABLE/DISABLE FUNCTION; TAPE AND REEL
maximum descent time	6 ns
Frequency Adjustment - Mechanical	NO
frequency stability	25%
JESD-609 code	e4
Installation features	SURFACE MOUNT
Nominal operating frequency	165 MHz
Maximum operating temperature	70 °C
Minimum operating temperature	-10 °C
Oscillator type	HCMOS
Output load	15 pF
physical size	7.5mm x 5.2mm x 1.5mm
longest rise time	6 ns
Maximum supply voltage	3.63 V
Minimum supply voltage	2.97 V
Nominal supply voltage	3.3 V
surface mount	YES
maximum symmetry	60/40 %
Terminal surface	Gold (Au)
Base Number Matches	1

Preview

Download Datasheet

View All

3.3V, HcMOs, sMD Oscillator

Model: F4100 sERiEs

Page 1 of 2

RoHs compliant / Pb Free

Rev. 2/26/2008

http://www.foxonline.com/need_a_sample.htm

• PARt nuMbER sElEctiOn

Learn More - Internet Required

Part Number

116-Frequency-xxxxx

117-Frequency-xxxxx

124-Frequency-xxxxx

125-Frequency-xxxxx

126-Frequency-xxxxx

127-Frequency-xxxxx

128-Frequency-xxxxx

Model Frequency

Number Stability

F4100

±100PPM

F4100R

±100PPM

F4105

±50PPM

F4105R

±50PPM

F4106

±25PPM

F4106R

±25PPM*

F4108

±20PPM*

Operating

Temperature (ºC)

-10 ~ +70

-40 ~ +85

-10 ~ +70

-40 ~ +85

-10 ~ +70

-40 ~ +85

-10 ~ +70

Frequency

Range (MHz)

0.012 ~ 170.000

0.012 ~ 165.000

0.012 ~ 156.520

0.012 ~ 162.000

Why XpressO?

Lower Cost, Faster Delivery, Low Jitter!

XpressO

Equivalent

FXO-HC73

• ElEctRicAl cHARActERistics

PARAMETERS

Frequency Range (F

)

Storage Temperature Range (T

stg

)

Supply Voltage (V

)

Input Current

)

0.012 ~ 0.040 MHz

0.040+ ~ 1.500 MHz

1.500+ ~ 32.000 MHz

32.000+ ~ 50.000 MHz

50.000+ ~ 67.000 MHz

67.000+ ~ 170.000 MHz

Output Symmetry (50% V

)

0.012 ~ 50.000 MHz

50.000+ ~ 170.000 MHz

Rise Time (10% ~ 90% V

) (T

)

0.012 ~ 80.000 MHz

80.000+ ~ 125.000 MHz

125.000+ ~ 170.000 MHz

Fall Time (90% ~ 10% V

) (T

)

0.012 ~ 80.000 MHz

80.000+ ~ 125.000 MHz

125.000+ ~ 170.000 MHz

Output Voltage

)

Output Current

)

Output Load

(HCMOS)

Standby Current

Start-up Time

)

0.012 ~ 32.000 MHz

32.000+ ~ 170.000 MHz

Output Disable Time

Output Enable Time

0.012 ~ 32.000 MHz

32.000+ ~ 170.000 MHz

Jitter

12kHz ~ 20MHz

RMS Period

Cycle-to-Cycle

MAX

(unless otherwise noted)

0.012 ~ 170.000 MHz

-55ºC ~ +125ºC

3.3V ± 10%

3mA

6mA

15mA

20mA

25mA

40mA

45% ~ 55%

40% ~ 60%

6nS

4nS

3nS

6nS

4nS

3nS

10% V

90% V

Min

2mA Min

-2mA Min

15pF

10µA

5mS

10mS

150nS

5mS

10mS

0.3pS Typ.

2.5pS Typ.

20pS Typ.

Top

View

7 .5 M ax

Dot denotes

pin 1

5 .2 M ax

1 .5 M ax

1 .4 ±0.2

Bottom

View

5 .0 8 ±0.1

2 .6 ±0.2

Recommended

Solder Pad Layout

1 .8 ±0.1

2 .0 ±0.1

4 .2 ±0.1

5 .0 8 ±0.1

Pin Connections

# 1 E /D

#3 O u tp u t

# 2 G N D #4 V

A ll d im e n sio n s a re in m illim eters

Inclusive of 25ºC tolerance, operating temperature range, input voltage change, load change, aging,

shock, and vibration. *Excludes Shock/Vibration

An internal pullup resistor from pin 1 to pin 4 allows active output if pin 1 is left open.

Note: A 0.01µF bypass capacitor should be placed between VDD (Pin 4) and GND (Pin 2) to

minimize power supply line noise. Drawing is for reference to critical specifications defined by

size measurements.

Certain non-critical visual attributes, such as side castellations, reference pin shape, etc. may vary.

All specifications subject to change without notice.

• EnAblE / DisAblE FunctiOn

INH (Pin 1)

UTPUT (Pin 3)

OPEN

ACTIVE

'1' Level V

≥ 70% V

ACTIVE

'0' Level V

≤ 30% V

High Z

FOXElectronics

5570 Enterprise Parkway Fort Myers, Florida 33905 USA +1.239.693.0099 FAX +1.239.693.1554

http://www.foxonline.com

EMEA

Tel/Fax: +44 .1767.312632 |

Asia

Hong Kong Tel: +852.2854.4285 Fax +852.2854.4282

Japan

Tel: +81.3.3374/2079 Fax: +81.3.3374.5221
