Coaxial
Power Splitter/Combiner
6 Way-0° 50Ω
Maximum Ratings
Operating Temperature
Storage Temperature
Power Input (as a splitter)
Internal Dissipation
-55°C to 100°C
-55°C to 100°C
10W max.
0.875W max.
ZC6PD-1900
1700 to 1900 MHz
Features
•
•
•
•
•
low insertion loss, 0.4 dB typ.
high isolation, 30 dB typ.
excellent VSWR, 1.1:1 typ.
up to 10W power input as splitters
rugged shielded case
Connectors
SMA
CASE STYLE: AB185
Model
ZC6PD-1900-S
Price
$134.95
Qty.
(1-9)
Coaxial Connections
SUM PORT
PORT 1,2,3,4,5,6
S
1,2,3,4,5,6
Applications
• PCS/DCS
• communication systems
• instrumentation
Splitter Electrical Specifications
FREQ.
RANGE
(MHz)
f
L
-f
U
1700-1900
ISOLATION
(dB)
INSERTION LOSS (dB)
ABOVE 7.8 dB
AMPLITUDE
UNBALANCE
(dB)
Max.
0.5
VSWR
(:1)
S
Typ. Max.
1.1
1.4
OUT
Typ. Max.
1.1
1.5
Typ. Min.
30
20
Typ. Max.
0.4
0.8
Typical Performance Data
Outline Drawing
Frequency
(MHz)
Insertion Loss
(dB)
Amplitude
Unbalance
(dB)
0.09
0.08
0.11
0.10
0.11
0.10
0.10
0.13
0.18
0.19
0.21
0.19
0.20
0.21
0.22
Isolation
(dB)
Adjacent
Opposite
30.11
31.20
32.44
33.74
34.80
37.43
40.51
43.58
47.36
49.71
45.06
41.39
39.06
37.34
37.20
34.33
34.89
35.60
36.24
36.89
37.43
39.64
43.58
41.31
42.74
45.06
46.72
48.61
49.94
50.18
VSWR
S
VSWR
OUTPUTS
1700.00
1715.00
1730.00
1743.75
1755.00
1775.00
1795.00
1807.00
1820.00
1833.75
1855.00
1870.00
1885.00
1897.50
1900.00
8.06
8.09
8.14
8.20
8.23
8.18
8.12
8.12
8.13
8.10
8.21
8.26
8.27
8.31
8.28
1.16
1.14
1.11
1.10
1.08
1.06
1.06
1.07
1.08
1.09
1.12
1.14
1.16
1.18
1.19
1.05
1.05
1.06
1.06
1.06
1.07
1.08
1.08
1.08
1.09
1.10
1.10
1.11
1.11
1.11
ZC6PD-1900
INSERTION LOSS
10.0
INSERTION LOSS (dB)
ZC6PD-1900
ISOLATION
80
70
ISOLATION (dB)
60
50
40
30
20
10
1700
1750
1800
FREQUENCY (MHz)
1850
1900
ADJACENT
OPPOSITE
Outline Dimensions (
inch
)
mm
A
4.76
120.90
G
.125
3.18
B
3.00
76.20
H
.50
12.70
C
.53
13.46
J
.25
6.35
D
E
.150 4.610
3.81 117.09
K
1.13
28.70
L
.500
12.70
F
1.500
38.10
wt
grams
183
9.5
9.0
8.5
8.0
7.5
7.0
6.5
6.0
1700
1750
1800
FREQUENCY (MHz)
ZC6PD-1900
VSWR
1.20
#S VSWR
1.15
VSWR
1.10
1.05
1.00
1700
OUTPUTS
1850
1900
electrical schematic
1750
1800
FREQUENCY (MHz)
1850
1900
Mini-Circuits
®
INTERNET
http://www.minicircuits.com
P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661
REV. OR
M96283
ZC6PD-1900
HY/TD/CP
060119
Distribution Centers
NORTH AMERICA 800-654-7949 • 417-335-5935 • Fax 417-335-5945 • EUROPE 44-1252-832600 • Fax 44-1252-837010
Mini-Circuits
ISO 9001 & ISO 14001
Certified
