Power Splitter/Combiner
2 Way-0°
Maximum Ratings
Operating Temperature
Storage Temperature
Power Input (as a splitter)
Internal Dissipation
-55°C to 100°C
-55°C to 100°C
1W max.
0.125W max.
Coaxial
ZAPD-30+
50Ω
20 to 3000 MHz
Features
• wideband, 20 to 3000 MHz
• excellent amplitude unbalance, 0.1 dB typ.
• excellent phase unbalance, 1 deg. typ.
CASE STYLE: F14
Connectors Model
Price
SMA
ZAPD-30-S+
$84.95
Qty.
(1-9)
Applications
Permanent damage may occur if any of these limits are exceeded.
Coaxial Connections
SUM PORT
PORT 1
PORT 2
S
1
2
• UHF TV/DVT
• aircraft radio navigation
• PCS/cellular/GSM
+ RoHS compliant in accordance
with EU Directive (2002/95/EC)
The +Suffix has been added in order to identify RoHS
Compliance. See our web site for RoHS Compliance
methodologies and qualifications.
Electrical Specifications
FREQ.
RANGE
(MHz)
L
f
L
-f
U
ISOLATION
(dB)
M
U
INSERTION LOSS (dB)
ABOVE 3.0 dB
L
M
U
PHASE
AMPLITUDE
UNBALANCE UNBALANCE
(Degrees)
(dB)
L
M
U
L
M
U
S
VSWR
(:1)
OUT
Typ. Min. Typ. Min. Typ. Min. Typ. Max. Typ. Max. Typ. Max. Max. Max. Max. Max. Max. Max. Typ. Max. Typ. Max.
14
12
16
12
20
14
1.1
1.5
1.1
1.8
1.4
2.3
3
5
9
0.3
0.4
0.8
1.5 1.95 1.55 2.1
Outline Drawing
20-3000
L = 20-200 MHz
M = 200-1500 MHz
U = 1500-3000 MHz
Typical Performance Data
Frequency
(MHz)
Total Loss
1
(dB)
S-1
20.00
40.00
60.00
80.00
100.00
400.00
600.00
800.00
1000.00
1400.00
4.06
4.06
4.07
4.07
4.08
4.08
4.07
4.07
4.07
4.12
4.18
4.21
4.29
4.37
4.47
Amplitude
Unbalance
(dB)
0.02
0.02
0.02
0.02
0.02
0.02
0.03
0.03
0.03
0.04
0.07
0.09
0.17
0.25
0.28
Isolation
(dB)
Phase
Unbalance
(deg.)
0.01
0.03
0.04
0.05
0.04
0.22
0.30
0.34
0.48
0.61
0.66
0.71
0.92
1.43
1.80
VSWR
S
VSWR
1
VSWR
2
S-2
4.08
4.08
4.09
4.09
4.10
4.10
4.09
4.10
4.10
4.16
4.25
4.30
4.45
4.62
4.76
15.35
14.99
14.75
14.64
14.57
14.77
15.14
15.62
16.24
17.85
19.60
20.27
20.63
19.58
18.76
1.68
1.67
1.66
1.67
1.67
1.65
1.63
1.61
1.60
1.54
1.47
1.44
1.38
1.33
1.32
1.52
1.49
1.48
1.47
1.46
1.48
1.51
1.54
1.57
1.64
1.67
1.65
1.62
1.67
1.73
1.52
1.49
1.48
1.47
1.46
1.47
1.49
1.52
1.56
1.63
1.70
1.71
1.73
1.84
1.93
Outline Dimensions (
inch
)
mm
A
2.00
50.80
H
0.39
9.91
B
2.00
50.80
J
1.00
25.40
C
0.75
19.05
K
0.50
12.70
D
1.00
25.40
L
1.00
25.40
E
0.25
6.35
F
1.500
38.10
G
0.125
3.18
wt
grams
170.0
1800.00
2000.00
2400.00
2800.00
3000.00
1. Total Loss = Insertion Loss + 3dB splitter loss.
ZAPD-30+
TOTAL LOSS
5.0
S-1(dB)
S-2(dB)
30
ZAPD-30+
ISOLATION
TOTAL LOSS (dB)
ISOLATION (dB)
0
600
1200
1800
2400
3000
4.8
4.6
4.4
4.2
4.0
FREQUENCY (MHz)
25
20
15
10
5
0
600
1200
1800
2400
3000
FREQUENCY (MHz)
2.2
2.0
1.8
ZAPD-30+
VSWR
#S-VSWR
#1-VSWR
#2-VSWR
electrical schematic
VSWR
1.6
1.4
1.2
1.0
0
600
1200
1800
2400
3000
FREQUENCY (MHz)
ISO 9001 ISO 14001 AS 9100
CERTIFIED
P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661
The Design Engineers Search Engine
IF/RF MICROWAVE COMPONENTS
Mini-Circuits
®
For detailed performance specs
& shopping online see web site
®
Provides ACTUAL Data Instantly at
minicircuits.com
REV. B
M127604
ZAPD-30+
HY/TD/CP/AM
Notes: 1.
Performance and quality attributes and conditions not expressly stated in this specification sheet are intended to be excluded and do not form a part of this specification sheet.
2.
Electrical specifications
and performance data contained herein are based on Mini-Circuit’s applicable established test performance criteria and measurement instructions.
3.
The parts covered by this specification sheet are subject to
Mini-Circuits standard limited warranty and terms and conditions (collectively, “Standard Terms”); Purchasers of this part are entitled to the rights and benefits contained therein. For a full statement of the Standard
Terms and the exclusive rights and remedies thereunder, please visit Mini-Circuits’ website at www.minicircuits.com/MCLStore/terms.jsp.
100614
