ZC16PD-960-S

Description
890MHz - 960MHz RF/MICROWAVE COMBINER, 1dB INSERTION LOSS, CASE UU179
CategoryWireless rf/communication    Radio frequency and microwave
File Size70KB,1 Pages
ManufacturerMini-Circuits
Websitehttps://www.minicircuits.com
Download Datasheet Parametric View All

ZC16PD-960-S Overview

890MHz - 960MHz RF/MICROWAVE COMBINER, 1dB INSERTION LOSS, CASE UU179

ZC16PD-960-S Parametric

Parameter NameAttribute value
Is it lead-free?Contains lead
Is it Rohs certified?incompatible
MakerMini-Circuits
Reach Compliance Codeunknown
Other featuresSMA, ISOLATION-MIN (DB):20
Characteristic impedance50 Ω
structureCOAXIAL
Maximum input power (CW)40 dBm
Maximum insertion loss1 dB
JESD-609 codee0
Maximum operating frequency960 MHz
Minimum operating frequency890 MHz
Maximum operating temperature100 °C
Minimum operating temperature-55 °C
RF/Microwave Device TypesCOMBINER
Terminal surfaceTIN LEAD
Maximum voltage standing wave ratio1.2
Coaxial
Power Splitter/Combiner
16 Way-0°
Maximum Ratings
Operating Temperature
Storage Temperature
Power Input (as a splitter)
Internal Dissipation
-55°C to 100°C
-55°C to 100°C
10W max.
2.4W max.
ZC16PD-960
50Ω
890 to 960 MHz
Features
high isolation, 28 dB typ.
low insertion loss, 0.5 dB typ.
excellent VSWR, 1.06:1 typ.
up to 10W power input as splitter
rugged, shielded case
Connectors
SMA
CASE STYLE: UU179
Model
ZC16PD-960-S
Price
$295.00
Qty.
(1-9)
Coaxial Connections
SUM PORT
PORT 1,2,3......,16
S
1,2,3......,16
Applications
• UHF
• cellular
• communication systems
FREQ.
RANGE
(MHz)
f
L
-f
U
890-960
Splitter Electrical Specifications
INSERTION LOSS (dB)
ABOVE 12 dB
AMPLITUDE
UNBALANCE
(dB)
Max.
0.5
ISOLATION
(dB)
VSWR
(:1)
S
Typ. Max.
1.06 1.3
OUT
Typ. Max.
1.06
1.2
Outline Drawing
Typ. Min.
28
20
Typ. Max.
0.5
1.0
Typical Performance Data
Frequency
(MHz)
890.00
898.00
901.75
907.75
915.25
919.75
925.00
930.25
938.50
942.25
946.75
953.50
957.25
958.00
960.00
Insertion Loss
(dB)
S-1
12.37
12.39
12.30
12.38
12.39
12.37
12.39
12.38
12.39
12.37
12.39
12.36
12.38
12.37
12.39
Amplitude
Unbalance
(dB)
0.24
0.24
0.22
0.25
0.23
0.25
0.24
0.25
0.26
0.24
0.25
0.26
0.24
0.26
0.25
Isolation
(dB)
1-2
30.43
30.07
29.88
29.58
29.16
28.89
28.61
28.30
27.83
27.60
27.29
26.89
26.68
26.63
26.51
1-9
41.59
40.94
40.62
40.17
39.64
39.39
39.06
38.77
38.25
38.08
37.83
37.51
37.30
37.28
37.19
VSWR
S
1.09
1.07
1.07
1.06
1.04
1.04
1.04
1.03
1.03
1.04
1.04
1.06
1.06
1.07
1.07
VSWR
1
1.00
1.01
1.01
1.01
1.01
1.02
1.02
1.02
1.03
1.03
1.03
1.03
1.04
1.04
1.04
ZC16PD-960
INSERTION LOSS
15
INSERTION LOSS (dB)
ISOLATION (dB)
50
ZC16PD-960
ISOLATION
1-2(dB)
1-9(dB)
Outline Dimensions (
inch
)
mm
A
B
8.50
3.95
215.90 100.33
G
H
.187 4.250
4.75 107.95
C
.75
19.05
J
.38
9.65
D
E
.250 8.250
6.35 209.55
K
.500
12.70
L
.475
12.07
F
_
_
M
wt
3.475 grams
88.27
710
14
13
12
11
10
890
44
38
32
26
20
890
904
918
932
946
960
904
918
932
946
960
FREQUENCY (MHz)
ZC16PD-960
VSWR
1.20
#S-VSWR
1.16
VSWR
1.12
1.08
1.04
1.00
890
#1-VSWR
FREQUENCY (MHz)
electrical schematic
904
918
932
946
960
FREQUENCY (MHz)
REV. OR
M95084
ZC16PD-960
HY/TD/CP
060120
