MX29LV800CTMI-55R datasheet, PDF

MX29LV800CTMI-55R: Description8M X 16 FLASH 3V PROM, 70 ns, PBGA48; Categorystorage storage; File Size3MB，76 Pages; ManufacturerMacronix; Websitehttp://www.macronix.com/en-us/Pages/default.aspx

Download Datasheet Parametric View All

MX29LV800CTMI-55R Overview

8M X 16 FLASH 3V PROM, 70 ns, PBGA48

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Maker	Macronix
Parts packaging code	SOIC
package instruction	SOP, SOP44,.63
Contacts	44
Reach Compliance Code	unknow
ECCN code	EAR99
Maximum access time	55 ns
Spare memory width	8
startup block	TOP
command user interface	YES
Universal Flash Interface	YES
Data polling	YES
JESD-30 code	R-PDSO-G44
JESD-609 code	e0
length	28.5 mm
memory density	8388608 bi
Memory IC Type	FLASH
memory width	16
Number of functions	1
Number of departments/size	1,2,1,15
Number of terminals	44
word count	524288 words
character code	512000
Operating mode	ASYNCHRONOUS
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
organize	512KX16
Package body material	PLASTIC/EPOXY
encapsulated code	SOP
Encapsulate equivalent code	SOP44,.63
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Parallel/Serial	PARALLEL
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
power supply	3/3.3 V
Programming voltage	3 V
Certification status	Not Qualified
ready/busy	YES
Maximum seat height	3 mm
Department size	16K,8K,32K,64K
Maximum standby current	0.000005 A
Maximum slew rate	0.03 mA
Maximum supply voltage (Vsup)	3.6 V
Minimum supply voltage (Vsup)	3 V
Nominal supply voltage (Vsup)	3.3 V
surface mount	YES
technology	CMOS
Temperature level	INDUSTRIAL
Terminal surface	Tin/Lead (Sn/Pb)
Terminal form	GULL WING
Terminal pitch	1.27 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
switch bit	YES
type	NOR TYPE
width	12.6 mm

MX29LV400C T/B

MX29LV800C T/B

MX29LV160C T/B

MX29LV400C T/B, MX29LV800C T/B,

MX29LV160C T/B

DATASHEET

The MX29LV160C T/B product family has been discontinued. The MX29LV160C T/B

product family is not recommended for new designs. The MX29LV160D T/B family is the

recommended replacement. Please refer to MX29LV160D T/B datasheet for full specifications

and ordering information, or contact your local sales representative for additional support.

P/N:PM1300

REV. 2.6, DEC. 22, 2011
