Power Splitter/Combiner
2 Way-0°
Maximum Ratings
Operating Temperature
Storage Temperature
Power Input (as a splitter)
Internal Dissipation
-55°C to 100°C
-55°C to 100°C
10W max.
0.125W max.
Coaxial
ZAPD-20+
50Ω
700 to 2000 MHz
Features
• wideband, 700 to 2000 MHz
• low insertion loss, 0.3 dB typ.
• high isolation, 30 dB typ.
• up to 10W power input as splitter
• excellent amplitude unbalance, 0.1 dB typ.
• excellent phase unbalance, 1 deg. typ.
• excellent VSWR, 1.1:1 typ.
• rugged shielded case
N-Type version shown
CASE STYLE: F53
Connectors Model
Price
N-TYPE
ZAPD-20-N+
$64.95
SMA
ZAPD-20-S+
$64.95
Qty.
(1-9)
(1-9)
Permanent damage may occur if any of these limits are exceeded.
Coaxial Connections
SUM PORT
PORT 1
PORT 2
S
1
2
Applications
+ RoHS compliant in accordance
with EU Directive (2002/95/EC)
The +Suffix has been added in order to identify RoHS
Compliance. See our web site for RoHS Compliance
methodologies and qualifications.
• cellular
• GPS
• PCS/DCS
• instrumentation
FREQ.
RANGE
(MHz)
ISOLATION
(dB)
Electrical Specifications
INSERTION LOSS (dB)
ABOVE 3.0 dB
PHASE
AMPLITUDE
UNBALANCE UNBALANCE
(Degrees)
(dB)
Max.
3
Max.
0.4
VSWR
(:1)
S
OUT
Typ. Max. Typ. Max.
1.15 1.35 1.1
1.3
Outline Drawing
f
L
-f
U
700-2000
Typ. Min.
30
20
Typ. Max.
0.3
0.7
Typical Performance Data
Frequency
(MHz)
Total Loss
(dB)
S-1
700.00
880.00
945.00
1075.00
1140.00
1205.00
1335.00
1435.00
1500.00
1566.00
1697.00
1763.12
1828.75
1960.00
2000.00
3.19
3.17
3.17
3.20
3.22
3.22
3.23
3.22
3.23
3.24
3.26
3.25
3.29
3.26
3.27
1
Amplitude
Unbalance
(dB)
0.04
0.04
0.03
0.05
0.04
0.04
0.04
0.04
0.05
0.06
0.07
0.08
0.07
0.09
0.10
Isolation
(dB)
Phase
Unbalance
(deg.)
0.29
0.50
0.54
0.59
0.61
0.60
0.64
0.53
0.51
0.66
0.71
0.69
0.78
0.94
0.83
VSWR
S
VSWR
1
VSWR
2
S-2
3.23
3.20
3.20
3.25
3.26
3.26
3.27
3.27
3.29
3.31
3.33
3.33
3.36
3.35
3.38
23.74
26.24
25.39
25.29
26.12
27.59
30.97
30.03
28.39
27.16
27.03
28.54
32.04
32.34
28.83
1.23
1.14
1.13
1.18
1.19
1.17
1.13
1.11
1.13
1.14
1.16
1.14
1.13
1.17
1.19
ZAPD-20+
ISOLATION
1.13
1.07
1.08
1.11
1.12
1.11
1.08
1.04
1.02
1.05
1.09
1.10
1.09
1.06
1.04
1.11
1.08
1.10
1.14
1.14
1.14
1.10
1.06
1.02
1.03
1.08
1.08
1.09
1.06
1.05
Outline Dimensions (
inch
)
mm
A
2.00
50.80
H
.39
9.91
B
2.00
50.80
J
1.00
25.40
C
.75
19.05
K
.50
12.70
D
1.00
25.40
L
1.00
25.40
E
.13
3.30
F
1.750
44.45
G
.125
3.18
wt
grams
170.0
ZAPD-20+
TOTAL LOSS
3.5
S-1(dB)
TOTAL LOSS (dB)
3.4
3.3
3.2
3.1
3.0
700
S-2(dB)
1. Total Loss = Insertion Loss + 3dB splitter loss.
35
ISOLATION (dB)
32
29
26
23
20
700
960
1220
1480
1740
2000
960
1220
1480
1740
2000
FREQUENCY (MHz)
FREQUENCY (MHz)
1.5
#S-VSWR
1.4
VSWR
1.3
1.2
1.1
1.0
700
ZAPD-20+
VSWR
#1-VSWR
#2-VSWR
electrical schematic
960
1220
1480
1740
2000
FREQUENCY (MHz)
