Directional Coupler
50Ω
Up to 5W
800 to 1000 MHz
Features
-55°C to 100°C
-55°C to 100°C
1.5A
DC Pass
ZADC-10-10
Maximum Ratings
Operating Temperature
Storage Temperature
DC Current
Permanent damage may occur if any of these limits are exceeded.
• excellent mainline loss, 0.85 dB typ.
• excellent VSWR, 1.16 typ.
• power input up to 5W max.
• DC Current through input to ouput 1.5A Max.
SMA version shown
CASE STYLE: CC51-1
Connectors Model
SMA
ZADC-10-10-S
N-TYPE
ZADC-10-10-N
Price
Qty.
$49.95 ea. (1-9)
$49.95 ea. (1-9)
Applications
• GSM
• instrumentation
• cellular
Coaxial Connections
INPUT
OUTPUT
COUPLED
1
3
2
Directional Coupler Electrical Specifications
Outline Drawing
FREQ.
RANGE
(MHz)
f
L
-f
U
800-1000
COUPLING
(dB)
MAINLINE LOSS
1
(dB)
DIRECTIVITY
(dB)
VSWR
(:1)
POWER
INPUT
(W)
Max.
5
Nom.
10±0.6
Flatness
±1.0
Typ.
Max.
0.85
1.2
Typ.
22
Min.
17
Typ.
1.16
1. Mainline loss includes theoretical power loss at coupled port.
Typical Performance Data
Frequency
(MHz)
753.33
880.00
897.00
914.00
931.00
948.00
965.00
976.66
988.33
1000.00
Mainline Loss
(dB)
In-Out
0.65
0.87
0.85
0.86
0.90
0.92
0.97
0.99
0.98
0.99
ZADC-10-10
MAINLINE LOSS
Coupling
(dB)
In-Cpl
11.00
10.15
10.00
9.87
9.81
9.72
9.67
9.63
9.55
9.44
Directivity
(dB)
20.74
22.13
22.36
22.63
22.90
23.19
23.49
23.75
23.99
24.34
In
24.50
23.48
23.28
23.06
22.85
22.64
22.41
22.25
22.07
21.86
Return Loss
(dB)
Out
24.59
23.83
23.66
23.49
23.33
23.16
22.97
22.84
22.67
22.48
Cpl
37.50
31.50
30.66
29.86
29.13
28.46
27.89
27.53
27.18
26.85
Outline Dimensions (
inch
)
mm
A
2.00
50.80
G
.125
3.18
B
2.00
50.80
H
.38
9.65
C
.75
19.05
J
1.00
25.40
D
.938
23.83
K
1.25
31.75
E
.13
3.30
F
1.750
44.45
wt
grams
145.0
2.0
MAINLINE LOSS (dB)
at RF level of -10 dBm
ZADC-10-10
COUPLING & DIRECTIVITY
40
COUPLING &
DIRECTIVITY (dB)
at RF level of -10 dBm
1.6
1.2
0.8
0.4
0.0
750
32
24
16
8
0
750
COUPLING
DIRECTIVITY
800
850
900
FREQUENCY (MHz)
ZADC-10-10
RETURN LOSS
950
1000
800
Electrical Schematic
850
900
FREQUENCY (MHz)
950
1000
50
RETURN LOSS (dB)
at RF level of -10 dBm
42
34
26
18
10
750
IN
OUT
CPL
800
ISO 9001 ISO 14001 AS 9100
CERTIFIED
P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661
The Design Engineers Search Engine
IF/RF MICROWAVE COMPONENTS
Mini-Circuits
850
900
FREQUENCY (MHz)
950
1000
®
For detailed performance specs
& shopping online see web site
®
Provides ACTUAL Data Instantly at
minicircuits.com
Notes: 1.
Performance and quality attributes and conditions not expressly stated in this specification sheet are intended to be excluded and do not form a part of this specification sheet.
2.
Electrical specifications
and performance data contained herein are based on Mini-Circuit’s applicable established test performance criteria and measurement instructions.
3.
The parts covered by this specification sheet are subject to
Mini-Circuits standard limited warranty and terms and conditions (collectively, “Standard Terms”); Purchasers of this part are entitled to the rights and benefits contained therein. For a full statement of the Standard
Terms and the exclusive rights and remedies thereunder, please visit Mini-Circuits’ website at www.minicircuits.com/MCLStore/terms.jsp.
REV. D
M119986
ED-6262/2
ZADC-10-10
WZ/TD/CP/AM
120919
