Power Splitter/Combiner
4 Way-0°
Operating Temperature
Storage Temperature
Power Input (as a splitter)
Internal Dissipation
Coaxial
ZC4PD-900+
ZC4PD-900
50Ω
-55°C to 100°C
-55°C to 100°C
10W max.
0.375W max.
800 to 900 MHz
Features
• high isolation, 30dB typ.
• excellent VSWR
• up to 10W power input as splitters
CASE STYLE: Z184
Connectors Model
Price
SMA
ZC4PD-900-S(+)
$89.95
Maximum Ratings
Qty.
(1-9)
Permanent damage may occur if any of these limits are exceeded.
Coaxial Connections
SUM PORT
PORT 1
PORT 2
PORT 3
PORT 4
S
1
2
3
4
Applications
+ RoHS compliant in accordance
with EU Directive (2002/95/EC)
The +Suffix identifies RoHS Compliance. See our web site
for RoHS Compliance methodologies and qualifications.
• cellular
• communication systems
Electrical Specifications
FREQ.
RANGE
(MHz)
f
L
-f
U
ISOLATION
(dB)
INSERTION LOSS
(dB)
ABOVE 6.0 dB
Typ.
0.3
Max.
0.6
PHASE
UNBALANCE
(Degrees)
Max.
3
AMPLITUDE
UNBALANCE
(dB)
S
Max.
0.2
Typ.
1.08
VSWR
(:1)
OUT
Max.
1.25
Typ.
1.17
Max.
1.30
Typ. Min.
30
20
Outline Drawing
800-900
Typical Performance Data
Freq.
(MHz)
S-1
800.00
810.00
815.00
820.00
825.00
830.00
835.00
840.00
845.00
860.00
870.00
880.00
890.00
900.00
6.26
6.25
6.25
6.26
6.26
6.26
6.26
6.27
6.27
6.22
6.21
6.25
6.26
6.23
Total Loss
1
(dB)
S-2
6.27
6.25
6.26
6.24
6.26
6.27
6.27
6.28
6.28
6.24
6.23
6.25
6.26
6.24
S-3
6.19
6.17
6.17
6.17
6.19
6.19
6.19
6.21
6.20
6.14
6.15
6.16
6.17
6.13
S-4
6.22
6.19
6.19
6.21
6.21
6.21
6.22
6.24
6.23
6.18
6.19
6.20
6.20
6.17
Amp.
Unbal.
(dB)
0.08
0.08
0.09
0.08
0.08
0.08
0.08
0.06
0.08
0.09
0.08
0.09
0.09
0.11
Isolation
(dB)
1-2
29.00
31.49
33.00
34.42
35.76
36.60
36.57
35.62
34.37
30.33
28.14
26.39
25.00
23.76
2-3
33.10
34.86
35.88
36.97
38.19
39.45
40.67
41.88
42.64
40.98
38.39
36.10
34.17
32.54
3-4
27.48
29.66
30.87
32.30
33.81
35.27
36.55
37.15
36.87
32.84
30.31
28.24
26.54
25.13
Phase VSWR VSWR VSWR VSWR VSWR
Unbal.
S
1
2
3
4
(deg.)
0.41
0.52
0.45
0.47
0.41
0.49
0.48
0.55
0.60
0.54
0.70
0.63
0.62
0.57
1.11
1.11
1.11
1.11
1.11
1.11
1.10
1.10
1.09
1.07
1.05
1.03
1.02
1.02
1.15
1.15
1.16
1.15
1.15
1.14
1.13
1.12
1.12
1.11
1.12
1.14
1.16
1.17
1.15
1.16
1.16
1.16
1.15
1.15
1.14
1.13
1.12
1.11
1.13
1.15
1.17
1.17
1.16
1.17
1.17
1.17
1.17
1.16
1.15
1.14
1.13
1.13
1.14
1.16
1.18
1.19
1.17
1.17
1.17
1.17
1.16
1.16
1.15
1.14
1.13
1.13
1.15
1.17
1.19
1.19
Outline Dimensions (
inch
)
mm
A
B
C
2.26
2.00
.70
57.40 50.80 17.78
K
L
.125
1.13
3.18 28.70
M
.35
8.89
D
G
J
.200 2.060 1.800
5.08 52.32 45.72
1. Total Loss = Insertion Loss + 6dB splitter loss.
ZC4PD-900
TOTAL LOSS
6.8
S-1(dB)
TOTAL LOSS (dB)
6.6
6.4
6.2
6.0
800
S-3(dB)
ZC4PD-900
ISOLATION
80
70
ISOLATION (dB)
60
50
40
30
20
10
0
800
1-2(dB)
2-3(dB)
3-4(dB)
N
P
wt
.38
.500 grams
9.65 12.70
59
825
850
FREQUENCY (MHz)
875
900
825
850
FREQUENCY (MHz)
875
900
1.60
#S-VSWR
1.40
VSWR
ZC4PD-900
VSWR
#1-VSWR
#3-VSWR
electrical schematic
1.20
1.00
800
825
850
FREQUENCY (MHz)
875
900
ISO 9001 ISO 14001 AS 9100
CERTIFIED
P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661
The Design Engineers Search Engine
IF/RF MICROWAVE COMPONENTS
Mini-Circuits
®
For detailed performance specs
& shopping online see web site
®
Provides ACTUAL Data Instantly at
minicircuits.com
Notes: 1.
Performance and quality attributes and conditions not expressly stated in this specification sheet are intended to be excluded and do not form a part of this specification sheet.
2.
Electrical specifications
and performance data contained herein are based on Mini-Circuit’s applicable established test performance criteria and measurement instructions.
3.
The parts covered by this specification sheet are subject to
Mini-Circuits standard limited warranty and terms and conditions (collectively, “Standard Terms”); Purchasers of this part are entitled to the rights and benefits contained therein. For a full statement of the Standard
Terms and the exclusive rights and remedies thereunder, please visit Mini-Circuits’ website at www.minicircuits.com/MCLStore/terms.jsp.
REV. B
M127604
ED-96470
ZC4PD-900
HY/TD/CP/AM
100617
